3533339COM
TV Stand
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor to stud in wall Iif instructed to).
- Do Not allow children to climb on unit.
- Put heavy items in lower shelves or drawrs.
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
You
Tube
B343533339COM2
Tough
Advertisement
Related Manuals for Ameriwood HOME B343533339COM2
Summary of Contents for Ameriwood HOME B343533339COM2
- Page 1 Tough WARNING Assembly Difficulty Meter - Unit can tip over causing severe injury or death. Follow Ameriwood Home - Anchor to stud in wall Iif instructed to). - Do Not allow children to climb on unit. Tube - Put heavy items in lower shelves or drawrs.
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 - Open your item in the area you plan to keep it to avoid excessive heavy lifting. -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Parts are labeled on the surface or edge of the part Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing,... - Page 4 Before You Start Please Note: You may need to lightly tap the wood dowels into the holes during your assembly process. ameriwoodhome.com...
-
Page 5: Board Identification
Board Identification Not actual size Left Panel Right Panel Partition 33533339010 33533339020 33533339030 33533339040 (x2) (x2) (x2) Shelf Back Bottom 33533339060 33533339070 33533339050 Left Front Leg (x2) (x4) (x2) Shelf Rail 33533339110 Lower Rail Side Rail 33533339080 33533339090 33533339100 ameriwoodhome.com... - Page 6 Board Identification Not actual size Left Rear Leg Right Front Leg Center Front Leg Right Rear Leg 33533339120 33533339130 33533339150 33533339140 BACK SIDE (x2) (x4) (x2) (x2) Drawer Front Drawer Back Drawer Bottom Drawer Side 33533339160 39991167346200C 39991167065190B 39991339066210D Hammer Block (Piece of wood to use to attach legs) Center Rear Leg...
-
Page 7: Part List
Part List Actual Size (x22) (x22) (x26) (x4) (x8) #A22700 #A22710 #A21670 confirmat screw #A21970 cam lock cam bolt wood dowel #A23030 drive fastener (x18) (x4) (x16) (x18) (x18) (x20) #A22770 #A22795 7/8" truss #6 x 7/16" #A22790 #8 x 7/16" quick lock round head #A17400... - Page 8 STEP 1 (x1) (x18) ameriwoodhome.com...
- Page 9 STEP 2 (x6) Press locking sleeves (11) into edge holes as shown. ameriwoodhome.com...
- Page 10 STEP 3 Hammer Block Top edges of both parts will be flush. Finished Edge Hole(s) in this surface. End View Be sure your parts are positioned as illustrated. Position and insert locking bolts (10) of left front leg (K) into edge holes of left panel (A) as shown. Be sure both parts are positioned as shown.
- Page 11 STEP 4 Hammer Block Top edges of both parts will be flush. Hole(s) in this surface. End View Be sure your parts are positioned as illustrated. Position and insert locking bolts (10) of left rear leg (L) into edge holes of left panel (A) as shown. Be sure both parts are positioned as shown.
- Page 12 STEP 5 (x6) Press locking sleeves (11) into edge holes as shown. ameriwoodhome.com...
- Page 13 STEP 6 Hammer Block Top edges of both parts will be flush. Finished Edge Hole(s) in this surface. End View Be sure your parts are positioned as illustrated. Position and insert locking bolts (10) of right front leg (M) into edge holes of right panel (B) as shown.
- Page 14 STEP 7 Hammer Block Top edges of both parts will be flush. Hole(s) in this surface. End View Be sure your parts are positioned as illustrated. Position and insert locking bolts (10) of right rear leg (N) into edge holes of right panel (B) as shown.
- Page 15 STEP 8 (x6) Press locking sleeves (11) into edge holes as shown. ameriwoodhome.com...
- Page 16 STEP 9 Hammer Block Top edges of both parts will be flush. Finished Edge Position and insert locking bolts (10) of center front leg (O) into edge holes of partition (C) as shown. Be sure both parts are positioned as shown. Place the hammer block on top of leg in each of the 3 locking bolt locations and give a firm strike to lock together.
- Page 17 STEP 10 Hammer Block Top edges of both parts will be flush. Position and insert locking bolts (10) of center rear leg (Q) into edge holes of partition (C) as shown. Be sure both parts are positioned as shown. Place the hammer block on top of leg in each of the 3 locking bolt locations and give a firm strike to lock together.
- Page 18 STEP 11 Marked with a "L" (x2) (x1) (x2) (x4) (x2) Quick Assembly Proper orientation of CAM LOCK ameriwoodhome.com...
- Page 19 STEP 12 Marked with a "R" (x2) (x1) (x4) (x2) (x2) Quick Assembly Proper orientation of CAM LOCK ameriwoodhome.com...
- Page 20 STEP 13 Marked with a "L" Marked with a "R" (x1) (x2) (x8) (x4) (x2) Side 1 Side 2 ameriwoodhome.com...
- Page 21 STEP 14 (x6) ameriwoodhome.com...
- Page 22 STEP 15 Quick Assembly (x8) (x6) (x8) Proper orientation of CAM LOCK ameriwoodhome.com...
- Page 23 STEP 16 Press shelf rail (H) onto quick locks (8). Turn screw in quick lock (8) clockwise to lock both parts into place. End View ameriwoodhome.com...
- Page 24 STEP 17 (x8) (x8) ameriwoodhome.com...
- Page 25 STEP 18 ameriwoodhome.com...
- Page 26 STEP 19 (x4) (x4) Insert wood dowels (3) into top edge of each back (G). Top edge has the larger holes. Attach a back (G) to each bottom (E) as shown with screws (4). ameriwoodhome.com...
- Page 27 STEP 20 Finished Edge Finished Edge ameriwoodhome.com...
- Page 28 STEP 21 ameriwoodhome.com...
- Page 29 STEP 22 Be sure the wood dowels (3) in the backs (G) insert into the holes in the top (D). ameriwoodhome.com...
- Page 30 STEP 23 (x4) (x8) SIDE SIDE ameriwoodhome.com...
- Page 31 STEP 24 (x8) Be sure groove in drawer sides are centered with groove in drawer front (P). SIDE SIDE ameriwoodhome.com...
- Page 32 STEP 25 SIDE finished surface SIDE ameriwoodhome.com...
- Page 33 STEP 26 (x8) Tap drive fasteners (5) lightly with hammer to fully insert. BACK SIDE SIDE ameriwoodhome.com...
- Page 34 STEP 27 (x8) (x4) (x2) (x2) Attach slides first and then the handle. SIDE SIDE ameriwoodhome.com...
- Page 35 STEP 28 (x2) (x4) ameriwoodhome.com...
- Page 36 STEP 29 With someone's help, carefully turn unit over on it's top as shown. Insert quick locks (8) into legs as shown. (x12) ameriwoodhome.com...
- Page 37 STEP 30 With the quick locks (8) inserted into legs, press lower rails (I) and side rails (J) onto the quick locks (8) as shown. Lock into place. Turn clockwise to lock parts into place. ameriwoodhome.com...
- Page 38 STEP 31 Note: The drawer bracket holes are slotted. Drawer fronts can be adjusted by loosening screws, making needed adjustments and re-tightening screws. roller cabinet member drawer runner roller ameriwoodhome.com...
- Page 39 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Maximum TV size: 69" flat screen TV Warning Label #B64358 30 lbs 13.6 kg Apply TV warning label somewhere on your unit for future TV size and weight limits requirements.
- Page 40 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com...
- Page 41 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 42 Español Página 10 Coloque e inserte los pernos de bloqueo (10) de la pata delantera izquierda (K) en los orificios de los bordes del panel izquierdo (A) como se muestra. Asegúrese de que ambas piezas están colocadas como se muestra. Coloque el bloque de martillo en la parte superior de la pata en cada una de las 3 posiciones de los pernos de bloqueo y dé...
- Page 43 Español Página 15 Presione los casquillos de cierre (11) en los agujeros de los bordes como se muestra. Página 16 Los bordes superiores de ambas partes estarán al ras. Coloque e inserte los pernos de bloqueo (10) de la pata delantera central (O) en los orificios de los bordes del tabique (C) como se muestra.
- Page 44 Visite el sitio web de su tienda local, califique su comprado y denos sus comentarios! Nos gustaría enviar un gran "Agradecimiento" a todos nuestros clientes por tomarse el tiempo de ensamblar este producto de Ameriwood Home, y por darnos sus valiosos comentarios. Gracias ameriwoodhome.com...
- Page 45 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-800-489-3351 (sans frais) du Lundi au Vendredi de 9h à...
- Page 46 Français Page 10 Placez et insérez les verrous de fermeture (10) du pied avant gauche (K) dans les trous de bord du panneau gauche (A) comme illustré. Assurez-vous que les deux pièces sont positionnées comme indiqué. Placez la sécurité anti-chute sur le dessus de la jambe dans chacun des 3 emplacements de verrous de fermeture et donnez un bon coup pour verrouiller l'ensemble.
- Page 47 Français Placez la sécurité anti-chute sur le dessus de la jambe dans chacun des 3 emplacements de verrous de fermeture et donnez un bon coup pour verrouiller l'ensemble. Le verrou de fermeture (10) s'enclenchera dans le manchon verrouillable (11). AVIS IMPORTANT : une fois verrouillées ensemble, les pièces ne peuvent pas être séparées. Remarque : Un maillet en caoutchouc peut être utilisé...
- Page 48 Visitez le site Web de votre détaillant local, évaluez votre produit acheté et laissez-nous quelques commentaires ! Nous tenons à offrir un grand "Merci" à tous nos clients pour avoir pris le temps d'assembler ce produit "Ameriwood Home", et de nous donner vos commentaires précieux. Merci ameriwoodhome.com...
