- Page 1 FEED PUMPS AST81 Instruction manual mod. AST81 aircom.it...
- Page 2 AVAILABLE MODELS mod. AST81 Airless pump with flow rate of 11 l/min AIRCOM - 2022 - v. 1.0 ®...
- Page 3 Filter and gasket replacement Anamaly resolution Spare parts and components Disposal Support WARNINGS! Carefully read and follow all instructions and safety precautions before using the product. MANUALS Our manuals are available at aircom.it/en/support/manuals/ Or, by scanning the QR Code on this page.
- Page 4 Replace the nameplate and any removed, damaged or illegible stickers. OBBLIGO DI IMPIEGO DI OCCHIALI E MASCHERINA aircom.it...
- Page 5 The equipment covered in this manual is a painting unit which allows you to spray paint any type of material. Characterized by a remarkable practicality, versatility and ease of use, the AST81 employs a pneumatically operated high-capacity piston pump unit.
-
Page 6: Technical Features
All gaskets are of a special type with high quality and high resistance; the valves are in stainless steel. FEATURE AST81 CAAPCITY 11 lt - 3 gpm PRESSURE RATIO 68:1 PRODUCT MAX. - Page 7 PRODUCTS AND DIMENSIONS The AST81 series painting units are designed for painting large surfaces and for uses such as: painting on behalf of third parties, shipyards, large and medium-sized carpentry shops, industrial body shops, mechanical constructions in general. The products that can be supplied are: high solid paints, normal paints, primers and glues.
- Page 8 The unit is supplied with a condensate filter with regulator, it is recommended to feed with a pressure of 6.5 bar Max. It is recommended to use dry compressed air for best painting results. aircom.it...
- Page 9 • Pay close attention to the writing on the pipes • Do not exceed the maximum pressure indicated by th manufacturer. • Given the high power of the pump (up to 240bar), we recommen the use of certified and tested guns up to 300 bar. aircom.it...
- Page 10 • Never point the paint gun at the human body or at animals • Do not modify or alter the equipment as supplied; in addition to bein able to cause malfunctions, or worse, even dangerous failures, you would invalidate the guarantee. aircom.it...
- Page 11 • Close the paint return cock very slowly • Discharge the product contained in the pipes by pressing the gu lever. • Thoroughly clean the unit NEVER OPEN the return valve before having turned the pressure adjustment handwheel to minimum. aircom.it...
- Page 12 EMERGENCY SITUATIONS FIRE: Use powder extinguishers, which must be located near the equipment as required by LAW (Legislative Decree 81/08 safety in the company) DO NOT USE WATER. Personnel must be trained to know how to operate under such conditions. aircom.it...
-
Page 13: Maintenance
• Do not wear rings, watches, chains, bracelets, etc. during maintenanc operations. • Always use personal protective equipment (gloves, goggles, safet shoes). • Use only original spare parts • Do not use open flames, sharp points or pins for cleaning • No smoking aircom.it... - Page 14 6. Clean the line filter by disassembling and washing it, paying particul attention to the filter sieve and the gun. 7. Carefully clean the inside of the product passage gun head aircom.it...
-
Page 15: Filter Replacement
2 bar (check that the stem starts to move), then turn the gasket holder cup clockwise. For slight leaks (usually after 50/80 hours of work) a slight pressure on the gasket holder cup is sufficient. Be very careful not to block the stem. aircom.it... - Page 16 • Clean tube and filter. • Spray gun nozzle hole • Clean the nozzle needle blocked by dry paint. and cap without using metal objects. aircom.it...
-
Page 17: Scheduled Maintenance
Check the clogging of the air filter equipment stationary without carrying Check if the screws are fixed very well out work activities Check pneumatic connection’s Check pump membrane wear Check pump shaft wear (*) Operation to be performed just from trained and professional operators aircom.it... - Page 18 FEED PUMPS AST81 Spare parts and components aircom.it...
-
Page 19: Spare Parts
SPARE PARTS COMPONENTS LIST aircom.it... - Page 20 SPARE PARTS COMPONENTS LIST aircom.it...
- Page 21 DOES NOT CONTAIN POLLUTING OILS but the waste paints must in any case be disposed of by authorized consortia. Do not throw in common waste. Do not disperse in the environment. SUPPORT DO YOU NEED HELP? We are at your disposal. +39 0124 5154 44 aircom@aircom.it Online support aircom.it...
- Page 22 AIRCOM SRL © 2022 - ALL RIGHTS RESERVED...
- Page 23 DISCOVER ALL PRODUCTS Follow us aircom.it...
