Summary of Contents for Advantech TREK-60
- Page 1 User Manual TREK-60 Modular AI Platform for Scalable Surveillance and Fleet Management...
- Page 2 The documentation and the software included with this product are copyrighted 2021 by Advantech Co., Ltd. all rights reserved. Advantech Co., Ltd. reserves the right to improve the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
- Page 3 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This type of cable is available from Advantech. Contact your local supplier for ordering information.
- Page 4 To assist us with improving this manual, we welcome any comments and constructive criticism. Please send all feedback in writing to support@advantech.com. Technical Support and Assistance Visit the Advantech website at http://support.advantech.com to obtain the latest product information. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
- Page 5 Placez le cordon d’alimentation à l’écart des zones à fort trafic. Ne placez rien sur le cordon d’alimentation.La tension et le courant du cordon doivent être supérieurs à la tension et au courant indiqués sur le produit. TREK-60 User Manual...
- Page 6 (this product is not a toy). ATTENTION: Ce produit n’est pass un jouet et devrait ètregard Jouet et devrait ètre gardè hors de la portèe des enfants. TREK-60 User Manual...
- Page 7 Ce produit doit étre certifié par UL pour l'alimentation électrique ou en courant continu, Tension nominale 9 ~ 32 V , 14A, et TMA 40 °C (104 °F), contactez si vous avez besoin d’aide Advantech en sait plus. TREK-60 User Manual...
- Page 8 TREK-60 User Manual viii...
-
Page 9: Table Of Contents
Quick Tour....................10 Figure 2.1 TREK-60 Front View..........10 Figure 2.2 TREK-60 Rear View (PoE Configuration)....10 Figure 2.3 TREK-60 Front Door with Key Lock Protection ..10 Figure 2.4 TREK-60 Front I/O............ 11 Figure 2.5 TREK-60 RF Extension Module ....... 11 Figure 2.6 TREK-60 I/O View (with PoE)........ - Page 10 TREK-60 User Manual...
-
Page 11: Chapter 1 General Information
Chapter General Information... -
Page 12: Introduction
1.1 Introduction Advantech’s TREK-60 is a rugged, modular video AI platform aimed at fleet manage- ment and surveillance applications. Powered by a 7th generation Intel® Core™ i7/i5/Atom™ E3900 quad-core proces- sor, TREK-60 supports up to eight camera input channels and AI accelerator expan- sion to enable scalable video inferences on edge devices. -
Page 13: Modular Design
1.3 Modular Design TREK-60 consists of an industrial computer with a ruggedized metal enclosure and RF and IO extension modules that enable flexible expansion and integration with existing infrastructure. The modular design allows TREK-60 to be easily customized for entry-level or high-end computing applications. -
Page 14: General Specifications
1 x G-sensor; linear acceleration zero-g level offset accuracy is ±40 mg 1 x Accelerometer and gyroscope 3 x Thermal sensors reserved (for CPU, top side of main board, and underside of main board) TREK-60 User Manual... - Page 15 1 x Built-in u-blox Neo-M8N GPS/GLONASS/BeiDou module with A-GPS sup- port, or optional Neo-M8U(untethered dead reckoning), Neo-M8L (dead reckon- ing) upon request 5 x FAKRA-type antenna holes for 1x GPS, 2x WI-FI+BT, 2x WWAN/LTE with WI-FI/WWAN MIMO supported TREK-60 User Manual...
- Page 16 – -30 ~ 50 °C/-22 ~ 122 °F for TREK-60 SKU 2 – -30 ~ 70 °C/-22 ~ 158 °F for TREK-60 SKU 2 (without RF/SDP or 40W PoE limit) Storage Temperature: -40 ~ 85 °C/-40 ~ 176 °F ...
- Page 17 33W (for sufficient power at 90% efficiency). Note 2: The system tested was a TREK-60 platform equipped with 32 GB UMLC mSATA, u-Blox NEO-M8N, RF extension module with Wi-Fi and WWAN, SDP 2.0, and a TREK-306PH2 display.
-
Page 18: Dimensions
1.5 Dimensions Figure 1.2 TREK-60 Dimensions TREK-60 User Manual... -
Page 19: Chapter 2 System Setup
Chapter System Setup... -
Page 20: Introduction
This chapter explains the connector and port pin definitions and provides information regarding setting up the TREK-60 device. 2.2 Quick Tour Figure 2.1 TREK-60 Front View Figure 2.2 TREK-60 Rear View (PoE Configuration) Figure 2.3 TREK-60 Front Door with Key Lock Protection TREK-60 User Manual... - Page 21 Figure 2.4 TREK-60 Front I/O Figure 2.5 TREK-60 RF Extension Module Figure 2.6 TREK-60 I/O View (with PoE) TREK-60 User Manual...
-
Page 22: Installation
2.3 Installation To install the device, first connect the TREK-60 power input port to the vehicle ignition system. The power cable should be to connected directly to the battery. This allows TREK-60 to be powered on/off via the device power button or vehicle ignition signals. -
Page 23: Wall And Din Rail Mounting
2.3.3 Wall and DIN Rail Mounting The TREK-60 device can be mounted on a wall or DIN rail in various configurations, as shown in Table 2.1. The device should be fully assembled before mounting. To mount TREK-60, use four M5x10L screws to affix the device to a wall mount bracket, or use four M3x5L screws to affix the device to a DIN rail bracket). -
Page 24: Bios Setup
CMOS RAM and compares them to the results of the equipment check con- ducted during the power on self-test (POST). If a discrepancy is detected, an error message is displayed onscreen, and the user is prompted to run the BIOS setup pro- gram. TREK-60 User Manual... - Page 25 TREK-60 User Manual...
- Page 26 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2021...
