Industrial and Sanitary
Setup, Operation & Maintenance Manual
DORNER MFG. CORP.
P.O. Box 20 • 975 Cottonwood Ave.
Hartland, WI 53029-0020 USA
851-312 Rev. F
Variable Speed
VFD Controllers
For other service manuals visit our website at:
www.dorner.com/service_manuals.asp
INSIDE THE USA
TEL: 1-800-397-8664
FAX: 1-800-369-2440
OUTSIDE THE USA
TEL: 262-367-7600
FAX: 262-367-5827
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dorner VFD
Summary of Contents for Dorner VFD
- Page 1 Industrial and Sanitary Variable Speed VFD Controllers Setup, Operation & Maintenance Manual DORNER MFG. CORP. INSIDE THE USA OUTSIDE THE USA P.O. Box 20 • 975 Cottonwood Ave. TEL: 1-800-397-8664 TEL: 262-367-7600 Hartland, WI 53029-0020 USA FAX: 1-800-369-2440 FAX: 262-367-5827 For other service manuals visit our website at: www.dorner.com/service_manuals.asp...
-
Page 2: Table Of Contents
Some illustrations may show guards removed. Do NOT operate equipment without guards. Dorner’s Limited Warranty applies. Upon receipt of shipment: Dorner reserves the right to make changes at any time without notice or obligation. • Compare shipment with packing slip. Contact factory regarding discrepancies. -
Page 3: Warnings − General Safety
Hazardous voltage will cause severe injury or death. LOCKOUT POWER BEFORE wiring. A WARNING Exposed moving parts can cause severe injury. DO NOT ATTEMPT ADJUSTMENTS WITH CONVEYOR RUNNING. Industrial and Sanitary Variable Speed VFD Controllers 851-312 Rev. F Dorner Mfg. Corp. -
Page 4: Product Description
Product Description Dorner Variable Speed VFD Controllers (Figure 1)) are AC motor speed controllers for Standard and Heavy Load VFD NOTE gearmotors. For additional information, refer to the AC Figure 1 Tech MC1000 Series Installation and Operating Manual shipped with your controller. -
Page 5: Installation
Controller Mounting Bar (2x) (450333MS) Hex Head Screws, M5 x 8mm (4x) Hex Head Screws, M6 x 16mm (2x) Install mounting clips (Figure 3, item B) on conveyor. Figure 5 Industrial and Sanitary Variable Speed VFD Controllers 851-312 Rev. F Dorner Mfg. Corp. -
Page 6: Industrial Controller Mounting
Socket Head Screws M6 x 16 mm (2x) T-Bars (2x) (639971M) Socket Head Screws M6 x 20 mm (2x) Spring Nut, M6 (2x) (990605M) Controller Mounting Bar (2x) (300459M) Figure 9 Industrial and Sanitary Variable Speed VFD Controllers Dorner Mfg. Corp. 851-312 Rev. F... -
Page 7: 6100 Conveyor Mounting
Attach controller (Figure 12, item F) to conveyor with screws (K). Figure 12 Figure 14 Temporarily tighten screw (I). Install second T-bar (Figure 15, item J) into T-slot. Figure 15 Figure 12 Figure 15 Industrial and Sanitary Variable Speed VFD Controllers 851-312 Rev. F Dorner Mfg. Corp. -
Page 8: Steel Stand Leg Mounting
17)) and tighten both screws (Figure 16, item I). Figure 19 Figure 17 Figure 19 Attach controller (Figure 20, item F) to Spring Nuts (L) with screws (K). Figure 20 Figure 17 Figure 20 Industrial and Sanitary Variable Speed VFD Controllers Dorner Mfg. Corp. 851-312 Rev. F... -
Page 9: Wiring
Make the input power connections through the line connection cord grip. Refer to the manufacturer’s manual for terminations inside the VFD controller. Industrial and Sanitary Variable Speed VFD Controllers 851-312 Rev. F Dorner Mfg. Corp. -
Page 10: Preventive Maintenance And Adjustment
LOCK OUT POWER before removing guards or performing maintenance. Service Parts NOTE For replacement parts, refer to the AC Tech MC1000 Series Installation and Operating Manual shipped with your controller. Industrial and Sanitary Variable Speed VFD Controllers Dorner Mfg. Corp. 851-312 Rev. F... -
Page 11: Notes
Notes Industrial and Sanitary Variable Speed VFD Controllers 851-312 Rev. F Dorner Mfg. Corp. -
Page 12: Return Policy
A representative will discuss action to be taken on the returned items and provide a Returned Goods Authorization number for reference. There will be a return charge on all new undamaged items returned for credit where Dorner was not at fault. Dorner is not responsible for return freight on such items.
