CW60R - 6.5" Coaxial Speaker System
• 6-1/2" woofer with stiff fi berglass textured polypropylene
cone, higher cone mass and enhanced motor strength to
optimize it to a restricted enclosure volume
• Low resonance 3/4 inch pivoting tweeter
• High power drivers and crossover for long term reliability
• Performance Enclosure and new construction bracket
available
9-7/16"
240mm
PSB Speakers reserves the right to change specifications or features without notice.
© 2006 PSB Speakers, a division of Lenbrook Industries Limited.
PSB is a registered trademark of Lenbrook Industries Limited. Printed in Canada 08/06. All rights reserved.
No part of this publication may be reproduced, stored or transmitted in any form whatsoever without the written permission of PSB Speakers
824 CW60R data.
Frequency Range (-6dB):
Recommended Power:
Impedance (Nominal):
Sensitivity (2.83V @1m)
Drivers:
Overall Dimensions (Diameter x D):
Cut-out Dimensions (Diameter):

Installation Notes

• Optimal spacing between speakers should
• Make a small exploratory hole and check
8"
203mm
• Use the mounting template provided to cut
• Lightly fi ll wall cavity with fi berglass 2 feet on
3"
76mm
• Adjust electric screwdrivers to appropriate
• Angle the tweeter inward towards the
• See manual for more installation hints.
To Reach US Customer Service dial 1 888 772 0000 ext 4445 or 4342
55-20,000Hz
20-75 Watts
8 Ohms
86dB SPL
6-1/2" Woofer
3/4" Dome Tweeter
9 7/16 diameter x 3"
8"
approximately equal the distance from the
listening area to the wall.
for obstructions in wall cavity before cutting
mounting hole.
the right sized mounting hole.
either side of the system. Use standard 4"
fi berglass split to half thickness. Use 1" thick
fi berglass behind system.
torque. Tighten mounting screws fi rmly but
do not over tighten!
listening area.
