Quadro FX 5600 Additional Power requirements
The NVIDIA Quadro FX 5600 graphics board is a performance optimized high-end board. Power is
taken from the PCI Express host bus as well as two 6-pin PCI Express power connectors.
Without any auxiliary power provided to the NVIDIA Quadro FX 5600 graphics board, a buzzer on
the graphics board will beep and the graphics board will not boot.
Table 6. Configuration with Two 6-Pin Connectors
Connect (2) supplied PCI
Express 6 pin power cables.
Advertisement
Table of Contents
Related Manuals for Nvidia VCQFX5600
Summary of Contents for Nvidia VCQFX5600
- Page 1 Quadro FX 5600 Additional Power requirements The NVIDIA Quadro FX 5600 graphics board is a performance optimized high-end board. Power is taken from the PCI Express host bus as well as two 6-pin PCI Express power connectors. Without any auxiliary power provided to the NVIDIA Quadro FX 5600 graphics board, a buzzer on the graphics board will beep and the graphics board will not boot.
-
Page 2: Power By Rail
Power by Rail Table 7 lists the power by rail numbers for the NVIDIA Quadro FX 5600 graphics Board.
