Your NVIDIA GeForce 7800 GT

Graphics Card

English: Your NVIDIA GeForce 7800 GT Graphics Card
Congratulations! Your new Power Mac G5 has the high-performance NVIDIA GeForce
7800 GT PCI Express graphics card installed. Your graphics card has 256 MB DDR3 video
memory and two DVI ports.
DVI port 2
You can connect a 20-, 23-, or 30-inch Apple Cinema Display to DVI port 1 and a 20- or
23-inch Apple Cinema Display to DVI port 2.
To connect two Apple Cinema Displays to your graphics card, you may need a DVI to
DVI Adapter. If you don't have an adapter, go to the Displays Support website at
www.apple.com/support/displays for more information.
Installing Additional PCI Express Cards
Your graphics card is installed in PCI Express slot 1 in your Power Mac G5. If you install
additional PCI Express cards, follow these guidelines:
 The total combined maximum video memory for all installed graphics
cards is 1 GB.
 Install a second PCI Express card in slot 3, a third in slot 4, and a fourth
in slot 2 for optimum ventilation.
More Information
To learn more about installing PCI Express cards and connecting video devices, see the
Power Mac G5 User's Guide. Additional information is available on the Apple Service &
Support website at www.apple.com/support.
DVI port 1
