Wireless Touch Keypad
SK201
SK201 is a two-way keypad; it lets user input their PIN codes into the
alarm system for arming or disarming, and inversely, it fetches the alarm
state of the system to display to the user. Therefore the numbers on the
keypad is able to show triggered zones during an alarm, or fault and
tamper codes if occur. Its internal buzzer beeps during entry/exit delays
and even sound during an alarm.Powered by battery and running U-net
wireless technology means the SK201 is cable-free, making it an easy to
install.

Main Features

• Touch contact input
• Wakeup by motion or touch
• Displays alarm status
• Internal buzzer
• LED brightness auto adjust
• Tamper detection
• Battery powered

Using the Keypad

LED:
LED:
Information
Fault / Tamper
pending
Button &LED:
Keys 0~9, C, F
LED:
"Bell" icon, Alarm
/ Tamper
Button &LED:
Button &LED:
Button &LED:
Light sensor
Motion sensor
The alarm system is operated mainly with the keypad. The user must
first create a PIN code using the App before using the keypad. For
creating a PIN code. You need to set it from the "Users" on APP selection
menu. Press one of the user on the list to get into the Edit User. The PIN
code can be set on "Settings" of Set access rights. Each user can assign
different PIN code for operation the system by keypad. For the way how to
add other users, please refer to 5.8 on SC109 control panel user manual.
If you want to change the PIN code, you can simply input the PIN code
again and save. There are maximum 8-digit of numbers can be set on
operating the keypad. To delete it, choose arrow button on the right part of
PIN code. It will clean up the PIN code on this user.
CONFIDENTIAL – FOR TESTALARM PRAHA SPOL. S.R.O. ONLY
1
