OTS1 19" instrukcja montażu / assembly manual Wykaz elementów / List of elements Oznaczenie Oznaczenie Numer strony Numer Numer strony Numer elementu Liczba elementu Liczba Nazwa elementu / w instrukcji / opakowania / Nazwa elementu / w instrukcji / opakowania /...
Page 5
/ assembly manual OTS1 19" Montaż szkieletu - przegląd elementów / Frame assembly - list of elements Płyta górna szkieletu / Frame's top plate Płyta dolna szkieletu / Frame's bottom plate Ceownik / C-profile Patrz szczegół A / Słup szkieletu /...
Page 6
OTS1 19" instrukcja montażu / assembly manual Montaż szkieletu - połączenie słupów z płytą dolną i górną / Frame assembly - mounting posts to bottom and top plate Krok Krok Step Krok Step Step Krok Montaż pozostałych słupów Step Montaż słupa szkieletu szkieletu w płycie dolnej /...
Page 7
/ assembly manual OTS1 19" Montaż szkieletu - skręcenie słupów z płytą dolną i górną, przykręcenie ceowników / Frame assembly - screwing the frame, montage of C-profi les Krok Step Patrz szczegół H / Montaż kompletnego szkieletu (skręcanie) /...
Page 8
OTS1 19" instrukcja montażu / assembly manual Montaż stopek i belek nośnych / Montage of leveling feet and mounting profi les Krok Krok Krok Step Step Step Montaż belek nośnych do szaf o szerokości L=600 / Montaż belek nośnych do szaf o szerokości L=800 / Montaż...
Page 9
/ assembly manual OTS1 19" Montaż dachu i osłon bocznych / Montage of roof and side panels Krok Krok Step Step Montaż dachu / Montage of roof Montaż osłon bocznych / Montage of side panels Patrz szczegół N / See detail N Patrz szczegół...
Page 10
OTS1 19" instrukcja montażu / assembly manual Montaż drzwi przednich / Montage of front door Krok Step Montaż drzwi przednich szklanych / Montage of front glass door Szczegół R / Detail R Patrz szczegół R / See detail R Szczegół P / Detail P płytka dociskowa /...
Page 11
/ assembly manual OTS1 19" Montaż maskownicy 3U i drzwi tylnych / Montage of 3U module panel and rear door Krok Step Patrz szczegół T / See detail T Montaż maskownicy z przepustem szczotkowym i drzwi tylnych /...
Page 12
OTS1 19" instrukcja montażu / assembly manual Uziemienie drzwi i osłon / Doors and panels earthing Krok Step Montaż linek uziemiających / Montage of earthing cables Patrz szczegół W / Patrz szczegół V / See detail W See detail V Szczegół...
Page 13
/ assembly manual OTS1 19" Poziomowanie szafy / Level the cabinet Szczegół Y / Detail Y Poziomica / Spirit level Klucz płaski 19 / Wrench 19 Wypoziomować szafę za pomocą stopek regulacyjnych (27). Level the cabinet using the leveling feet (27) regulation.
