Simon Beta Test 7/9/01 Manual

3 security system control panel

Table of Contents

Advertisement

Quick Links

Download this manual

6LPRQ 6HFXULW\

6\VWHP &RQWURO

3DQHO

Document Number: 466-1873 BETA TEST

June 2001

Contents

System Components 1

Control Panel 1

System Devices 1

Planning Sensor Types & Locations 2

Control Locations 2

Control Panel 2

Remote Handheld Touchpad 3

Keychain Touchpad 3

Lamp, Appliance, Wallswitch, and Universal Module

House Code and Unit Numbers 3

Installing the System 4

Materials Needed 4

Mounting the Panel 4

Hardwire Interior Sirens 4

Hardwire Exterior Siren 5

Hardwire Sensors 5

Universal Module 5

Power Transformer 5

Backup Battery 6

Phone Line Connections 6

Full Line Seizure with an RJ-31X 6

Full Line Seizure with an RJ-11 6

Sensor Installation 6

Closing the Cover 7

Reset Memory to the Factory Defaults 8

Set the Clock 8

Adding (Learning) Sensors 8

Deleting Sensors 9

Light and Appliance Controls 9

Numbered Options 9

Option 01: Panel Piezo Beeps 10

Option 02: Panel Voice 10

Option 03: Latchkey 10

Option 04: Primary Phone Number 10

Option 05: Secondary Phone Number 10

Option 06: Downloader Phone Number 11

Option 07: Account Number 11

Option 08: Phone Lock 11

Option 09: Downloader Code 11

Option 10: Entry Delay 11

Beta Test 7/9/01

Doors &

Windows

1 / 2

Special

Doors

Motion

Chime

FIRE

Installation Instructions

Option 11: Exit Delay 11

Option 12: Phone Mod 1 12

Option 13: Phone Mod 2 12

Option 14: DTMF Dialing 12

Option 15: No Activity Time-out 12

Option 16: Auto Phone Test 12

Option 17: Dialer Delay 12

Option 18: Alarm Cancel Report 13

Option 19: RF Timeout 13

Option 20: Manual Phone Test 13

Option 21: Opening Reports 13

Option 22: Closing Reports 13

Option 23: Force Armed Report 13

Option 24: AC Power Failure Report 14

Option 25: CPU Low Battery Report 14

Option 26: Fail to Communicate 14

Option 27: Ring/Hang/Ring 14

Option 28: No Delay from Keychain Touchpad 14

Option 29: Panel Piezo Alarms 14

Option 30: Panel Panic Alarms 15

Option 31: Downloader Enable 15

Option 32: 300 Baud 15

Option 33: Audio Verification 15

Option 34: Fail to Open Report 15

Option 35: Fail to Close Report 15

Option 36: Sensor Activated Light Lockout Start

Option 37: Sensor Activated Light Lockout Stop

Option 38: Auto Arm 16

Option 39: Siren Time-out 16

Option 40: Trouble Beeps 16

Option 41: Chime Voice 16

Option 42: Speaker Level 16

Option 43: Pager Phone Number 16

Option 44: Pager Phone Mod 3 17

Option 45: Sensor Alarm Restoral Report 17

Option 46: Fire Shutdown - AVM 17

Option 47: AVM Mode 17

Option 48: Panic Talk - AVM 17

Option 49: Arming LEDs Shutdown 17

Option 50: RF Jam Detect 17

Option 51: 24 Hour Tamper 17

Option 52: Unvacated Premises 18

Option 53: Hardwire Siren Supervision 18

Option 54: Access Code Length 18

Option 55: Status Beep Volume 18

Option 56: Call Waiting 18

ITI Part No. 60-875-95R

Motion

Sensors

Status

H O M E S E C U R I T Y

Arm

Disarm

System

3 / 4

5 / 6

7 / 8

9 / 0

C O D E

Time

Sensor

On

Off

H O M E C O N T R O L

Lights

E M E R G E N C Y

POLICE

AUX

Test Weekly

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the Beta Test 7/9/01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Simon Beta Test 7/9/01

Page 1: Table Of Contents
Beta Test 7/9/01 ITI Part No. 60-875-95R 6LPRQ 6HFXULW\ 6\VWHP &RQWURO 3DQHO Doors & Motion Windows Sensors Status H O M E S E C U R I T Y Disarm System 1 / 2 3 / 4 5 / 6...
Page 2 Beta Test 7/9/01 Appendix C: Planning Tables 35 Option 57: Supervisory/Tamper Report 18 Option 58: Remote Touchpad Arming 18 Option 60: Secure Arming 19 Option 61: Demo Mode 19 Option 62: Supervisory Protest 19 Option 63: 24 Hour Time 19...
Page 3 Beta Test 7/9/01 FCC Notices FCC Part 15 Information to the User Changes or modifications not expressly approved by Interlogix Inc. can void the user’s authority to operate the equipment. FCC Part 15 Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against interference in a residential installation.
Page 4 Canada Notice The Canadian Department of Communications label identifies certified equipment. This certification means that the equipment meets certain telecommuni- cations network protective, operational, and safety requirements. The department does not guarantee the equipment will operate to the user’s satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company.
Page 5: Introduction
Beta Test 7/9/01 Introduction Introduction User Interface The system is easy to install if you plan ahead and perform When the panel cover is closed, the panel buttons operate the installation in the following order: the security system. When the panel cover is open, the but- tons program the security system.
Page 6: Planning Sensor Types & Locations
Beta Test 7/9/01 Planning Sensor Types & Locations ® Interrogator 200 Audio Verification Module (60-677)* temperature rises to 50°F, the sensor transmits a restore sig- nal to the panel. The Audio Verification Module (AVM) gives the central station operator the ability to hear what’s happening at the...
Page 7: Remote Handheld Touchpad
Beta Test 7/9/01 Planning Sensor Types & Locations Remote Handheld Touchpad Note If you are using a Universal Module to operate a garage Locate Remote Handheld Touchpads where they will be door, make sure to assign a unique unit number to this convenient and offer quick access to the user.
Page 8: Installing The System
Beta Test 7/9/01 Installing the System Installing the System Materials Needed Pencil Use the following procedure to mount the panel to the wall or wall studs, using the supplied mounting hardware and the Hammer panel mounting holes. Screwdriver Pry Down...
Page 9: Hardwire Exterior Siren
Beta Test 7/9/01 Installing the System Hardwire Exterior Siren The Hardwire Exterior Siren (13-046) may be used with this panel. Normally Normally Closed Turn option 53 on for siren supervision. When option 53 is Closed on and a hardwire exterior siren is not connected, a 47k ohm...
Page 10: Backup Battery
Beta Test 7/9/01 Installing the System Backup Battery Phone Line Connections The rechargeable battery will be fully charged nine hours after you plug in the transformer. If you check system status Full Line Seizure with an RJ-31X while the battery is charging, the system may report a low battery.
Page 11: Programming
Beta Test 7/9/01 Programming Programming Closing the Cover If you need more time before proceeding with program- This panel was designed to be easy to use and program. ming, simply close the panel cover until you are ready to These instructions tell you how to set up for programming continue.
Page 12: Reset Memory To The Factory Defaults
Beta Test 7/9/01 Programming Reset Memory to the Factory Defaults Device Programming If it becomes necessary to set ALL programming back to Device To Program the factory defaults, do the following: Door/Window Sensor Press button on top of sensor Open the panel cover and enter Utility Access code 1.
Page 13: Deleting Sensors
Beta Test 7/9/01 Programming Deleting Sensors To add a time-activated module: Add . Press To delete sensors: Press Light Control. Press Delete . The panel announces “Select from Main Press Unit # until you hear the unit number that matches Menu.”...
Page 14: Option 01: Panel Piezo Beeps
Beta Test 7/9/01 Programming Option 01: Panel Piezo Beeps (Default = On) Option 02: Panel Voice (Default = On) Determines whether the panel piezo produces beeps based Determines whether the panel announces all status, alarm, on system activity (on) or is silent (off). Table X “Panel and program mode messages (on), or only when SYSTEM Piezo Beeps”...
Page 15: Option 06: Downloader Phone Number
Beta Test 7/9/01 Programming To set Secondary Phone Number, press: Option 09: Downloader Code (Default = 12345) Add—Option #—05—Up to 26 digits—DONE. Lets you set a unique 5-digit code that is required for initiat- ing ToolBox sessions (on) or sets the code to its default Note (off).
Page 16: Option 12: Phone Mod 1
Beta Test 7/9/01 Programming Option 12: Phone Mod 1 (Default = 0) To set Phone Mod 2, press: Determines the primary phone number (Option 4) report Add—Option #—13—0, 1, 2, or 3—DONE. content and reporting format. To reset Phone Mod 2 (return to default), press: Note Delete—Option #—13—DONE.
Page 17: Option 18: Alarm Cancel Report
Beta Test 7/9/01 Programming Note To turn on Manual Phone Test, press: Regardless of this option setting, the panel always dials Add—Option #—20—DONE. immediately for alarms from sensors in groups 0-8, 26, and for alarms triggered by the control panel or remote To turn off Manual Phone Test, press: handheld touchpad emergency buttons.
Page 18: Option 24: Ac Power Failure Report
Beta Test 7/9/01 Programming Option 24: AC Power Failure Report (Default = off) The following table shows the available settings. Determines whether the panel sends AC power failure reports to a central station or pager after the programmed Ring/Hang/Ring Settings time expires (on), or not (off).
Page 19: Option 30: Panel Panic Alarms
Beta Test 7/9/01 Programming Option 30: Panel Panic Alarms Option 35: Fail to Close Report (Default = off) Determines whether the panel panic buttons (police, auxil- Determines whether the panel sends a Fail to Close report to iary, and fire) activate alarms when pressed (on), or not a central station or pager if the system has not been armed (off).
Page 20: Option 38: Auto Arm
Beta Test 7/9/01 Programming Option 38: Auto Arm (Default = off) Trouble beeps can be silenced by arming or disarming the system, or by pressing the STATUS button. Trouble beeps Determines whether the panel automatically bypasses pro- resume 4 hours later if the trouble condition is not cleared.
Page 21: Option 44: Pager Phone Mod 3
Beta Test 7/9/01 Programming Option 44: Pager Phone Mod 3 (Default = 09) To turn on AVM Mode, press: Determines the pager phone number (Option 43) report Add—Option #—47—DONE. content and reporting format. The following table describes the choices. All entries must be 2 digits.
Page 22: Option 52: Unvacated Premises
Beta Test 7/9/01 Programming Option 52: Unvacated Premises (Default = on) To set Status Beep Volume, press: Determines whether the system automatically arms down to Add—Option #—52—DONE. level 2 (ARM Doors & Windows) if the user arms the sys- tem to a higher level without leaving the premises (on), or To reset Status Beep Volume (return to default), press: remains at the armed level chosen by the user (off).
Page 23: Option 60: Secure Arming
Beta Test 7/9/01 Programming Note (Default = off) For UL listed systems, Exit Extension must be off. Determines whether the system prevents users from arming if a low CPU battery trouble condition exists (on) or not To turn on Exit Extension, press: (off).
Page 24: Option 69: Sia Limits
Beta Test 7/9/01 Programming Option 68: Swinger Shutdown Option 71: Programming Report (Default = off) Determines whether the panel sends a report to the central Determines whether the panel prevents the same sensor station anytime the programming mode is entered or exited from activating an alarm more than once in a single arming (on) or not at all (off).
Page 25: Option 76: Vox Gain Range
Beta Test 7/9/01 Programming To set VOX Receiver Gain, press: For panels with a built-in microphone, a setting of 16 is rec- ommended. For systems using the Interrogator 200, a set- Add—Option #—78—1 - 10—DONE. ting of 4 should be used.
Page 26: Testing The System
Beta Test 7/9/01 Testing the System The panel says, code name is deleted. learned as type 25, this function will not be available. The control panel will also announce which sensor was tripped if chime voice (option 41) is on.
Page 27 Beta Test 7/9/01 Testing the System Note Sensor Tripping Instructions If a sensor does not meet the minimum transmission beep requirements, refer to the “If a Sensor Fails the Sensor Do This Sensor Test” section of this manual. Door/Window Open the secured door or window Freeze Apply ice to the sensor.
Page 28: Phone Communication
Beta Test 7/9/01 Testing the System If a sensor fails the sensor test If the test is unsuccessful, the SYSTEM STATUS button will light and the panel will say Phone communication fail- If sirens do not beep when a sensor is tripped, use an ITI RF ure within 10 minutes.
Page 29: Central Station Communication
Beta Test 7/9/01 Testing the System Pager Communication Control Panel Phone Command Use the following table to determine what the numeric mes- Function sage is reporting. DISARM * + CODE + 1 Pager Reporting Message ARM Doors/ * + CODE + 2...
Page 30: X-10 Lamp Modules
Beta Test 7/9/01 Emergency Planning Alarm Siren and X-10 Light Information Fire Intrusion Emergency Audio Verification Set X-10 Lights Steady Flashing Steady Phone Function Button(s) X-10 Siren Steady Steady Alarm beeps Speak Interior & Temporal Steady Fast on/off Panel Siren...
Page 31: Specifications
Beta Test 7/9/01 Specifications Specifications Power Requirements: ..9 VAC, 700 mA Rechargeable Batteries: 6.0 VDC, 1.2 Ah Lead-Acid The battery will last 24 hours with no AC 6.0 VDC 3.2 Ah Lead-Acid. The battery will last 60 hours with no AC (Euro version only) Radio Frequency: ....319.5 MHz + or - 140 kHz...
Page 32: Appendix A: Troubleshooting
Beta Test 7/9/01 Appendix A: Troubleshooting Appendix A: Troubleshooting Use the following table to aid you with troubleshooting problems during installation. Troubleshooting Guide Problem Solution System Status How to clear SYSTEM STATUS (Alarm Memory) From a disarmed state press SYSTEM STATUS, listen to the status message, then press DISARM.
Page 33 Beta Test 7/9/01 Appendix A: Troubleshooting Troubleshooting Guide Problem Solution Motion sensor does not respond to motion. Make sure the sensor battery is fresh and installed correctly. Wait 2 minutes after installing a new battery to test the sensor. Adjust the sensor mounting.
Page 34: Appendix B: Options
Appendix B: Options Programmable Options Function Default Delete Range Who Can Installer Change: Settings Panel Piezo Beeps On/Off U1 U2 M (must be added for UL listed systems) Panel Voice On/Off U1 U2 M Latchkey Option 12:00 Midnight - U1 U2 M 11:59 PM Primary Phone Number None...
Page 35 Programmable Options Function Default Delete Range Who Can Installer Change: Settings 300 Baud Central Station Communications 110 Baud On/Off U1 U2 Audio Verification On/Off U1 U2 Fail to Open 12:00 Midnight - U1 U2 11:59 PM Fail to Close 12:00 Midnight - U1 U2 11:59 PM Sensor Activated Light Lockout Start Time...
Page 36 Programmable Options Function Default Delete Range Who Can Installer Change: Settings Line Cut Detection 02-48 (10-240 sec in 5 U1 U2 sec intervals)/Off Programming Report On/Off U1 U2 Modem Sensitivity On (high)/Off (normal) (normal) Panel Police Panic Audio On (silent)/Off (audible (audible) VOX Mic Gain...
Page 37 Sensor Group Characteristics Active Name/Application Siren Type Levels 00 Fixed Panic: 24 hour audible fixed emergency button Intrusion 1234 01 Portable Panic: 24 hour audible portable emergency buttons Intrusion 1234 02 Fixed Panic: 24 hour silent fixed emergency buttons. Status light will not blink. Silent 01234 03 Portable Panic: 24 hour silent portable emergency buttons.
Page 38 Home Control Planning Table* Module Activated by Time Activated Unit # Type Location Sensor Entry/Exit Start Time Stop Time Example Lamp Hall lamp Motion 8 p.m. 10:30 p.m. System Access Codes Type Default Installer Settings Utility Access Code 1 654321, 54321, 4321, or Utility Access Code 2...
Page 39: Appendix C: Planning Tables
Phone Comm.Module Module System Panic Attic Closet Medicine Cabinet Hallway Downstairs Window Downstairs Upstairs Window Upstairs Basement Window Basement Special Chime Garage Den Window Office Window Office Patio Door Porch Window Porch Kitchen Window Kitchen Laundry Room Bathroom Dining Room Living Room Utility Room Child’s Room...
Page 40 Quick Reference Table Remote Handheld Remote How to ... Control Panel Touchpad Keychain Phone Touchpad Control Arm the system Press + Master Code + 2 Doors & Doors & - Doors & Windows Windows Windows Arm the System Press + Master Motion Code + 3 Motion...
