INSTALLATION MANUAL
Level of Difficulty
Easy
Parts List
Item Qty Description
1
1
Safety chain assembly
2
2
Safety-chain loop
3
1
Rail pin, 1/2"
4
1
Rail pin clip
5
1
Hex bolt, 1/2"
6
1
Nylock nut, 1/2"
Tools Required
Torque wrench
Socket, 3/4"
Wrench, 3/4"
--
Torque Specifications
1/2" bolt
65 ft-lbs.
Use above torque setting unless otherwise noted
Product Registration
CURT Group stands behind our products
with industry-leading warranties. Provide
feedback and help us to improve our
products by registering your purchase at:
warranty.curtgroup.com/surveys
Maintenance
Inspect the unit for proper operation, and
worn, damaged or missing parts. Replace
as required or when the unit's wear
exceeds 1/8" from the original surface.
Check the hardware torque specification
after the first 200 miles of towing
and every 400 miles after that.
CURTMFG.COM
•
PRODUCT SUPPORT: 877.287.8634
Do not modify this product in any way. Unauthorized modification may impair the
function and / or safety and could affect the life of the product and void the warranty.
Keep safety chains in place and in working order.
Product Photo
CAUTION
Check for damaged parts before each use. Carefully check that the product
will operate properly and perform its intended function. Replace damaged
or worn parts immediately. Never operate the product with a damaged part.
NOTICE
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
To help prevent damage to the product or vehicle, refer to the specified
torque specifications when securing hardware during the installation process.
•
16612-INS-RA
•
12/20/2022
•
ECN10120
•
PAGE 1
16612
