- Page 1 ED100 Intelligent Automatic Flat Door system...
-
Page 2: Table Of Contents
Catalog 1. Technical parameter 2. Description of accessories 3. Mechanical installation 3 - 9 3.1 Installation example 3.2 Baseboard installation 4 - 5 3.3 Arm installation 3.4 Push arm installation 7 - 8 3.5 Driver system installation 3.6 Hood installation 3.7 Connection of drive system and pull arm 3.8 Driver system and push arm connection 4. -
Page 3: Technical Parameter
Technical parameter Power supply: 200V~240V Opening time: 3~7s/90° Opening and holding time: 1~30s Temperature: -20°C~55°C Protection level: IP12D Product weight: 6.5Kg Product volume: 515x95x90mm 2000 mm = Door width kg = Door weight 1200 1000 Optimum scope Limit range... -
Page 4: Description Of Accessories
Description of accessories Power cord hole Sensor equilibrium hole Floor Hood Power Connection Seat Motor Microcomputer Controller Driving Device Output shaft Transformer Pull arm (and push arm choose one) Push arm (choose one from pull arm) -
Page 5: Mechanical Installation
Mechanical installation 3.1 Installation example Pull- arm mounting: Suitable for door wing opening inward (drive system inside) Push Arm Installation: Suitable for door wing opening outward (drive system inside) -
Page 6: Baseboard Installation
Mechanical installation 3.2 Baseboard installation Pull-arm mounting φ20Sensor Line Equivalent Entry Power Supply Line Equivalent Entry φ20Sensor Line Equivalent Entry Power Supply Line Equivalent Entry The floor is fastened to the door frame with eight countersunk wood screws according to the size shown (for steel structure, M6*15 inner hexagonal countersunk head bolts) The floor is fastened to the door... -
Page 7: Arm Installation
Mechanical installation 3.2 Baseboard installation Push Arm Installation φ20Sensor Line Equivalent Entry Power Supply Line Equivalent Entry φ20Sensor Line Equivalent Entry Power Supply Line Equivalent Entry The floor is fastened to the door frame with eight countersunk wood screws according to the size shown (for steel structure, M6*15 inner The floor is fastened to the door hexagonal countersunk head bolts) - Page 8 Mechanical installation 3.3 Pull-arm mounting The fixed seat of the pull arm is fastened to the door wing as shown. Move the limit block to adjust the opening angle (the left time limit block is on the left side) Installation on the right side of automatic door...
-
Page 9: Push Arm Installation
Mechanical installation 3.4 Push Arm Installation The push arm fixing seat is fastened to the door wing with two round head wood screws according to the size shown (for steel doors, M6*15 cross head screw is used). According to the different depth L of the door frame, the length of the push arm can be Installation on the right adjusted by loosening three clamping bolts,... - Page 10 Mechanical installation 3.4 Push Arm Installation Limited block Adjust limit block to graphic position in U-shaped hole...
-
Page 11: Driver System Installation
Mechanical installation 3.5 Driver system installation Hood installation Install the drive system as shown in the illustration on the installed base plate，with eight hexagon socket heads screwed How the hood is opened... -
Page 12: Connection Of Drive System And Pull Arm
Mechanical installation 3.7 Drive system and pull arm connection 3.8 Drive system and push arm connection Drive shaft extension... -
Page 13: Electrical Connection
Electrical connections Transformer 18V Controller Insurance tube 3A Motor eight core wire Controller Power cord connection Motor, transformer connection External power cord 220V When the factory is shipped, the transformer two- core cable, the motor eight-core cable and the controller are connected. Remote learning button Electric lock + Sensor power supply... - Page 14 Electrical connections Double door synchronization Double door synchronization (in) Double door synchronization (in) Double door synchronization (out) Double door synchronization (out) door A controller door B controller In the double - opening door, the first opening and the second closing are set as the active ones, and the rear opening is first set as the driven door, the active door K2 is set, and the driven door K2 is placed.
-
Page 15: Parameter Adjustment
Parameter adjustment Remote learning button Electric lock + Sensor power supply K1 Opening direction selection Opening speed Emergency power supply + Sensor power supply K2 Master driven door selection Door opening angle Sensor signal K3 Choose PUSH arm or PULL arm Closing speed Sensor signal Double door interlock (in) - Page 16 Parameter adjustment remote control Remote learning button Electric lock + Sensor power supply Controller and controller pair code description K1 Opening direction selection Opening speed Sensor power supply Emergency power supply + K2 Master driven door selection Door opening angle Sensor signal K3 Choose PUSH arm or PULL arm Closing speed...
-
Page 17: Quality Assurance Certificate / Qualification Certificate
Product Quality Assurance / Certificate 1. Under normal conditions of use, due to defects in the manufacture of the product itself, free after- sales service can be obtained during the quality assurance period. 2. if there is a problem, please contact our company. Certificate 3.
