ASSEMBLY INSTRUCTIONS
HUSK LOUNGE
3 SEATER
MODEL: MR-2752
Husk 3 Seater Lounge
The components are heavy, assembly should be performed by two people.
If you have any di culty with assembly or operation, please contact the store of purchase in the fi rst instance.
Please read the below safety & electrical instructions before operating

Safety Instructions

• This product is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the product by a person responsible
for their safety.
• Ensure there is no person, animal or item obstructing the area under
the footrest before operating this product.
• Improper use or installation may result in the risk of fi re, electric shock
and/or injury. We assume no liability for any eventual damages caused
by improper use or inappropriate handling, or by any other non-com-
pliance with the instructions in this manual.
• Children should be supervised to ensure that they do not play with
the product.
• This product contains moving parts. Keep fi ngers, hair and body
parts well clear from moving parts. To reduce the risk of injury, keep
children and pets clear of the product when in use.

Electrical Instructions

• Never force the back or footrest to close faster than the electric motor.
• Before commencing cleaning or maintenance, ensure this product is
disconnected from the power outlet and the back is in the full upright
position.
• Disconnect this product from the power outlet before moving.
• Cease operation and disconnect from the power outlet if you ever
detect a burning odour or smoke coming from the product.
• Do not operate this product if liquid spillage occurs on or around it.
Disconnect from the power outlet and allow product to completely dry
before reconnecting.
Synargy is a registered responsible supplier on ERAC. Electrical components within our products have been tested to comply with legal
requirements imposed for electrical safety and EMC.
• Do not sit or place additional weight on the arms, back or open
footrest.
• This product is very heavy. Only move this product by lifting the main
body. Never drag by the footrest, back or arm rest.
• Return this product to the full upright position to stand safely and
prevent a tripping hazard.
• Do not operate this product if damage is visible in any form.
• Do not modify or use unauthorised substitute parts.
• This product has been designed and intended for indoor residential
use only. It is not suitable for commercial or outdoor use.
• This product is not intended to be used as part of a health care plan.
Consult your medical professional before operating if you are taking
medication or have physical limitations.
• Do not operate the power functions or charge station with wet
hands.
• Check the condition of the power cord, electrical cords, transformer,
plug and connector on a monthly basis. Do not operate if wear is
visible.
• Ensure the power cord, electrical cords and transformer are clear of
moving parts and not trapped underneath the base.
• Position the power cord to minimise a tripping hazard.
• Never attempt to open or disassemble electrical components.
• We recommend the use of a surge protector (not included).
A
1 x Seat Base
B
1 x LAF Armrest
D
1 x LAF Back
E
1 x Center Back
G
1 x LAF Wing
H
1 x RAF Wing
1 x USB
J
Power
Supply
Remove all packaging and set aside in a safe location before disposal or recycling of applicable materials.
On the underside of the sofa there is a package containing the power supply - cut the ties to remove the
packaging and set the power supply aside. Remove the timber support rails from the seat base using the
provided tool.
Identify the armrests for the LAF side
(B)
and the RAF side
(A)
by the attached zippers
B
Visit us online for product care, information and warranty details:
C
1 x RAF Armrest
F
1 x RAF Back
I
1 x Power Supply
(C)
Connect these to the ends of the seat base
C
A
www.synargy.com
SynargyFurniture
