USER MANUAL
EVOLVE2
55
Technology for life's new rhythm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVOLVE2 55 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jabra EVOLVE2 55

Summary of Contents for Jabra EVOLVE2 55

  • Page 1 USER MANUAL EVOLVE2 Technology for life’s new rhythm...
  • Page 2 ® © 2023 GN Audio A /S. All rights reserved. Jabra is a ® trademark of GN Audio A/S. The Bluetooth word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by GN Audio A/S is under license.
  • Page 3 1. Welcome .........5 2. Jabra Evolve2 55 overview ..6 2.1 Included accessories 2.2 Optional accessories 3. How to wear ........9 3.1 Wearing styles 3.2 Headset adjustment 3.3 Foldable earcups 4. How to charge ......12 4.1 Charge using the charging cable 4.2 Charge using the charging stand (optional...
  • Page 4 7.10 Sidetone 7.11 Factory reset 8. Software and firmware .... 29 8.1 Jabra Sound+ 8.2 Jabra Direct 8.3 Update firmware 9. Support ........31 9.1 FAQ 9.2 How to care for your headset 9.3 How to clean your Jabra device...
  • Page 5 1. Welcome Thank you for using the Jabra Evolve2 55. We hope you will enjoy it! Jabra Evolve2 55 features • Best-in-class comfort* with Jabra AirComfort technology • Silence your surroundings with Active Noise Cancellation (ANC) • Work-anywhere professionalism, with noise-cancelling microphone technology •...
  • Page 6 2. Jabra Evolve2 55 overview Left Right Microphone ANC on/off Volume up Voice assistant Skip track (hold 1 sec) Play/pause music Mute microphone Busylight/ Volume down Status LED Previous track (hold 1 sec) Power on/off (hold 2 sec) Bluetooth pairing (hold 4 sec)

  • Page 7: Included Accessories

    2.1 Included accessories USB-A version Jabra Link 380 USB-A USB-A to USB-C Bluetooth adapter* charging cable USB-C version Jabra Link 380 USB-C USB-C to USB-C Bluetooth adapter* charging cable Carry pouch *Bluetooth adapter is in the carry pouch...

  • Page 8: Optional Accessories

    2.2 Optional accessories Optional accessories available jabra.com/accessories USB-C port Charging stand Replacement ear cushions...

  • Page 9: How To Wear

    3. How to wear 3.1 Wearing styles Mono variant Stereo variant...

  • Page 10: Headset Adjustment

    3.2 Headset adjustment Headband Adjust the headband so that the headset fits your head comfortably. Stereo variant Mono variant Boom arm It is important to position the microphone close to your mouth. The boom arm can be bent for better positioning. Max.7cm +/- 3cm...
  • Page 11 3.3 Foldable earcups The earcups can be folded flat for easy storage.

  • Page 12: How To Charge

    4. How to charge The headset can be charged using the optional charging stand, or via a charging cable plugged directly into the headset. It takes approx. 2 hours to fully charge. When fully charged, the battery life is up to 18 hours. If out of battery, charging the headset for 30 minutes will give the headset up to 9 hours of battery life.
  • Page 13 USB port on your computer. It is recommended to charge the headset using the supplied Jabra charging cable; however, it is possible to use a compatible charger. Right earcup...
  • Page 14 4.2 Charge using the charging stand (optional accessory) Connect the charging stand to a powered USB port on your computer using the supplied charging cable, and then dock the headset in the charging stand. Alternatively, the charging stand can be plugged into any powered USB power supply.
  • Page 15 4 hours to conserve battery. To exit sleep mode, press any button. The length of time before the headset enters sleep mode can be adjusted using the Jabra Sound+ app on your smartphone or Jabra Direct on your computer.

  • Page 16: What The Leds Mean

    5. What the LEDs mean Power on Power off Battery full Battery medium Battery low Battery critically low Pairing mode Resetting/Firmware updating BUSYLIGHT/STATUS LED Busylight Active call Incoming call Muted (slow flash) Headset is Plugged into computer trying to connect to and signed into Microsoft Teams.

  • Page 17: How To Connect

    To hear music in the headset you may need to select the Jabra Link 380 as the playback device in your operating system’s audio settings. To manually pair the Jabra Evolve2 55 with the Jabra Link 380, download and use Jabra Direct.

  • Page 18: Pair With A Bluetooth Device

    6.2 Pair with a Bluetooth device 1. Press and hold the Power button (4 sec) until the LED flashes blue. 2. Follow the voice-guided instructions to pair your Bluetooth device. To complete the pairing, you may be asked to confirm a passcode that will be displayed on your phone and announced in your headset.

  • Page 19: How To Use

    7. How to use Left Right ANC button Volume up button Play/pause button Volume down button Power button Call button 7.1 Power on/off Hold the Power button for 2 seconds to power the headset on/off.
  • Page 20 7.2 Calls & music Right Calls & music Press the Call button Alternatively, move the Answer call microphone down to answer a call End call Press the Call button Double-press the Reject call Call button Bring Microsoft Press the Call button* Teams to (when signed into foreground on...
  • Page 21 Press the Play/pause Play/pause music button when listening to music Mute/unmute Press the Play/pause microphone button when on a call Press the Play/pause Hear battery button when not on a status call or listening to music Press the Volume up or Volume down button, Adjust volume when listening to music...
  • Page 22 Activate voice Press and hold (1 sec) assistant (Siri, the ANC button when Google Assistant) not on a call ANC on/off Press the ANC button 7.3 Busylight(s) To indicate to colleagues that you are busy, the Busylight(s) on the headset automatically light up red when you are on a call.
  • Page 23 The headset microphone can be muted by moving the microphone boom-arm up, or unmuted by moving it down. This feature is on by default, and can be disabled using Jabra Sound+ on your smartphone or Jabra Direct on your computer.
  • Page 24 An incoming call can be answered by moving the microphone boom-arm down, close to your mouth. This feature is on by default, and can be disabled using Jabra Sound+ your smartphone or Jabra Direct on your computer. Answer call...
  • Page 25 7.7 Multiuse The headset can be paired with up to 8 Bluetooth devices, and connected to two Bluetooth devices at once (e.g. the Jabra Link 380 and a phone, or two phones). The headset can accept multiple incoming calls from either device.

  • Page 26: Multiple Call Handling

    7.8 Multiple call handling The headset can accept and handle multiple calls at the same time. Right Multiple call handling End current call and Press the Call answer incoming call button Put current call on Hold (2 secs) the hold and answer Call button* incoming call Switch between held...

  • Page 27: Voice Guidance

    Alternatively, Jabra Direct your computer, or Jabra Sound+ on your smartphone, to turn Voice guidance on or off. For the latest list of supported languages, refer to the Jabra Sound+ app on your smartphone or Jabra Direct on your computer.

  • Page 28: Factory Reset

    Sidetone enables you to better hear your own voice when you are on a call. Sidetone settings can be configured using the Jabra Sound+ app on your smartphone or Jabra Direct on your computer. 7.11 Factory reset Resetting the headset clears the list of paired devices and resets all settings.

  • Page 29: Software And Firmware

    8. Software and firmware 8.1 Jabra Sound+ Jabra Sound+ is a mobile application that allows you to update the headset to the latest firmware to add new functionalities and configure it based on your needs. 8.2 Jabra Direct Jabra Direct is a desktop application designed to support, update and manage Jabra devices to ensure their optimal performance.

  • Page 30: Update Firmware

    Using Jabra Sound+ Connect the Evolve2 55 via Bluetooth to your phone. Using Jabra Direct Connect the Evolve2 55 to a computer using the USB cable or the Jabra Link 380 Bluetooth adapter.
  • Page 31 9. Support 9.1 FAQ View the Jabra Evolve2 55 FAQ, certifications, and technical specifications at jabra.com/support 9.2 How to care for your headset • Always store the headset in the supplied case. • To prevent the depletion of the battery...
  • Page 32 9.3 How to clean your Jabra device Keep your product clean by following these best practices for hygiene. 1. Apply normal dish soap and water to a cloth, making sure you wring out excess liquid so the cloth is not dripping wet. Use soap and water only –...
