- Page 1 Installation & User Guide Fence Watch . Electric Fence Monitor...
- Page 2 Quick Start Guide. (English) Follow these steps to get your Fence Monitor working: 1) Make sure your 2G SIM card is registered with the phone network. 2) Insert the SIM card into the Fence Monitor. 3) Turn on the Monitor, place in the sun and wait for the status light to flash green (allow up to 45 minutes for the internal emergency battery to charge) 4) Once the SIM is activated, create a new contact in your mobile...
- Page 3 Guide De Démarrage Rapide. (French) Suivez ces étapes pour le bon fonctionnement de votre Moniteur de Clôture : 1) Assurez-vous que votre carte SIM 2G est connectée au réseau télé phonique. 2) Insérez la carte SIM dans le Moniteur de Clôture. 3) Allumez le Moniteur, placez-le exposé...
- Page 4 Quick Start Guide. (Spanish) Follow these steps to get your Fence Monitor working: 1) Make sure your 2G SIM card is registered with the phone network. 2) Insert the SIM card into the Fence Monitor. 3) Turn on the Monitor, place in the sun and wait for the status light to flash green (allow up to 45 minutes for the internal emergency battery to charge) 4) Once the SIM is activated, create a new contact in your mobile...
- Page 5 Quick Start Guide. (Swedish) Follow these steps to get your Fence Monitor working: 1) Make sure your 2G SIM card is registered with the phone network. 2) Insert the SIM card into the Fence Monitor. 3) Turn on the Monitor, place in the sun and wait for the status light to flash green (allow up to 45 minutes for the internal emergency battery to charge) 4) Once the SIM is activated, create a new contact in your mobile...
-
Page 6: Monitor Installation
Monitor Installation STEP 1: Charge Battery NOTE: Make sure switch is in the OFF (0) position. • The monitor has the internal battery already connected. However it is a good idea to make sure it is fully charged before use. With monitor in the OFF position, allow the sun to fully charge the battery (3 days) to ensure optimal battery life, or use an optional charger Part No:22-120. -
Page 7: Step 3: Mounting The Monitor
& facing the noontime sun (due south in the northern hemisphere) Avoid areas that might become shaded. • Fix the Fence Watch Monitor securely to a wooden post or use a mounting stand (Not supplied) part number SP50-022. - Page 8 STEP 4: Connect EARTH and FENCE Terminals Place ring end of crocodile clip over terminal. Connect GREEN/ YELLOW wire to EARTH termi- nal; connect RED wire to FENCE terminal. STEP 5: Connect Earth System Connect green crocodile clip to earth stake (part no. 18-179B) NOTE: Connect additional earth stakes with lead-out cable if required STEP 6: Connect Monitor Cable to Fence Line...
- Page 9 Ensure Your Fence System is Sound • Check all connection points such as splices, jumpers, and insulators are sound and secure • IMPROPER CONNECTION POINTS WILL AFFECT YOUR ELECTRIC FENCE PERFORMANCE. • Install the Fence Monitor at the furthest point from the energiser. Commands Commands must follow this format.
- Page 10 REG Command. To pair up or register a sending mobile phone with the Fence Monitor, text REG to the phone number of the Fence Monitor SIM card. Only commands from the registered phone will be acted upon by the Fence Monitor. If REG is sent to the Fence Monitor from a different phone number, this will replace the existing registered phone (see also PIN command for extra security).
- Page 11 NOP Command. Removes the PIN number if one has been set. Text: NOP^xxxx where xxxx is the current PIN. Note 1: The current PIN number must match the one stored. STA Command. Request a status report from the Fence Monitor. Text: STA Note 1: A PIN number is not required for this command Note 2: There is no alternative response to this command (if the com-...
- Page 12 BLS Command. When using a Pay-As-You-Go SIM you can include in the status mes- sages the remaining credit balance available on the account. This can be achieved when you first activate the SIM. To check the code Insert the sim into a mobile phone and enter the special sequence of charac- ters using the keypad.
- Page 13 TLO Command. Sets the LOW temperature warning message. e.g. Sending the command: TLO^+10 will send an alert if the tempera- ture drops below 10 Text: TLO^xxxx^+10 where xxxx is the current PIN. Note 1: The Fence Monitor temperature range is -15 + 50 UNI FAH or CEL Command.
- Page 14 Incorrect PIN “PIN error” A PIN was required but either not entered or entered incorrectly. Warnings: (1) Mobile phone network issues can delay sent/received messages. (2) Isolate the Fence Monitor from the fence before handling it or mak- ing connections to it. Electric Fence Monitoring.
-
Page 15: Battery Maintenance
Battery Maintenance Battery Maintenance • A low battery can be recharged by removing the battery and using a 6-volt charger (part no. 22-120). • When not in use, fully charge the battery before storage. Warning: Do not charge the solar powered electric fence Monitor battery with an automobile battery charger as this will damage the battery. - Page 16 GSM status Indicator. No light : The Monitor function is not working (possibly because the internal emergency supply is still charging). Wait up to 45 minutes for it to fully charge. Red flashing: The Fence Monitor is initializing. This may take several minutes.
- Page 17 Fence Line Maintenance/Testing Fence Line Maintenance • Regularly test voltage at the furthest point on the fence line from the energiser – we recommend Rutland digital tester 14-172 or 8-light tester 14-173 • Routinely check all fence and How To Test Fence...
-
Page 18: Standard Warranty
EC, 92/59EEC, 2006-95-EC, 2001/95/EC. EN60335, EN60335-2-76, EN55014, EN301489, EN60950-1, EN301511. The technical documentation as required by the Conformity Assessment procedure is kept at the following address: Company: Woodstream Europe Ltd Address: 8 Lands End Way Oakham Rutland LE15 6RF. UK - 18 -... -
Page 19: Warranty Terms And Conditions
Rutland Electric Fencing Co. Ltd. makes no other expressed or implied warranty of fitness or merchantability or any other expressed or implied warranty. IN NO CASE SHALL WODSTREAM EUROPE LTD., OR THE SELLER, BE LIABLE FOR CONSEQUENTIAL, SPECIAL OR INDIRECT DAM-... - Page 20 To request a Rutland Electric Fencing Co Ltd. catalogue or for information on any Rutland product, please contact us at: Woodstream Europe Ltd. Fencing House 8 Lands End Way Oakham, Rutland LE15 6RF UK Web: www.Rutland-Electric-Fencing.co.uk Email: Enquiries@woodstream.com Phone: +44 (0) 1572 722558 – UK and EU +44 (0) 1356 624109 –...
