3
INSERT SCREW THROUGH HOLE (
OF CLEANER (
diagram
THROUGH BACK PANEL AND TIGHTEN TO SECURE HANDLE (
YOUR DIRT DEVIL
IS READY
TO CLEAN!
4
located under tool caddy
3). PLACE BOLT ONTO END OF SCREW COMING
NEED HELP?
If you need further assistance, please contact
Refurb Product Support via the website at
www.RefurbProductSupport.com. Support agents
are available Monday through Friday from 8am to
4pm EST. Always identify your vacuum by the
complete model number when requesting
information. The model number appears on the
bottom of the vacuum.
FRONT
) ON BACK
4).
diagram
