Wireless Presentation System
User's Manual
Version: 1.0
Date: 2008.1.11
User's Manual │ 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TX778W and is the answer not in the manual?

Questions and answers

Related Manuals for Optoma TX778W

Summary of Contents for Optoma TX778W

  • Page 1 Wireless Presentation System User’s Manual Version: 1.0 Date: 2008.1.11 User’s Manual │ 1...

  • Page 2: Table Of Contents

    Table of Contents Overview ... 3 First Setup of the Wireless Presentation System ... 4 Client Utility ... 9 Description of Wireless Projector Application ... 9 Start/Stop Presentation ... 11 Start/Stop Playing Video... 11 Administrator Page ..12 Searching for a Server... 13 Repeat ...

  • Page 3: Overview

    The Wireless Presentation System is compatible with all types of projectors. After downloading the software, the projector wireless system will instantly display your presentation on the screen via the projector with just one click of the mouse.

  • Page 4: First Setup Of The Wireless Presentation System

    Supports static-IP and DHCP servers. 2. First Setup of the Wireless Presentation System 1) Connect the wireless module to the projector, and ensure that the connection is fitted tightly. 2) Ensure the wireless module LED light is green Ensure the WLAN card/internal wireless chipset of your personal computer is enabled.
  • Page 5 Select and connect to the “Wireless Projector” network. If “Wireless Projector” is not seen, ensure that the PC is within near range (Up to 300 feet / 100 meter, depend on environment) of the projector and the module is selected to be active. If disconnected, please click “View Wireless Networks”...
  • Page 6 4) Open your web browser to go to Optoma home page. The default IP address of the Wireless Projector system is 192.168.100.10, which is also shown on the bottom left corner of projected screen.
  • Page 7 5) Click the download button on the panel located on the left side of the webpage. This will take you to a second page that prompts you for a password. Click the download button to continue. Please note: no password is needed for ‘user’ login. User’s Manual │...
  • Page 8 6) When the ‘File Download’ appears below, click “Run” to execute the installation program. After installing the program, the Wireless Projector shortcut will appear on the PC desktop. Note: To ensure proper installation, make sure the personal firewall on the PC does not block the software.

  • Page 9: Client Utility

    3.1 Description of Wireless Projector Application 1) After successfully logging in, the user interface application of the Wireless Projector system appears (see below): 2) The features of the various buttons of the wireless projector application are listed below. Presentation Mode...
  • Page 10 Stop projecting Start Playing Video Pause Playing video Audio volume ON. Audio volume strength bar Server Login Code This icon will blink when wireless data/video is playing This icon will blink when wireless data/video is playing Function menu Minimize the program Exit the program Note: For security, the Server Login Code randomly changes as users log in and out of the presentations as the default.

  • Page 11: Start/Stop Presentation

    3.2 Start/ Stop Presentation Click to start wireless presentation. Click to stop wireless presentation. Click to pause presentation that will hide any activities of your PC screen. Once you click “Play” button again, screen projection will be resumed. 3.3 Start/ Stop Playing Video Supported Video Formats: MPG 1/2, Divx 3/4/5, XviD(MPEG4) Click to switch to Video Mode.

  • Page 12: Administrator Page

    3.4 Administrator Page Click to open the function menu and select “Web Admin” to access the management webpage. The functions of this webpage will be described on next chapter. User’s Manual │ 12...

  • Page 13: Searching For A Server

    3.5 Searching for a server Click “Search Server” to search for wireless projector again. User’s Manual │ 13...

  • Page 14: Repeat

    3.6 Repeat Click “Repeat” to enable/disable video repeat capability. 3.7 System Information Click “Info” to show the system information, which will include the product model number, IP address and Login Code. User’s Manual │ 14...

  • Page 15: About

    3.8 About 3.9 Exit Program Click to exit this program. User’s Manual │ 15...

  • Page 16: Web Management

    4. Web Management 4.1 Home page 1. Ensure the projector is switched on, and that the personal computer (PC) / notebook has connected successfully to the wireless projector WLAN network (as described in Section 2) 2. Open your web browser, ensure “Wireless projector” is connected and it will automatically take you to the wireless projector home page 3.

  • Page 17: Download Software

    4.2 Download Software 1. Press “Download” button to download the software, leave the password box blank. 2. You can either save the file first to implement later or execute this program immediately. User’s Manual │ 17...

  • Page 18: Administrator Login Page

    3. Follow the Installation Wizard instructions until the installation process is completed. 4. The “Windows Security Alert” will appear if the program is blocked by a Windows’ firewall. Press “Unblock” to continue with the installation. 5. Once the installation has completed, a shortcut will appear on the desktop of your PC/ notebook.

  • Page 19: System Status

    ■ Default Gateway ■ Wireless MAC address ■ Wire MAC address Connection Status: ■ Projecting status: Will be either “Waiting to project” or “Projecting” ■ Total Users: It shows how many users login into wireless projector. User’s Manual │ 19...

  • Page 20: Network Setup

    4.5 Network Setup *** Click ‘Network Setup’ button. IP Setup: ■ You can select “obtain IP address automatically” or “Use the following IP address” ■ IP Address: The default value is 192.168.100.10. ■ Subnet Mask: The default value is 255.255.255.0 ■...

  • Page 21: Projection Setup

    ■ SSID Broadcast: You can select “Enable” or “Disable” ■ Channel: To set fixed channel or Auto. “Auto” means after powering on the wireless projector system, it will scan all wireless channels and select one clear channel automatically. ■ WEP: You can disable the WEP key or select 64-bit or 128-bit in an ASCII or HEX string.

  • Page 22: Change Passwords

    ■ Resolution: 1024x768, 1280x768 and 800x600. ■ Color Depth: provides WPS output with 16-bit or 32-bit color depth. This depends on your PC settings. ■ Screen Refresh Rate: This is VGA output refresh rate. It provides 60 Hz and 75Hz to match the different kinds of projectors. ■...

  • Page 23: Reset To Default

    4.8 Reset to Default *** Click ‘Reset to Default’ button to restore factory default settings User’s Manual │ 23...

  • Page 24: Firmware Upgrade

    ‘Reset’ button. 3. Turn on the projector. 4. Wait for 10 seconds or more, then release the ‘Reset’ button 5. This will reset the Optoma Wireless Presentation System to the default settings. 4.9 Firmware Upgrade User’s Manual │ 24...
  • Page 25 9. Upon the completion of the firmware upgrade, manually power off the projector and power on again. Warming: Do not power off wireless module while the firmware upgrade is in progress. This will cause the wireless projector to fail. User’s Manual │ 25...

  • Page 26: Reboot System

    4.10 Reboot System *** Click ‘Reboot System’ button to restart the system ■ Reboot: Restarts the system automatically. 4.11 Logout *** Click ‘Logout’ button to return back to the Web homepage. User’s Manual │ 26...
