- Page 1 LIGHTBAR GUIDE Bullitt Basic...
-
Page 2: Table Of Contents
Contents Lightbar Mounting Methods Page Lightbar Basic Installation Page Lens Replacement Page Controller Replacement Page Functional Checks Page - 2 - M001v1.0 Revised November 2017... -
Page 3: Lightbar Mounting Methods
• Examine the Lightbar for damage such as cracked or scratched lenses. Report any damage immediately through Redtronic helpdesk or support Lightbar Mounting Methods Lightbars have several mounting options. These are detailed as follows: - Universal Footpack Part No. - Page 4 Universal Footpack & Super Strong Magnets Part No. EM108UF & EM102RFSS Fixing Style: Temporary 55-68mm elevation with adjustable angle Dekra speed tested rated to 146mph/235kph) Can be used in conjunction with a Safety Lanyard (EM173L1) Universal Footpack & Gutter Mount Part No.
- Page 5 Roof Bar Bracket Part No. EM108RBB Fixing Style: Permanent 26-56mm bar width with adjustable distance between brackets Roof Rail Clamps Part No. EM108RRC Fixing Style: Semi-Permanent - 5 - M001v1.0 Revised November 2017...
- Page 6 Universal Footpack & Suction Cups Part No. EM108UF & EM102SC Fixing Style: Temporary 55-68mm elevation with adjustable angle Should be used in conjunction with Safety Lanyard (Part No. EM173L1) NOTE: Always remove the red caps from suction prior to use – these are for storage only (suction will not work if caps are present) M6x25 UNC Cable Screw...
- Page 7 Roof Rail Bracket Part No. EM108RRB Fixing Style: Permanent - 7 - M001v1.0 Revised November 2017...
-
Page 8: Lightbar Basic Installation
Lightbar Basic Installation Standard Lightbar connectivity: - N.B. For non-standard Lightbar builds, please refer to ‘Cables’ on page 6 of the Lightbar Datasheet or to the drawing - 8 - M001v1.0 Revised November 2017... - Page 9 Single Colour Lightbar Size Lightbar Style No. of Controllers No of LEDs Max Current (12v) 55cm Bullitt Basic BS1 EM312 EBS x1 2.5A Bullitt Basic BS1 EM312 EBS x1 2.5A 71cm 88cm...
- Page 10 Flash Pattern: - If the flash patterns are not co-ordinated, i.e. certain banks of LED’s are on different patterns, you will need to reset all the controllers to their original flash pattern If you do not have a pattern select switch installed, apply the brown wire from the Bullitt cable to the positive (+VE) supply on the battery for 2 seconds to reset all controllers to flash pattern 1 If a pattern select switch (momentary) is installed, simply hold the switch down for 2 seconds Sync;...
-
Page 11: Lens Replacement
It may be necessary to remove the top lens if the serial number is not clearly visible (see step 3.5 for instructions). Redtronic holds a full description of your Lightbar, enabling our support team to provide you with the part number relating to a specific... - Page 12 Lightbar It may be necessary to return the Lightbar to Redtronic for analysis. Damaged lenses that have been replaced must be returned to Redtronic in every instance. Please contact support@redtronic.co.uk...
- Page 13 3.5.2 Ensure that the LED modules are seated correctly, noting the supporting standoffs (highlighted below) which are designed to hold the LED module in place 3.5.3 Position the replacement top lens onto the base section of the Lightbar. Make sure the silicone seal is fitted correctly into the Base section lens 3.5.4 Ensure all LED modules are level with the seating posts in the lens top...
-
Page 14: Controller Replacement
Controller Replacement If the fault cannot be rectified contact Redtronic for assistance. You will need to provide a Redtronic support team representative with the serial number on the holographic label. This is located within the Lightbar, at one end next to the manufacturers inspection sticker or on the underside, in the centre of the lightbar. - Page 15 Diagnosing failure of LED module and / or controller The controller powers the left and right-side LED modules in the lightbar independently. If all LED modules have failed, check earth connection from lightbar to the vehicle, secondly check the in-line fuse between the lightbar cable and the power source.
- Page 16 Replacing the Controller 4.4.1 Power off the Lightbar and remove the lens directly above the controller using M6 (5mm) & M4 (3mm) hex head drill bits or drivers. Remove the M4 hex screws first, then M6 hex screws 4.4.2 Once the top lens has been removed, note down the orientation of the faulty controller 4.4.3 Remove the x4 M3.5x13 screws securing the controller to the base of the Lightbar, using a Pozi (PZ2) tool...
-
Page 17: Functional Checks
This is not a faulty shutdown reset the side controller, it has just shut down the output Check all fixings are secure before Loose contacting a Footpack Redtronic Support Team member - 17 - M001v1.0 Revised November 2017...
