Installation and Operation Instructions
ML4
Product Description
The ML4 is a petite, covert style directional and is ideal for customers wanting to avoid visible mounting
screws. The ML4 comes as standard with a highly effective adhesive (rear only) making it only necessary
to drill a single cable entry hole to install. Considering the extremely slender depth (12mm), it is a perfect
solution for applications where space is restricted, especially inside the tailgate where a slim lamp is
required. An optional extra includes a window pod for window mounting.
Part Number
EM355AC
EM335BC
EM335RC
EM335BRC
Flash Patterns
1
2
3
4
5
6
+44 (0)1422 310999
Colour
Voltage
10-30VDC
10-30VDC
10-30VDC
10-30VDC
INFO@REDTRONIC.CO.UK
Amps
400mA
400mA
400mA
400mA
Mega-Flash
Quad
Triple
Double
Single
Hyper
WWW.REDTRONIC.CO.UK
MANUFACTURED IN THE
UNITED KINGDOM
Warranty
2 years
2 years
2 years
2 years
PAGE 1
V1.1 (M025)
Advertisement
Related Manuals for Redtronic ML4
Summary of Contents for Redtronic ML4
- Page 1 Installation and Operation Instructions Product Description The ML4 is a petite, covert style directional and is ideal for customers wanting to avoid visible mounting screws. The ML4 comes as standard with a highly effective adhesive (rear only) making it only necessary to drill a single cable entry hole to install.
- Page 2 Synchronisation Yellow Wire Link to other Redtronic products Installation Connecting the ML4 directionals to a vehicle battery / power source requires the black wire to be connected to the negative (-ve) terminal, and either the red wire (V1) or the...
- Page 3 To synchronise ML4’s: yellow wires When the desired flash pattern has been set, connect the from each ML4 together, this will ensure all ML4’s flash in a synchronised format. Note: Do not apply yellow wires positive (+ve). Do not attempt to sync Redtronic products with any other manufacturer’s products.
- Page 4 Warranty disclaimer: shrouds / mounting pods are not covered under warranty. Cleaning and Maintenance Please refer to our ‘How to care for your Redtronic Polycarbonate Products” and our “shrouds and mounting pods” document. +44 (0)1422 310999 INFO@REDTRONIC.CO.UK...
