BX31
Technical Informa�on
SINGLE
Voltage Range
Max Current (12v)
Max Current (24v)
No. of LEDs
3
AMBER Lumens
BLUE Lumens
RED Lumens
WHITE Lumens
GREEN Lumens
LED power (Wa�s)
9w
Weight (gram)
Temp. Range
Approval
Installers should use
IP67 rated
cable connectors.
Failure to do so
may result in voiding the product
warranty. Please consult our
technical department for more
informa�on.
BX32
BX31
DUAL
MULTI
SINGLE
11 - 30v DC
500mA
250mA
6
9
6
686.25
476.25
648.75
1095
727.5
18w
27w
18w
59g
–40 to 105 ºC
EMC & R65
BX32
DUAL
MULTI
SINGLE
11 - 30v DC
1Amp
500mA
12
18
6
1372.5
952.5
1297.5
2190
1455
36w
54w
18w
90g
–40 to 105 ºC
EMC & R65
SINGLE, DUAL
& MULTI COLOUR
BX61
BX61
DUAL
MULTI
SINGLE
11 - 30v DC
1Amp
500mA
12
18
12
1372.5
952.5
1297.5
2190
1455
36w
54w
36w
104g
–40 to 105 ºC
EMC & R65
BX62
BX62
DUAL
MULTI
11 - 30v DC
2Amp
1Amp
24
36
2745
1905
2595
4380
2910
72w
108w
164g
–40 to 105 ºC
EMC & R65
Installa�on
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Redtronic BX31
Summary of Contents for Redtronic BX31
- Page 1 SINGLE, DUAL & MULTI COLOUR BX31 BX32 BX61 BX62 Technical Informa�on BX31 BX32 BX61 BX62 SINGLE DUAL MULTI SINGLE DUAL MULTI SINGLE DUAL MULTI SINGLE DUAL MULTI Voltage Range 11 - 30v DC 11 - 30v DC 11 - 30v DC...
- Page 2 Connec�ng BX lamps to a vehicle ba�ery / power source requires the black wire to be connected to the nega�ve (-) terminal, and the red wire to be connected to posi�ve (+) terminal. Note: Secondary colour op�ons require the orange wire to be connected to the posi�ve (+) connec�on on the power source.
