Table of Contents

Precautions ........................................................................................... 2
Product Features ................................................................................... 3
Package Overview ................................................................................ 4
Product Overview .................................................................................. 5
Main Unit .......................................................................................... 5
Panel Control .................................................................................... 6
Connection Ports .............................................................................. 6
Full function wireless remote controller ............................................. 7
Connecting the Projector ....................................................................... 8
Powering On/Off the Projector ............................................................... 9
Power On the Projector .................................................................... 9
Power Off the Projector .................................................................... 10
Adjusting the Projected Image ............................................................... 11
Adjusting the Projector Height .......................................................... 11
Adjusting the Projector Zoom/Focus ................................................. 12
Adjusting Projection Image Size ....................................................... 12
On-Screen Display Menus .................................................................... 16
How to Operate ................................................................................ 16
Image-I (Computer mode) ................................................................ 17
Image-I (Video mode) ....................................................................... 18
Image-II (Computer mode) ............................................................... 19
Image-II (Video mode) ...................................................................... 20
Audio ................................................................................................ 21
Language ......................................................................................... 21
Management ..................................................................................... 22
Troubleshooting ..................................................................................... 23
Changing the Lamp ............................................................................... 25
Specifications ........................................................................................ 26
Compatibility Modes .............................................................................. 27
1
E
nglish

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H55 and is the answer not in the manual?

Questions and answers

Related Manuals for Optoma H55

Summary of Contents for Optoma H55

  • Page 1: Table Of Contents

    Connection Ports ... 6 Full function wireless remote controller ... 7 Installation Connecting the Projector ... 8 Powering On/Off the Projector ... 9 Power On the Projector ... 9 Power Off the Projector ... 10 Adjusting the Projected Image ... 11 Adjusting the Projector Height ...

  • Page 2: Usage Notice

    Warning- When the lamp reaches the end of its life, it will burn out and may make a loud popping sound. If this happens, the projector will not turn back on until the lamp module has been replaced. To replace the lamp, follow the procedures listed under “Changing the Lamp”.

  • Page 3: Introduction

    Full function wireless remote controller Multimedia audio integration User friendly multilingual on-screen display menu Advanced electronic keystone correction User friendly control panel Luxurious carrying case included SXGA compression and VGA, SVGA re-sizing 200 Watts user replaceable UHP lamp Mac compatible nglish Introduction projector. The...

  • Page 4: Package Overview

    Introduction Package Overview This projector comes with all the items shown below. Check to make sure your unit is complete. Contact your dealer immediately if anything is missing. Projector with lens cap RS232 Cable S-Video Cable Audio Cable Jack/RCA...

  • Page 5: Product Overview

    nglish Introduction Product Overview Main Unit 1. Panel Control 2. Power Connector & Power Switch 3. Connection Ports 4. Focus Ring 5. Zoom Lens 6. Zoom Ring 7. Speaker 8. Remote Control Receiver 9. Elevator Button 10. Elevator Foot...

  • Page 6: Panel Control

    nglish Introduction 1. Lamp Warning LED 2. Temperature Warning LED 3. Volume 4. Mute 5. Menu (On/Off) 6. Four Directional Select Keys 7. Enter 8. Zoom 9. Re-sync 10. Source 11. Power /Standby 2. Audio Input for Video 3. Composite Video Input Connector 4.

  • Page 7: Full Function Wireless Remote Controller

    Full Function Wireless Remote Controller Backlight Enter Menu Computer Source HDTV Source Brightness Contrast Keystone Correction Zoom nglish Introduction Power Four Directional Select Keys Re-sync 16:9/4:3 Aspect Ratio Video Source S-Video Source Freeze Color Temperature Mute Volume...

  • Page 8: Installation

    INPUT S-Video Output To ensure the projector works well with your computer, please configure the display mode of your graphic card to make it less than or equal to 1024 X 768 resolution. Make sure timing of the display mode is compatible with the projector.

  • Page 9: Powering On/Off The Projector

    1. Remove the lens cap.Œ 2. Ensure that the power cord and signal cable are securely connected. 3. Turn on the main power switch on the side of the projector and allow the projector to warm up for 1-2 minutes. ...

  • Page 10: Powering Off The Projector

    After the “Power/Standby” indicator starts flashing, you can turn off the main power switch on the side of the projector. If you want to turn on the projector, you must press the “Power/ Standby”button within 90 seconds of the start of the indicator flashing.

  • Page 11: Adjusting The Projected Image

    Ž 3. Use to fine-tune tilt-adjustment. To lower the projector: 1. Press the elevator button. 2. Lower down the projector, then release the button to lock the elevator foot into position. Ž 3. Use to fine-tune tilt-adjustment. Installation ...

  • Page 12: Adjusting The Projector Zoom/Focus

    You may adjust zoom ring to zoom in / out. Rotate the zoom ring counter- clockwise to zoom in and clockwise to zoom out. To focus the image, rotate the focus ring until the image is clear. The projector will focus at distances from 3. 7 feet to 40.7 feet (1.1m to 12.4m).

  • Page 13: User Controls

    When you press “Backlit” button, all buttons on remote controller will flash fluorescent yellow. Return to normal mode, press “Backlit” button again. Power Refer to the “Power On/Off the Projector” section on page 9~10. Four Directional Select Keys to select items or make adjustments for your selection.
  • Page 14 Freeze Press the “Freeze” button to still the screen image. Keystone Adjust image distortion caused by tilting the projector. (±16 degrees) Zoom When you press “Zoom” button, the zoom icon appears on the screen. Press button to zoom in or zoom out of the image.
  • Page 15 Use the Panel Control Power / Standby Refer to the “Power On/Off the Projector” section on page 9~10. Source Press “Source” to choose RGB, DVI-Digital, DVI-Analog, S-Video, Composite, Component and HDTV sources. Re-Sync Automatically synchronizes the projector to the input source.

  • Page 16: On-Screen Display Menus

    OSD will be the “Computer OSD”. In video source, the OSD will be the “ Video OSD”. The projector will detect the source automatically. To open the OSD menu, press the “Menu” button on the Remote Control or Panel Control.

  • Page 17: Image-I (Computer Mode)

    Computer mode Language Management Image-I Image-II Audio Brightness Zoom Contrast Keystone Color Temp. Brightness Adjusting the brightness of the image. Press the Press the Contrast The contrast controls the degree of difference between the lightest and darkest parts of the picture. Adjusting the contrast changes the amount of black and white in the image.

  • Page 18: Image-I (Video Mode)

    nglish User Controls Video mode Language Management Image-I Image-II Brightness Tint Contrast Sharpness Color Brightness Adjusting the brightness of the image. Contrast The contrast controls the degree of difference between the lightest and darkest parts of the picture. Adjusting the contrast changes the amount of black and white in the image.

  • Page 19: Image-Ii (Computer Mode)

    Computer mode Language Management Image-I Image-II Frequency H. Position Tracking V. Position 16:9 / 4:3 Reset Frequency “Frequency” is for changing the display data frequency to match the frequency of your computer’s graphic card. When you experience a vertical flickering bar, use this function to make an adjustment.

  • Page 20: Image-Ii (Video Mode)

    Color Temp. 16:9 / 4:3 Reset Keystone Correction Adjust image distortion caused by tilting the projector. (±16 degrees) 16 : 9 / 4 : 3 You can use this function to fit your desired aspect ratio type. Color Temperature Adjust the color temperature. The range is from “Low” to “High”. The factory default is “Mid”.

  • Page 21: Audio

    Computer / Video mode Language Management Image-I Image-II Audio Volume Stereo / Mono Treble Mute Bass Volume Press the Press the Treble The treble setting controls the higher frequencies of your audio source. Press the Press the Bass The Bass setting controls the lower frequencies of your audio source. Press the Press the Stereo / Mono...

  • Page 22: Management

    HDTV Front-Desktop The factory default setting. Rear-Desktop When you select this function, the projector reverses the image so you can project behind a translucent screen. Front-Ceiling When you select this function, the projector turns the image upside down for ceiling-mounted projection.

  • Page 23: Appendices

    Check if the projection lamp has been securely installed. Please refer to the “Changing the lamp” section. Make sure you have removed the lens cap and the projector is switched on. Problem : Partial, scrolling or incorrectly displayed image. Press the “Re-Sync” button on the Remote Control.
  • Page 24 The projector itself will automatically detect 16:9 DVD and adjust the aspect ratio by digitization to full screen with 4:3 default setting. If the projector is still outstretched, you will also need to adjust the aspect ratio by referring to the following: Please select 4:3 aspect ratio type on your DVD player if you are playing a 16:9 DVD.

  • Page 25: Changing The Lamp

    Changing the lamp The projector will detect the lamp life itself. It will show you a warning message “Lamp is running out of standard lifetime. Be sure to replace the lamp as soon as possible.” When you see this message, change the lamp as soon as possible.

  • Page 26: Specifications

    nglish Appendices Specifications Light Valve Contrast Ratio Lamp Number of Pixels Displayable Color Projection Lens Projection Screen Size Projection Distance TV Line Video Compatibility H. Frequency V. Frequency Multimedia Audio Power Supply Power Consumption Uniformity I/O Connectors Weight Dimensions (W x H x D) Environmental Safety Regulation - Single Chip DLP...

  • Page 27: Compatibility Modes

    Compatibility Modes Remark : “ ” compression computer image. (ANALOG) Mode Resolution V.Frequency (Hz) " " " " nglish Appendices H.Frequency (kHz)
