Onkyo HT-R495 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

AV Receiver
HT-R495
Final Issue
HT-S5910(B) = HT-R495(B) + HTP-596(B)(SKF-596(B)+SKC-594(B)+SKR-594(B)+SKW-593(B))
HT-S5915(B) = HT-R495(B) + HTP-598(K)(SKF-596(K)+SKC-594(K)+SKR-594(K)+SKW-658(B))
HT-R495
SKR-594
SKF-596
SKW-593
(For HT-S5910)
SKW-658
(For HT-S5915)
SKC-594
Service Manual
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Color
Type
HT-R495
(B) – Black
MDC
HT-R495
(B) – Black
MMP
HT-R495
(B) – Black
MMB
HT-R495
(B) – Black
MMT
HT-R495
(B) – Black
MMA
Published by Onkyo & Pioneer Corporation Global CS Department 2019
Power Requirement
Remarks
AC 120 V
Canada/USA
AC 220 V to 240 V
Europe
AC 220 V to 240 V
UK
AC 220 V to 240 V
Thailand
AC 220 V to 240 V
Australia/New Zealand
For details, refer to "Important Check Points for good servicing".
Ref.No. : 4862

Advertisement

Table of Contents
loading

Related Manuals for Onkyo HT-R495

Summary of Contents for Onkyo HT-R495

  • Page 1 AC 220 V to 240 V Thailand HT-R495 (B) – Black AC 220 V to 240 V Australia/New Zealand SKR-594 For details, refer to "Important Check Points for good servicing". SKW-658 (For HT-S5915) SKF-596 SKC-594 Published by Onkyo & Pioneer Corporation Global CS Department 2019...

  • Page 2: Service Notes

    Important Check Points for Good Servicing Service Notes In this manual, procedures that must be performed during repairs are marked with the below symbol. Please be sure to confirm and follow these procedures. 1. Product safety Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by following the safety instructions described in this manual. Use specified parts for repair.

  • Page 3: Other Cautions

    “!” in the parts list are critical for risk of fire and electrical shock. Replace these components with ONKYO parts whose part numbers appear as shown in this manual. 2. Safety check after servicing (1) To ensure safety, check that the covered insulating sheet or tube are removed, all parts and wires which are removed or disconnected while servicing have been put back to their original positions after servicing.

  • Page 4: Note For Parts List

    Note for Parts List File Name of Parts List File (EXCEL File) When parts list is EXCEL file, please refer to the following explanation about file name. P L _ T X – S R 3 4 3 ( B ) M J J . x l s x Destination Model No.
  • Page 5 Reset Reset 【STORE】 [ SETUP ] + [ ENTER ] x 2 【RESET】 1. [ CBL/SAT ] + [ ON/STANDBY ]  2. Unplug the power cord from AVR after the disappeared "Clear“ of FL tube and AVR goes standby. 【RECALL】 [ SETUP ] + [ RETURN ] x 2 Detail Key Operation is here. Common...

  • Page 6: Protect Mode

    Power Supply RL6501 for STANDBY TRANS. VOLTAGE (FL/FR) VPRO: DC voltage detection DRIVE IPRO: Current detection Q6021 SEC-1 Relay FUSE AC IN F9002 (HIGH) RL9001 RELAY Power RL6911 Supply FUSE RL6912 SEC-1 F6901 (LOW) F6902 Power Supply TX-SR393/TX-SR494 HT-R398 / HT-R495...

  • Page 7: Self-Diagnostics

     Front R channel  Surround back L channel turn on/off, or AC unplugged. the power supply for amplifier circuit become low voltage state(SEC1-LOW), and the speaker  Surround back R channel relay will be turned off. TX-SR393/TX-SR494 HT-R398 / HT-R495...
  • Page 8 3. Setup & select channel for self-diagnostic by enter service mode to “AMPChDiag” Display as in the right figure appears. Select channel by cursor Left & Right. 4. [STANDBY/ON] Unit will go into standby. 5. [STANDBY/ON] Unit will turn on. Then self-diagnostic will start automatically TX-SR393/TX-SR494 HT-R398 / HT-R495...
  • Page 9 After display “DATA Cleared!”, It will be data reset and go to normal mode. Information Displayed (Record this Information) DataCleared! Time after Power on History No. Cumulative operation time after Reset xx : xx : 1 ~ 3 : xx h (1 is latest.) TX-SR393/TX-SR494 HT-R398 / HT-R495...

  • Page 10: Service Information

    THX_U2GAME_LMD_END THX_51_MTR_GAMES FLASH SURR_51_NEOX_GAME THX_51_DSC_GAMES DEBUGMODE THX_U2MUSIC_LMD_BEGIN SURR_20_DOLBY_SURR THX_51_PLIIX_GAME FLASH2 THX_51_SLCT2_MUS SURR_51_DOLBY_SURR THX_51_PLIIZ_GAMES FLASH3 THX_51_PLIIZ_SLCT2_MUSIC SURR_LMD_END THX_51_NEO6_GAMES FLASH4 THX_U2MUSIC_LMD_END THX_51_NEURAL_GAMES FLASH_CHECK DTSSS_LMD_BEGIN THX_20_NEOX_GAMES THX_U2CINEMA_LMD_BEGIN SPECIAL_LMD_END DTSSS_20_NEO6_MUSIC THX_51_NEOX_GAMES THX_51_SLCT2_CIN THX_20_DOLBY_SURR_GAME DTSSS_20_NEO6_CINEMA THX_51_PLIIZ_SLCT2_CINEMA DTSSS_51 THX_51_DOLBY_SURR_GAME THX_U2CINEMA_LMD_END DTSSS_LMD_END THX_GAME_LMD_END TX-SR393/TX-SR494 HT-R398 / HT-R495...

  • Page 11: Firmware Update

    ID and Password are those we informed when changed. Filename is as follows: ONKAVR002B_Rxxx_xxx.zip for TX-SR393, HT-R398 Step4 : [Cursor UP +3 ] Filename is as follows: ONKAVR002C_Rxxx_xxx.zip for TX-SR494, HT-R495 OSD Firmware Version will appear on the main unit’s display. Filename is as follows: ONKAVR002B_Rxxx.zip for TX-SR292BT...
  • Page 12 If you need each module of the firmware update, you can select the module by pressing PRESET < and > button. It should be updated firmware by selecting USB -> ALL normally. TX-SR393/TX-SR494 HT-R398 / TX-SR292BT HT-R495...
  • Page 13 Wait until update is completed. When the update ends, “Completed!” is displayed. When “ Completed!” message appeared, you can power off by pressing “ ON/STANDBY” button. (If you leave it, it automatically turns standby mode. ) TX-SR393/TX-SR494 HT-R398 / TX-SR292BT HT-R495...
  • Page 14 Model and Destination １．[ TV ] + [ ON/STANDBY ] → [ ENTER ] → [ TUNER UP/DOWN ] x 4 Model Name Destination FL Display HT-R495 R 4 9 5 0 1 0 1 HT-R495 R 4 9 5...
  • Page 15 *If the measured value are under 1 mV or over 10 mV, you have to make sure repair. When there is no measured connector on the board: 1. Measure by inserting a like thin pin into the hole of the connector for measurement. 2. Measure via connector as shown. BAAF-2690 HT-R495...
  • Page 16 Hookup and Setting No Sound ■ No sound from connected player □ Chose input selector which is assigned to connected input terminal ? □ Isn’t muting on ? ■ No sound from connected TV □ Chose wrong input selector ? □...
  • Page 17 Hookup and Setting No Picture ■ In general □ Connection cable is bent , twisted or damaged ? □ Input is switched on TV ? ■ No picture from connected player by HDMI input terminal □ Chose input selector which is connected to player ? □...
  • Page 18 Hookup and Setting No Power ■ In general □ Check if the connection cable is bent or twisted, damaged. ■ There is time when indication on the front panel doesn't just light up. □ Please check the connecting cord of a DISPLAY PCB. ■...

  • Page 19: Troubleshoot

    Trouble Shoot No Sound (HDMI in) Here the trouble shoot which focuses on the hardware troubles regarding PCB assembly is explained. Of course, with actual repair there are also troubles due to damaged Power Transformer, Wiring, soldering etc. in addition to PCB assembly. No Good Process Check Point...
  • Page 20 Trouble Shoot No Sound (Opt in) Here the trouble shoot which focuses on the hardware troubles regarding PCB assembly is explained. Of course, with actual repair there are also troubles due to damaged Power Transformer, Wiring, soldering etc. in addition to PCB assembly. No Good Process Check Point...
  • Page 21 Trouble Shoot No Sound (Analog in) Here the trouble shoot which focuses on the hardware troubles regarding PCB assembly is explained. Of course, with actual repair there are also troubles due to damaged Power Transformer, Wiring, soldering etc. in addition to PCB assembly. No Good Process Check Point...
  • Page 22 Trouble Shoot No Picture (HDMI in/ out) Here the trouble shoot which focuses on the hardware troubles regarding PCB assembly is explained. Of course, with actual repair there are also troubles due to damaged Power Transformer, Wiring, soldering etc. in addition to PCB assembly. No Good Process Check Point...
  • Page 23 Trouble Shoot No Power Here the trouble shoot which focuses on the hardware troubles regarding PCB assembly is explained. Of course, with actual repair there are also troubles due to damaged Power Transformer, Wiring, soldering etc. in addition to PCB assembly. No Good Process Check Point...
  • Page 24 Check Point (BAAF-2690) Trouble Shoot J4101 Audio Signal(FL OUT, CLA-IN) +15V J4188 -15V J4187 F6901 F6902 Check Damage Q6021 Q6001 Base Base Back ● Each voltage is shown as the reference value. TX-SR292BT/SR393/SR494, HT-R398/R495 Audio Signal(FL OUT, CLA-OUT)
  • Page 25 Check Point (BAAF-2690/BACLA-2673) Trouble Shoot ANY PARTS Check damage Normal(OK) or Damage  (No good) Check the damage in the red framework part as shown with visual inspection. e.g. Broken, Burnout, Discoloration, etc. J5131 J5132 J5102 J5101 J5130 J5100 J5142 J5112 J5141 J5111 J5140 J5110 J5152 J5122 J5151 J5121 J5150 J5120 J5042 J5041 J5040 C5522 C5521 C5523 C5482 C5481 C5483 J5052 J5051 J5050 R5482 R5481 R5483 R5462 R5461 R5463...
  • Page 26 Check Point (BADIS-2672) Trouble Shoot C7780 J7782 J7906 J7780 ATMOS S7623 RIGHT LEFT S7601 KEY3 S7700 D7751 LED_ATMOS_4K Q7780 KEY2 FLDCLK S7624 S7622 STANDBY/ON J7907 J7924 /REMIN DOWN P7900 FLDSDO D7750 Bluetooth GNDDG FLDCS D7902 +3.3S D7900 D7901 /FLDRST Q7905 +3.3VDIS S7621 Q7905A MICMUT DIMMER INFO...
  • Page 27 Check Point (BAPRC-2695) Trouble Shoot +5.8V 0 → +2.5V Audio Signal (DACFL) Q3404 Audio Signal (OPT) +10V → +18V 0 → +3V 0 → +3.3V +10V → +18V P7002A P7001A P7001 ● Check damage and connection How to check 1.Disconnect the FFC from the socket. 2.Check the contacts of the FFC.
  • Page 28 Check Point (BAPS-2674) Trouble Shoot Check Damage. F9001 P9001A P9002 AC-G AC G P9021 AC 100 V to 240 V P9002  (Power supply voltage when RL9001-ON) BCPS-2674 AC-H 25142674 QPWBCPS2674 F9001C F9001A J9001 T9002 F9001D F9001B T2.5AL250V C9012 RL9001 Check the operation sound. P9101 RL9001 F9101 J9021 T4A 250V J9026 J9025 P9022 J9036 P2802A C9103 D9101A Bottom Side View Back TX-SR292BT/SR393/SR494, HT-R398/R495...

  • Page 29: Schematic Diagrams

    Schematic Diagrams Block Diagrams (Analog Audio) (Analog Audio) BAAF-2690 Main L MICOUT Direct L Main R Main +29dB DACFL Multi Front L Headphone BT MODULE BAETC-2679/2688 DownMix Direct R AMUT Main +29dB DACFR Multi Front R AUXL SPRLF DIS2672 AUXR DIS2681 (Only T2-00) Main...
  • Page 30 Schematic Diagrams Block Diagrams (Video) BAPRC-2695 Q8401 HDMI Tranceiver MN864788A TMDS HDMI IN1 HDMI IN2 MAIN OUT LINK0 HDMI IN3 HDMI IN4 TX-SR292BT/SR393/SR494, HT-R398/R495...
  • Page 31 Schematic Diagrams Block Diagrams (Dgital Audio & Control) BAETC-2696 Bluetooth BT_CONTROL BT_CONTROL DSP_Flash_SPI BT_RX BT_TX DAC_CONTROL BT_WAKE BT_L VIDEO_MCU VMPU MAIN_MCU BT_L DAC_CS BT_R write/Debug Q7009 BT_R Q8701 DAC_RST DSP_CONTROL BT_RST 6 Flash-ROM P8702 R5F5651CDDFB R5F56519ADFP SPI_Flash-UPG Q3401 DSP_IRQ BT_RX_MIBO DSP_CS GD25Q64CSIGR BT Module...
  • Page 32 Schematic Diagrams ASP Section FFC-100mm FROM BAPRC-2695(PART-8) FROM BAPRC-2695(PART-8) FFC-100mm P7002B 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 NSCT-17P2408 P7003B BAAF-2690(1/2)

  • Page 33: Amp Section

    Schematic Diagrams Amp Section *P6903B *P6904B BAAF-2690(2/2) -62V AV=29dB AV=29dB R25J-150 R5505 1/4W R25J-10 R25J-0.22 R6141 R6145 Q5385 0.22 INA6006AP1-T111 0.22 1/4W Q6001 Q6005 1/4W 2SD2390 2SD2390 D6601 D6605 R5861 *R6601 DA2J10100 R6605 DA2J10100 UTSP C5025 R6001,6021 J6441 J6445 IN_FL R5005 47u 50V R5045...
  • Page 34 Schematic Diagrams Thermal Sensor Section BAETC-2691 Q6800 LM61CIZ C6801 104K THERMAL C6800 (PTH) 104K Q6800A Thermal connect +3.3VDC R6808 220k 1 2 3 4 5 P6800A CHD-1.5-5 FROM BAPRC-2695(PART-8) TX-SR292BT/SR393/SR494, HT-R398/R495...
  • Page 35 Schematic Diagrams Amp Section MODEL NO. TX-SR292BT/393/494,HT-R398_C/495_C,VSX-534/534D/326_C/834 SCHEMATIC DIAGRAM(PART-5) AMP SECTION BACLA-2673 TX-SR292BT/393/494,HT-R398_C/495_C BACLA-2681 VSX-534/534D/326_C/834 CLASS A R25J-10 Model R5502 R5382,R5422 1/4W R25J-220 R542*/R544* Q5382 Q5382,Q5422 Mount INA6006AP1-T111 Mount IN_FR Q542*/Q544* Q5422 GNDIN_FR UTSP R538*/R540* C5022 R25J-56K +B1R 47u50V R5002 R5042 R6402 -B1R...
  • Page 36 Schematic Diagrams PS Section THE COMPONENTS IDENTIFIED MARK ARE CRITICAL FOR SAFETY, REPLACE ONLY WITH PART NUMBER SPECFIED. CAUTION FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, VOLTAGE (MEASURED WITH VOLTMETER) IS DC VOLTAGE. (NO INPUT SIGNAL) REPLACE ONLY WITH FUSE OF SAME TYPE AND RATING INDICATED. ELECTRLYTIC CAPACITORS ( ) ARE IN uF/WV.

  • Page 37: Display Section

    Schematic Diagrams Display Section BADIS-2672 DISPLAY Q7905A Q7905 (FL) CIG25-1608N FLAC1 FLAC2 FLAC1 R7900 FLAC2 RNU1/2WCJ-8.2 SEC3_1 INC5001AP1-T111 Q7901 D7900 L7900 R7903 Q7900 INA5001AP1-T111 or KTA1661-Y LBC2518T2R2M SEC3_2 J7900 RL1N4003 Q7903/7904 or 2SC2881-Y or 2SC2712-GR R7914 D7902 D7901 R25J-47 Q7903 Q7904 RL1N4003 RL1N4003...
  • Page 38 Schematic Diagrams Display (Head Phone) Section BAETC-2679 HEADPHONE C7884 102J P7881 GND_DG MSJ-064-05A SR R7881 HPDET RS1/2WBJ-330 HP_GND R7880 RS1/2WBJ-330 TP7882 P7882 TER21-0130V TX-SR292BT/SR393/SR494, HT-R398/R495...

  • Page 39: Dsp Section

    Schematic Diagrams DSP Section MODEL NO.TX-SR292BT/393/494,HT-R398_C/495_C,VSX-534/534D/326_C/834 BAPRC-2695 (1/6) DSP_DBDA DIR_BCK/DSD_CLK DSP_DBCK DIR_LRCK2 TP3403 TP3404 TP3406 DIR_SD0/DSD0 64Mbit HM_AM_SD1_DSD1 R3407 2.2k HM_AM_SD2_DSD2 R3414 HM_AM_SD3_DSD3 Q3401 HM_AM_SD4_DSD4 VCC 8 DIR_LRCK HD# 7 ADSP_MCK SCLK 6 ADSP_MCK R3404 ADSP1_SD0 DSPC_RST_DBG SI 5 ADSP1_SD0 R3406 3.3k ADSP1_BCK...

  • Page 40: Power Supply Section

    Schematic Diagrams Power Supply Section MODEL NO.TX-SR292BT/494,HT-R398_C/495_C,VSX-534/534D/326_C/834 BAPRC-2695 (2/6) 12:C9 FANCTRL TP728 POFF2 12:C8 POFF2 POFF 12:C8 POFF 12:M1;14:B10;14:P8;15:R5 HDMI_PON 12:C9 M_PON +12VWR 12:C9 +12VWR R8903 1k POFFIN TP730 GNDDG POFFIN POFF M_PON TP727 M_PON M_PON Q8963 R8962 TP8700 POFF2 POFF2 R8961 KRA302E...
  • Page 41 Schematic Diagrams HDMI Section BAPRC-2695 (3/6) L8160 +3.3VATX_788 BLM15PX121SN1D +3.3VHD +1.1VHD L8161 +1.1V +3.3VARX0_788 BLM15PX121SN1D C8152 L8162 +3.3VARX1_788 226M BLM15PX121SN1D 6.3V SPIFLASH_UPG L8151 L8163 +1.1VATX_788 BLM15PX121SN1D C8153 +3.3VARX2_788 BLM15PX121SN1D L8152 226M L8164 R8155 6.3V +1.1VARX0_788 BLM15PX121SN1D +3.3VARX3_788 BLM15PX121SN1D L8153 C8154 L8165 +3.3VHD +1.1VARX1_788...
  • Page 42 Schematic Diagrams DIR/DAC/BT Section BAPRC-2695 (4/6) VOL_CLK VOL_CLK 12:M3 VOL_DAT VOL_DAT 12:M3 VPROTECT VPROTECT 12:M3 IPROTECT IPROTECT 12:M3 SEC1H SEC1H 12:M3 VOLH TO BLUETOOTH MODULE TO AMPLIFIRE SECTION VOLH 12:M3 AMUT AMUT 12:M4 BAAF-2690 BAETC-2696 SPRLF SPRLF 12:M4 SPRLCS SPRLCS 12:M4 SPRLSB SPRLSB...
  • Page 43 Schematic Diagrams MMPU Section ・　　印は火災、感電の危険に関与する部品の為、必ず指定部品を使用の事。 ・記入無きコンデンサの耐圧は下記である。 BAPRC-2695(5/6) 　容量/耐圧 DIG_SDI ・電圧表示は無信号時に測定した直流電圧を示す。 (PART-10内) 15:R4;16:B7 DIG_SDI (DSP_MIDO) DIG_SDO （単位V、入力抵抗100KΩ/V以上の電圧計） 104K/16V 15:R4;16:B7 DIG_SDO (DSP_MODI) ・記入無き電解コンデンサ（　　 ）の単位はμF/WVである。 105K/10V DIG_CLK 15:R4;16:B7 DIG_CLK その他/50V ・記入無きコンデンサの単位はpF/50WVである。 例　030→3pF　330→33pF　331→330pF　333→0.033μF DAC_CS 15:R5 DAC_CS DAC_RST ・PWB表示のシンボル図において、太線は部品名印刷側である。 15:R5 DAC_RST 例　 　印刷側 DIR_INT0 15:R4 DIR_INT0 DIR_RST ・本配線図は基本配線図につき性能改善等により予告なく変更する事がある。...
  • Page 44 Schematic Diagrams VMPU Section MODEL NO.TX-SR292BT/393/494,HT-R398_C/495_C,VSX-534/534D/326_C834 BAPRC-2695(6/6) KRA302E VM_HPD VM_HPD Q8704 VM_HPD0 Q8705 KRC402E +3.3V_VMPU DBG_TXD DBG_RST FINED_V R8723 R8701 +3.3V_VMPU 4.7k USBV_DP +3.3V_VMPU D8701 DBG_RXD VM_RST USBV_DM C8702 104K DBG_RST SF_3.3V Q7017 PE3 75 HPD_IN1 AVCC1 KRC402E R8733 10k PE4 74 EMLE (NC)
  • Page 45 Schematic Diagrams Bluetooth Module Section BAETC-2696 SIDE C794 104K 9PIN BLUETOOTH MODULE TP101 TP102 +3.3VBT TP103 BT_RST BT_WAKE Q781 JS-BTMA2F76S-1 TP104 SPK_R TP105 LRVCM TP106 SPK_L GND4 TP41 TP107 R797 SPK_R BT_WAKE GND1 SPK_RP 41 TP40 TP108 LRVCM BT_TX WAKE LRVCM 40 R796 TP109...

  • Page 46: Tuner Section

    Schematic Diagrams Tuner Section BARF-2678/2687 TEST PARTS VDDRF VDD2 +3.3V 332K GND1 VDD2 100D X2 19 VDDRF X1 18 473K 330n 090D 101J FRF1 RFGND VDD1 +3.3V GNDRF IISD R9 100 105K LOUT LOUT LRCK/LOUT ARF1 ROUT ROUT BCLK/ROUT ARF2 BK1608HS601-T R8 100 105K...

  • Page 47: Exploded Views

    A901 WARRANTY CARD (MDC only) A911 INSTRUCTION MANUAL, QSG_U3(HTR495) (MDC only) A911 INSTRUCTION MANUAL, QSG_U8(HTR495) (Except MDC) A912 INSTRUCTION MANUAL, QSG_Ar(HTR495) (MMB only) A913 INSTRUCTION MANUAL, SAFETY_U4(2019Low-ONK) (MDC only) A913 INSTRUCTION MANUAL, SAFETY_U9(2019Low-ONK) (Except MDC) A505A A505B Front A501 + UNIT HT-R495...
  • Page 48 équipement doit être installé et utilisé en gardant une distance de 20 cm ou plus entre le mentioning this document. dispositif rayonnant et le corps (à lʼexception des extrémités : mains, poignets, pieds et Additional test will be required if it will be equipped to the chevilles). other devices. A211A A201 A211 HT-R495...
  • Page 49 Rear, Amp. T901 BAETC-2680 BAETC-2692 BACLA-2673 BAPS-2674 BAETC-2691 BAETC-2733 Q6001A F6901 F6902 P9000 P7002 Q6001B P7003 P101 Q6001 Q6002 BAPRC-2695 BAAF-2690 Q6003 Q6005 Q6006 Q6007 Q6008 P7001 Q6021 Q6022 BARF-2678 Q6023 Q6025 P101 Q6026 Q6027 Q6028 P7003 A121 A120 A101 HT-R495...
  • Page 50 Appendix Notation button operation Use the following expressions to simplify the description of the button operation. Example 1) [ A ] + [ B ] → [ C ] This means "While holding down [ A ] button, press [ B ] button then release both buttons and then press [ C ] button". Example 2) [ A ] + [ B ] x 2 → [ C ] This means "While holding down [ A ] button, press [ B ] button twice then release both buttons and then press [ C ] button". Common...

  • Page 51: Set Volume

    Appendix Reset & Store Recall User Parameter Value Data Step1: STORE (To save user preferences.) Step3: RECALL (To load user preferences.) [ SETUP ] + [ ENTER ] x 2 [ SETUP ] + [ RETURN ] x 2 Step2: RESET 1. Set Volume 40 2. [ TV ] + [ ON/STANDBY ]  → [ ENTER ] 3. [ ON/STANDBY ] ※) ”All Clear” appears on the display and the unit returns to  standby. Do not unplug the power cord until “All Clear”  disappears from the display. Common...
  • Page 52 Appendix MAIN Checksum Verification [ DIMMER ] + [ ON/STANDBY ] x 2 → [ ENTER ] Or use service mode function. Please see this section. Display checksum as below. “xxxxxxxx” is checksum of Main MCU. Make sure Checksum after firmware update Common...
  • Page 53 Appendix Key Operation Check This test is each key(button) is working normally or not. Step6: Push [ON/STANDBY] key Setp1: Set volume 40 Setp2: [TV] + [ON/STANDBY] Step7: Push [BD/DVD] key for exit key operation check mode(1-06)  ̲ And return “TEST 1-00” This Segment is blinked Setp3: Push [BD/DVD] Setp8: Push [ON/STANDBY] key for “ALL Clear” reset and go to standby mode. Step4: Push [TUNING UP] x 5 and select “TEST 1-06” Step5: When you push Each key(button). The FL tube shows each key name. Above sample: Push [BLUETOOTH] key. Common...
  • Page 54 Appendix Check FL Tube and LED [ TV ] + [ ON/STANDBY ]  → [ ENTER ] Step5: Push [↑] Confirm that all LEDs and all segments of FL tube are lit. Step1: Set Volume 40 Step2: [TV] + [ON/STANDBY] → [ENTER] Step6: Push [↑] The Unit shows “Model & Destination” Step3: Push [↑] Step7: Push [ON/STANDBY] and all clear reset. Step4: Push [↑] The unit will enter standby mode. Common...

  • Page 55: Enter Service Mode

    Enter Service mode Service Mode How to enter to service mode. Step1 : [DIMMER] + [ON/STANDBY] x 2 The version of main microprocessor. M1.xx / xxxxxAEx (displayed only for 3 seconds) Step2 : [SETUP] or [HOME] 1. Service Step3: Follow this Tree operation for each service mode.
  • Page 56 Service Mode Tree 1/2 Service Mode Service Mode Tree [ENTER] [ENTER] [ENTER] 1. Service 1-1.Tech Sprt. Main Checksum Display Main Checksum [RETURN] [RETURN] [↓] [↑] [ENTER] ProtectData Display Protect data See this section [↑] [↓] [ENTER] [↑] [↓] ProtectDataCLR Clear:[ENTER] Clear Protect History data [↓] [↑]...
  • Page 57 Service Mode Tree 2/2＝ Service Mode Service Mode Tree [↑] [↓] [ENTER] Select Parameter by Use Cursor 1-3.Video FAD Mode [←] [→] SET PARAMETER Left & Right See This section [RETURN] [↑] [↓] Select Parameter by Use Cursor [←] [→] SET PARAMETER Dolby VDB Thru Left &...
  • Page 58 Describe Service Mode (1-1Tech Sprt) Service Mode 1. Main Checksum Step2: Press [ON.STANDBY] button for enter standby mode If you press [ENTER] button, It will display main MCU checksum. sum M:xxxxxxxx Step3: Press [ON.STANDBY] button again for turn on the device and It will be running xxxxxxxx: checksum of Main MCU diagnostic automatically 2.
  • Page 59 Describe Service Mode (1-3 Video) 1/2 Service Mode If you use this function, you can select each parameter by use press [Cursor Left] and [Cursor Right] button. HDMI Thru If the TV will power off when the standby-thru at the unit CEC working, the AVR completely power off.
  • Page 60 No necessary user this function at the user claim Thru Sel Change Enable selector switching by remote control during standby through in ONKYO model. Standby Sleep - Sets the validity / invalidity of selector switching by remote control while keeping state.
  • Page 61 Service Mode Describe Service Mode (1-4 Sales) Photo mode This mode for sample display for taking photo. Press [ENTER] COMMON...
  • Page 62 Enter Service mode Service Mode How to enter to service mode. Step1 : [DIMMER] + [ON/STANDBY] x 2 The version of main microprocessor. M1.xx / xxxxxAEx (displayed only for 3 seconds) Step2 : [SETUP] or [HOME] 1. Service Step3: Follow this Tree operation for each service mode.
  • Page 63 Service Mode Tree 1/2 Service Mode Service Mode Tree [ENTER] [ENTER] [ENTER] 1. Service 1-1.Tech Sprt. Main Checksum Display Main Checksum [RETURN] [RETURN] [↓] [↑] [ENTER] ProtectData Display Protect data See this section [↑] [↓] [ENTER] [↑] [↓] ProtectDataCLR Clear:[ENTER] Clear Protect History data [↓] [↑]...
  • Page 64 Service Mode Tree 2/2＝ Service Mode Service Mode Tree [↑] [↓] [ENTER] Select Parameter by Use Cursor 1-3.Video FAD Mode [←] [→] SET PARAMETER Left & Right See This section [↓] [RETURN] [↑] Select Parameter by Use Cursor [←] [→] SET PARAMETER Dolby VDB Thru Left &...
  • Page 65 Describe Service Mode (1-1Tech Sprt) Service Mode 1. Main Checksum Step2: Press [ON.STANDBY] button for enter standby mode If you press [ENTER] button, It will display main MCU checksum. sum M:xxxxxxxx Step3: Press [ON.STANDBY] button again for turn on the device and It will be running xxxxxxxx: checksum of Main MCU diagnostic automatically 2.
  • Page 66 Describe Service Mode (1-3 Video) 1/2 Service Mode If you use this function, you can select each parameter by use press [Cursor Left] and [Cursor Right] button. HDMI Thru If the TV will power off when the standby-thru at the unit CEC working, the AVR completely power off.
  • Page 67 No necessary user this function at the user claim Thru Sel Change Enable selector switching by remote control during standby through in ONKYO model. Standby Sleep - Sets the validity / invalidity of selector switching by remote control while keeping state.
  • Page 68 Service Mode Describe Service Mode (1-4 Sales) Photo mode This mode for sample display for taking photo. Press [ENTER] COMMON...
  • Page 69 1/32 PAGE HT-R495(B)MDC <Note> Black color model 1. Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. 120V 2. The ! mark found on some component parts indicates the importance of the safety factor of the part.
  • Page 70 2/32 PAGE [Semi-conductors] Q6001 TRANSISTOR 2SD2390-O 2204343 Q6001or TRANSISTOR 2SD2390-P 2204344 Q6001A ISO SHEET ISO SHEET(1D3.2_23x18.5) 223067 Q6001B ISO SHEET ISO SHEET(2D3.2_23x37) 223068 Q6002 TRANSISTOR 2SD2390-O 2204343 Q6002or TRANSISTOR 2SD2390-P 2204344 Q6003 TRANSISTOR 2SD2390-O 2204343 Q6003or TRANSISTOR 2SD2390-P 2204344 Q6005 TRANSISTOR 2SD2390-O 2204343...
  • Page 71 AM LOOP ANTENNA (S&O) 232216 A808 FM ANT AS Type W 292191 A810 TAPE (SEROHAN)NITTO NO.29 29110149 A901 WARRANTY CARD (ONKYO-2017) 29365304B A911 INSTRUCTION MANUAL QSG_U3(HTR495) 29403694 A913 INSTRUCTION MANUAL SAFETY_U4(2019Low-ONK) 29403523 BAAF-2690-1J <Note> 1. Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
  • Page 72 4/32 PAGE D6606or CHIP TYPE DIODE 1SS352 223234R2 D6607 CHIP TYPE DIODE DA2J10100 223303R2 D6607or CHIP TYPE DIODE 1SS352 223234R2 D6608 CHIP TYPE DIODE DA2J10100 223303R2 D6608or CHIP TYPE DIODE 1SS352 223234R2 D6621 CHIP TYPE DIODE DA2J10100 223303R2 D6621or CHIP TYPE DIODE 1SS352 223234R2 D6622...
  • Page 73 5/32 PAGE Q5106 TRANSISTOR 2SC2713-BL 2213136R2 Q5107 TRANSISTOR 2SC2713-BL 2213136R2 Q5108 TRANSISTOR 2SC2713-BL 2213136R2 Q5125 TRANSISTOR 2SC2713-BL 2213136R2 Q5126 TRANSISTOR 2SC2713-BL 2213136R2 Q5127 TRANSISTOR 2SC2713-BL 2213136R2 Q5128 TRANSISTOR 2SC2713-BL 2213136R2 Q5225 TRANSISTOR INC5001AP1-T111 2218100R2 Q5225or TRANSISTOR KTC4373-Y 2218120R2 Q5225or TRANSISTOR 2SC2881-Y 2217564AR2 Q5226...
  • Page 74 6/32 PAGE C4008 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 342102214R1 C4009 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 342102214R1 C4010 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-221J1 342102214R1 C4011 UPZ TYPE PLASTIC FILM CAPACITOR 2AUPZTF221JE 376332214T C4012 UPZ TYPE PLASTIC FILM CAPACITOR 2AUPZTF221JE 376332214T C4020 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-1M(UTSP) 397580107AT...
  • Page 75 7/32 PAGE C5025 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 397584707AT C5026 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 397584707AT C5027 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 397584707AT C5028 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V 47M(UTSP) 397584707AT C5085 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 397581007AT C5086 UTSP TYPE ELECTROLYTIC CAPACITOR...
  • Page 76 8/32 PAGE C6901or ELECTROLYTIC CAPACITOR CE69W63V-6800MMS 3504556 C6902 ELECTROLYTIC CAPACITOR CE69W63V-6800MBC 3504542 C6902or ELECTROLYTIC CAPACITOR CE69W63V-6800M 3504518 C6902or ELECTROLYTIC CAPACITOR CE69W63V-6800MMS 3504556 C6903 FILM C C282A334J20A21A 376833344T C6904 FILM C C282A334J20A21A 376833344T C6911 CHIP TYPE CERAMIC CAPACITOR CK725B1H-104K1 332101045R1 [Resistors] R4001 CHIP TYPE CARBON RESISTOR RN72K1J-000JE...
  • Page 77 9/32 PAGE R4119 CHIP TYPE CARBON RESISTOR RN72K1J-152JE 435031524R1 R4120 CHIP TYPE CARBON RESISTOR RN72K1J-152JE 435031524R1 R4124 CHIP TYPE CARBON RESISTOR RN72K1J-101JE 435031014R1 R4134 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 435030004R1 R4135 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 435030004R1 R4141 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 435030004R1 R4142...
  • Page 78 10/32 PAGE R5185 CHIP TYPE CARBON RESISTOR RN72K1J-100JE 435031004R1 R5186 CHIP TYPE CARBON RESISTOR RN72K1J-100JE 435031004R1 R5187 CHIP TYPE CARBON RESISTOR RN72K1J-100JE 435031004R1 R5188 CHIP TYPE CARBON RESISTOR RN72K1J-100JE 435031004R1 R5205 CHIP TYPE CARBON RESISTOR RN72K1J-100JE 435031004R1 R5206 CHIP TYPE CARBON RESISTOR RN72K1J-100JE 435031004R1 R5207...
  • Page 79 11/32 PAGE R5788 CHIP TYPE CARBON RESISTOR RN72K1J-334FE 435033342R1 R5861 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 435030004R1 R5862 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 435030004R1 R5863 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 435030004R1 R5881 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 435030004R1 R5882 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 435030004R1 R5883...
  • Page 80 12/32 PAGE R6647 CHIP TYPE CARBON RESISTOR RN72K1J-682JE 435036824R1 R6648 CHIP TYPE CARBON RESISTOR RN72K1J-682JE 435036824R1 R6661 CHIP TYPE CARBON RESISTOR RN72K1J-394JE 435033944R1 R6662 CHIP TYPE CARBON RESISTOR RN72K1J-394JE 435033944R1 R6663 CHIP TYPE CARBON RESISTOR RN72K1J-394JE 435033944R1 R6665 CHIP TYPE CARBON RESISTOR RN72K1J-394JE 435033944R1 R6666...
  • Page 81 13/32 PAGE P5506B RETAINER (TRM) 25060507 P5509A RETAINER (TRM) 25060507 P6001B PLUG NPLG-9P0964 25056014 P6002B PLUG NPLG-9P0964 25056014 P6003B PLUG NPLG-9P0964 25056014 P6400 FLAT CABLE JL3 250 H 3J250606H P6400A WIRE HOL CHD-2.5-3 25053540 P6400B WIRE HOL CHD-2.5-3 25053540 P6401 FLAT CABLE JL5 300 H 5J300606H...
  • Page 82 14/32 PAGE D9033 CHIP TYPE DIODE KDS4148U 223283R2 D9034 CHIP TYPE DIODE KDS4148U 223283R2 D9035 ZENER DIODE DZ2J051M0L 224760510R2 D9036 CHIP TYPE DIODE DA2J10100 223303R2 D9037 DIODE RBR3MM30ATR 22380401R2 D9101 DIODE G10XB80-02-60A-T16 22380378F D9102 CHIP TYPE DIODE DA2J10100 223303R2 D9102or CHIP TYPE DIODE KDS4148U 223283R2...
  • Page 83 15/32 PAGE [Transformers,Coils] CHIP TYPE CARBON RESISTOR RN72K1J-000JE 435030004R1 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 435030004R1 RF COIL SDCL1608CR33JTDF 233557R1 RF COIL SDCL1608CR10JTDF 233556R1 ANTENNA COIL K7-D 232212 L7900 CHOKE COIL LBC2518T2R2M 231364M022R2 L7901 CHOKE COIL LBC2518T2R2M 231364M022R2 T9002 POWER TRANSFORMER NPT-1520JQ 2301812A [Capacitors]...
  • Page 84 16/32 PAGE C7905 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W25V-47M(UTSP) 397554707AT C7907 CHIP TYPE CERAMIC CAPACITOR CK725B1H-223K1 332102235R1 C7908 CHIP TYPE CERAMIC CAPACITOR CK725B1H-473K1 332104735R1 C7909 CHIP TYPE CERAMIC CAPACITOR CK725B1H-104K1 332101045R1 C7910 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 342101014R1 C7911 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 342101014R1 C7912...
  • Page 85 17/32 PAGE R5303 CHIP TYPE CARBON RESISTOR RN72K1J-152JE 435031524R1 R5321 CHIP TYPE CARBON RESISTOR RN72K1J-152JE 435031524R1 R5322 CHIP TYPE CARBON RESISTOR RN72K1J-152JE 435031524R1 R5323 CHIP TYPE CARBON RESISTOR RN72K1J-152JE 435031524R1 R5381 NON-FLAMMABLE CARBON FILM RESISTOR R25J-220 415472214T R5382 NON-FLAMMABLE CARBON FILM RESISTOR R25J-220 415472214T R5383...
  • Page 86 18/32 PAGE R7631 CHIP TYPE CARBON RESISTOR RN72K1J-271JE 435032714R1 R7632 CHIP TYPE CARBON RESISTOR RN72K1J-331JE 435033314R1 R7633 CHIP TYPE CARBON RESISTOR RN72K1J-471JE 435034714R1 R7634 CHIP TYPE CARBON RESISTOR RN72K1J-561JE 435035614R1 R7635 CHIP TYPE CARBON RESISTOR RN72K1J-821JE 435038214R1 R7636 CHIP TYPE CARBON RESISTOR RN72K1J-122JE 435031224R1 R7637...
  • Page 87 19/32 PAGE P010H PRINTED WIRING BOARD BCETC-2679 25142679 N NSP P010I PRINTED WIRING BOARD BCETC-2680 25142680 N NSP P010J PRINTED WIRING BOARD BCETC-2733 25142733 N NSP TERMINAL NTM-1PDSC437 25060515 P101A SOCKET NSCT-7P2100 25052203 TERMINAL NTM-2PDML439 25060517 P2802 WIRE HARNESS ASSEMBLY NSAS-7P2128 2009991317UL P2802A...
  • Page 88 20/32 PAGE D7001or CHIP TYPE DIODE 1SS352 223234R2 D7002 CHIP TYPE DIODE DA2J10100 223303R2 D7002or CHIP TYPE DIODE 1SS352 223234R2 D7003 CHIP TYPE DIODE DA2J10100 223303R2 D7003or CHIP TYPE DIODE 1SS352 223234R2 D7004 CHIP TYPE DIODE DA2J10100 223303R2 D7004or CHIP TYPE DIODE 1SS352 223234R2 D7009...
  • Page 89 21/32 PAGE Q8704 TRANSISTOR KRA302E 2218360R2 Q8704or TRANSISTOR DTA014EEBTL 2218680R2 Q8705 TRANSISTOR KRC402E 2218330R2 Q8705or TRANSISTOR DTC014EEBTL 2218690R2 Q8709 TRANSISTOR KRC402E 2218330R2 Q8709or TRANSISTOR DTC014EEBTL 2218690R2 Q8710 TRANSISTOR KRC402E 2218330R2 Q8710or TRANSISTOR DTC014EEBTL 2218690R2 Q8712 TRANSISTOR KRC402E 2218330R2 Q8712or TRANSISTOR DTC014EEBTL 2218690R2 Q8713...
  • Page 90 22/32 PAGE L8944 CHOKE COIL BLM21PG221SN1 230949R2 L8951 CHOKE COIL BLM21PG221SN1 230949R2 L8952 CHOKE COIL 1255AS-100M 231482M100R2 L8953 CHOKE COIL BLM21PG221SN1 230949R2 L8954 CHOKE COIL BLM21PG221SN1 230949R2 L8961 CHOKE COIL BLM21PG221SN1 230949R2 L8962 CHOKE COIL 1255AS-100M 231482M100R2 L8965 CORE MCF12102G900-T 2350041R2 [Capacitors] C1000...
  • Page 91 23/32 PAGE C3402 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 332011045R1 C3403 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 332011045R1 C3404 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 332011045R1 C3405 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 332011045R1 C3406 CHIP TYPE CERAMIC CAPACITOR CK725B1A-105K0 332001055R1 C3407 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 332011045R1 C3408...
  • Page 92 24/32 PAGE C7076 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 332011045R1 C7077 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J0 342031014R1 C7180 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K0 332031025R1 C7181 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K0 332031025R1 C7182 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K0 332031025R1 C7183 CHIP TYPE CERAMIC CAPACITOR CK725B1H-102K0 332031025R1 C7184...
  • Page 93 25/32 PAGE C8071 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 332011045R1 C8091 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 332011045R1 C8092 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 332011045R1 C8093 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 332011045R1 C8094 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J0 342031014R1 C8095 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-120J0 342031204R1 C8096...
  • Page 94 26/32 PAGE C8989 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-180J0 342031804R1 X3401 CRYSTAL 7V24580019 3010576R2 X7002 CRYSTAL 7V24080062 3010575R2 X8031 CRYSTAL 7V27080047 3010579R2 X8702 CRYSTAL 7V24080062 3010575R2 [Resistors] R1000 C-METAL R RN72K1J-221JE0 435012214R1 R1001 C-METAL R RN72K1J-103JE0 435011034R1 R1002 C-METAL R RN72K1J-103JE0 435011034R1 R1003 C-METAL R...
  • Page 95 27/32 PAGE R3408 CHIP RESISTOR NETWORK MNR04MRAPJ221 43464722104R2 R3408or CHIP RESISTOR NETWORK YCN104-221-JK 43464C22104R1 R3408or CHIP RESISTOR NETWORK CN24JT221 43474E22104R1 R3409 CHIP RESISTOR NETWORK MNR04MRAPJ221 43464722104R2 R3409or CHIP RESISTOR NETWORK YCN104-221-JK 43464C22104R1 R3409or CHIP RESISTOR NETWORK CN24JT221 43474E22104R1 R3410 C-METAL R RN72K1J-470JE0 435014704R1 R3411...
  • Page 96 28/32 PAGE R3494or CHIP RESISTOR NETWORK YCN104-470-JK 43464C47004R1 R3494or CHIP RESISTOR NETWORK CN24JT470 43474E47004R1 R3495 CHIP RESISTOR NETWORK MNR04MRAPJ470 43464747004R2 R3495or CHIP RESISTOR NETWORK YCN104-470-JK 43464C47004R1 R3495or CHIP RESISTOR NETWORK CN24JT470 43474E47004R1 R3496 CHIP RESISTOR NETWORK MNR04MRAPJ470 43464747004R2 R3496or CHIP RESISTOR NETWORK YCN104-470-JK 43464C47004R1 R3496or...
  • Page 97 29/32 PAGE R7075or CHIP RESISTOR NETWORK YCN104-470-JK 43464C47004R1 R7075or CHIP RESISTOR NETWORK CN24JT470 43474E47004R1 R7076 C-METAL R RN72K1J-221JE0 435012214R1 R7077 C-METAL R RN72K1J-103JE0 435011034R1 R7078 C-METAL R RN72K1J-103JE0 435011034R1 R7080 C-METAL R RN72K1J-104JE0 435011044R1 R7082 C-METAL R RN72K1J-104JE0 435011044R1 R7083 C-METAL R RN72K1J-332JE0 435013324R1...
  • Page 98 30/32 PAGE R7257 C-METAL R RN72K1J-105JE0 435011054R1 R7258 C-METAL R RN72K1J-681JE0 435016814R1 R7265 C-METAL R RN72K1J-104JE0 435011044R1 R7266 C-METAL R RN72K1J-473JE0 435014734R1 R7270 C-METAL R RN72K1J-473JE0 435014734R1 R7271 C-METAL R RN72K1J-102JE0 435011024R1 R7272 C-METAL R RN72K1J-222JE0 435012224R1 R7273 C-METAL R RN72K1J-470JE0 435014704R1 R7274...
  • Page 99 31/32 PAGE R8101 C-METAL R RN72K1J-000JE0 435010004R1 R8103 C-METAL R RN72K1J-272JE0 435012724R1 R8104 C-METAL R RN72K1J-103JE0 435011034R1 R8105 C-METAL R RN72K1J-000JE0 435010004R1 R8106 C-METAL R RN72K1J-472JE0 435014724R1 R8107 C-METAL R RN72K1J-100JE0 435011004R1 R8108 C-METAL R RN72K1J-103JE0 435011034R1 R8109 C-METAL R RN72K1J-000JE0 435010004R1 R8110...
  • Page 100 32/32 PAGE R8742 C-METAL R RN72K1J-103JE0 435011034R1 R8743 C-METAL R RN72K1J-103JE0 435011034R1 R8744 C-METAL R RN72K1J-470JE0 435014704R1 R8747 C-METAL R RN72K1J-000JE0 435010004R1 R8748 C-METAL R RN72K1J-470JE0 435014704R1 R8749 C-METAL R RN72K1J-470JE0 435014704R1 R8750 C-METAL R RN72K1J-470JE0 435014704R1 R8751 C-METAL R RN72K1J-103JE0 435011034R1 R8754...
