Communication Settings
Baud Rate
9600
Data Bits
8
Parity
N
Stop Bits
1
Flow Control
None
Command Structure
[Header][Package Size(n)][Command(c)] [Data 1]... [Data d]
Header: 2Bytes, "IR" fixed
Package Size: 2Bytes, Hexadecimal alphabets,n =c+d
Command: 3 Bytes, Hexadecimal alphabets
Data: d Bytes, d=0~248
PC send to Projector
Command
Description
(Inviald Command or Command Failed)
IR04002n
AV Mute, n=0~1
n=0: AV Mute OFF
n=1: AV Mute
IR04002?
IR03003
sync Re-sync
IR04004n
Freeze, n=0~1
n=0: Unfreeze
n=1: Freeze
IR04004?
IR04005n
Blanking Color, n=0~1
n=0: Blue
n=1: Black
IR04005?
IR04006n
Source Detect, n=0~2
n=0, Auto
n=1, NA
n=2, Manual
IR04006?
IR04008n
Mute, n=0~1
n=0: Mute OFF
n=1: Mute ON
IR04008?
IR03009
Source
IR04010n
Degamma, n=0~3
IR03010?
IR04011n
Zoom, n=0~3
n=0: Off
n=1: Zoom 1
n=2: Zoom 2
IR04011?
IR05012nn
Zoom Value, nn=F6~FF-00-01~0A(Hex Value)
IR04012?
IR03013
Menu
IR03014
Left
IR03015
Right
IR03016
Up
IR03017
Down
IR03018
Enter
IR03019
Keystone
IR0301A
Display Format
IR0301B
Display Mode
IR04020n
Source Select, n=0~9
n=0: D-sub Analog RGB
n=1: D-sub Component
n=2: D-sub SCART
n=3: DVI-Digital RGB
n=4: DVI-Analog RGB
n=5: NA
n=6: NA
n=7: Component
n=8: S-video
n=9: Composite Video
IR04020?
EP910 RS232 Command Table V1.0
Response
IR0500000
IR0500001
IR0500002
IR03002
IR03002
IR03002
IR04002n
IR03003
IR03004
IR03004
IR03004
IR04004n
IR03005
IR03005
IR03005
IR04005n
IR03006
IR03006
IR03006
IR03006
IR04006n
IR03008
IR03008
IR03008
IR04008n
IR03009
IR03010
IR04010n
IR03011
IR04011n
IR03012
IR05012nn
IR03013
IR03014
IR03015
IR03016
IR03017
IR03018
IR03019
IR0301A
IR0301B
IR03020
IR03020
IR03020
IR03020
IR03020
IR03020
IR03020
IR03020
IR03020
IR03020
IR03020
IR04020n
Description
Response "IR0500000" after the projector received a inviald or failed command
Response "IR0500001" if the projector is cooling.
Response "IR0500002" if the value out of range
Response "IR03002" after command send successed
User input value is from -10 to +10
Page 1 of 4
1_25_06
