Summary of Contents for Ecobike Basic Black
- Page 1 E L E C T R I C B I K E USER MANUAL...
-
Page 2: Eu Declaration Of Conformity
EU Declaration of conformity Wrocław, Poland 1.01.2022 The manufacturer EcoBike Sp. z o.o., Osiniecka 108, 54-530 Wrocław, Poland hereby declares that the object of declaration conforms to the EU directives and standards listed below. Technical documentation is available directly under the manufacturer’s address. -
Page 3: Important Notice
Introduction Thank you for purchasing Ecobike product. We have designed and manufactured our e-bikes in compliance with the highest international standards. We want to ensure that riding your bike is enjoyable and helps improve your health and well-being. Before riding your bicycle, please carefully read the user’s manual. -
Page 4: Safety Rules
Safety rules • • We recommend using a Do not grab hold cars or bicycle helmet that meets other vehicles • safety requirements and If your clothing has hanging standards parts or is otherwise loose, • You shall always follow the make sure that it will not road traffic and vehicle usage come in contact with any... - Page 5 • The maximum load of the bike is 120 kg. For Ecobike Cargo model, the maximum load is 155 kg. Do not exceed the carrying capacity of the bicycle •...
-
Page 6: Before The Ride
Preparing your bike for the first ride Unpack your bike and accessories from the cardboard container. Pay special care while unpacking to not scratch the bike frame or damage any transmission cables. Authorised dealers are obliged to prepare your bike for the first ride in their shop. -
Page 7: Cleaning And Maintenance
For more advanced repairs such as disassembling the forks or suspension dampers, consult a bicycle repairs shop. Locations and contact information of Ecobike autho- rised dealers and service providers can be found on www.ecobike.pl (“Store locator” tab). -
Page 8: Rims And Spokes
Wheels A correctly adjusted wheel should rotate freely and smoothly, without seizing, wobbling or loosening the axle. If the hub is loose, it must be adjusted using specialised equipment. In this case, we recommend bringing your bicycle to an authorised repair shop. Tires Follow the manufacturer’s instructions regarding tire pressure. - Page 9 Seat Adjust the seat post to the desired height and clamp it tightly. The seat pin should be inserted into the frame so that the safety marking on the pin is hidden. If you can see the marking, there is a risk of the seat pin breaking during the ride.
- Page 10 Pedals Pedals must stay correctly fixed to the crankset. An incorrect setup may damage the threading of the pedals and the crank. The right pedal’s shaft has a right- handed mounting thread and is labelled with “R”. Left pedal’s shaft is L/R marking threaded left-handed and is labelled “L”...
-
Page 11: Disc Brakes
Crankset A crankset with cranks bolted directly to its axle requires systematic check-ups. Cups inside the crank mechanism are used to gauge play in the crankset. The crank is adjusted by tightening the side crews with an Allen wrench. Riding the bike with a loose crank may damage the crank’s internal mechanics. - Page 12 Motor An electric bike can be equipped with a central motor or a motor in the front/rear hub. During uphill riding, a natural phenomenon is a decrease in speed. Depending on the degree of incline of the bike and the user’s pedaling force, the motor will minimize the overload, allowing the user to achieve a speed proportional to the ride conditions.
- Page 13 Battery Ecobike employs high-quality, light lithium-ion batteries. These batteries are environmentally friendly, have a long lifespan and high energy density, operating in a wide range of temperatures. B A T T E R Y A S S E M B L Y / D I S A S S E M B L Y To insert or remove the battery, insert the battery key and turn it.
- Page 14 For your safety Failure to follow the rules for battery use and storage may damage the battery, which may result in leakage, overheating, explosion or ignition of the battery. Avoid direct contact with the battery liquid and do not inhale its vapors. In the event of the liquid spilling on clothes or skin, rinse with plenty of water.
- Page 15 Instructions for use of the battery and the charger • • If you will have a longer Do not bend, modify, break in riding the e-bike, disassemble, or solder to the charge the battery to battery terminals directly • 80% and store it at room Do not install the battery temperature.
-
Page 16: Warranty Terms And Conditions
Product covered by the War- have been specified in the War- ranty, performed by the Warran- ranty Card, tor, Service Station or Manufac- “Manufacturer” refers to EcoBike • turer. Sp. z. o. o. (Ltd.), ul. Osiniecka The warranty period for the No. - Page 17 cost of such inspection shall be flicting with the user’s manual. paid by the Beneficiary. Failure to damaging the Product in an un- • inspect the Product results in the fortunate event (such as a traffic loss of the Warranty for mechan- accident).
- Page 18 the Warrantor immediately, not Product. If the defect requires later than within 14 days from a longer diagnosis or a transfer the date of their appearance. If of the Product or its part to the the defect is not reported to the Manufacturer, Warrantor Warrantor within the specified...
- Page 19 In the event of an unfounded war- In the case of non-compliance of ranty claim, all costs related to the sold item with the contract, its consideration shall be paid by the buyer is entitled to legal pro- the Beneficiary. In particular, the tection measures on the part of Beneficiary will cover the costs of and at the expense of the seller,...
-
Page 20: Warranty
WARRANTY CARD Bicycle model Frame number Battery number Motor number Date of purchase Stamp and signature of the Seller Results of the First Inspection (between 70-120 km) - Page 21 Repairs log Service Point stamp and signature Date of request Date of repair Description of the repairs / maintenance performed Service Point stamp and signature Date of request Date of repair Description of the repairs / maintenance performed...
- Page 22 Service Point stamp and signature Date of request Date of repair Description of the repairs / maintenance performed Service Point stamp and signature Date of request Date of repair Description of the repairs / maintenance performed...
- Page 23 Service Point stamp and signature Date of request Date of repair Description of the repairs / maintenance performed Service Point stamp and signature Date of request Date of repair Description of the repairs / maintenance performed...
- Page 24 55-330 Źródła, Polska +48 71 307 04 02 biuro@ecobike.pl www.ecobike.pl C O M P A N Y D A T A Osiniecka 108 54-530 Wrocław, Polska NIP: 8943124748 KRS: 0000715499 REGON: 369401457 Copyright © Ecobike Sp z o. o. All rights reserved.
