- Page 3 1. INTRODUCE First of all, we would like to thank you for purchasing our electric bike, which has been carefully designed and manufactured in accordance with the requirements of the highest international standards. We wish your new bike to be a new way of your life. Please read the following instructions carefully before proceeding with the bicycle.
-
Page 4: Technical Information
bike is very comfortable and allows hours of riding. These types of bicycles, and in particular their braking system, have been designed for a maximum load of 125 kg (bicycle + cyclist + luggage), the weight of the cyclist with luggage may not exceed 100 kg. This bike is designed for recreational purposes, not for competitive purposes. - Page 5 6.2 WHEELS Properly adjusted wheels should rotate slightly and smoothly, without jerks, perceptible slack. In the case of loosening in the wheel hub, it must be eliminated by adjusting. In order to adjust the wheel, you must have specialist tools, therefore, if a fault is found, please go to an authorized service point.
- Page 6 in parallel. After finding out that the tire has any of the defects, immediately go to an authorized service point. 6.6 SPOKES Spokes in wheels should be evenly stretched. The spokes loosened during the bicycle's operation may cause radial and axial runout of the wheels or rupture of the spokes, which affects the service life of the rim and hub bearings, as well as negatively affects the braking performance.
- Page 7 6.14 LIGHTING Lighting is a basic element of the user's safety. If the bicycle is used on public roads and it is not equipped with lighting and reflections, it should be additionally equipped with the bicycle in accordance with the provisions of the traffic regulations.
-
Page 8: Handlebar Assembly
Picture 1 – Put front wheel into the fork. Picture 2 – insert the "pin" through the wheel, tighten the nut on the left side so that the quick-release closure is tightened with the appropriate resistance. 7.3 HANDLEBAR ASSEMBLY handlebar most comfortable position for you and tighten all screws according to the picture below. -
Page 9: Charging The Battery
9. USING BATTERY AND CHARGER 9.1 BATTERY ECOBIKE uses high-quality lithium-ion batteries in its bicycles, which are light and do not cause environmental pollution. It’s a typical source of so-called green energy. In addition, they are characterized by: ✓... -
Page 10: Electric Motor
from heat, moisture or flammable materials. In addition, it cannot be covered. When charging the battery, please observe the following steps: A. Insert the charger plug into the socket in the battery, and then connect the charger cable to the power socket. B. -
Page 11: Driving Information
11.2 DRIVING INFORMATION 1. Press MODE to switch between modes. 2. Press Button “light” to ON/OFF front and rear light. 11.3 FAILURE INFORMATION ON THE DISPLAY 12. USER MANUAL OF LCD DISPLAY C600E USB 12.1 DISPLAY AND REMOTE APPEARANCE 12.2 TURNING ON/OFF THE DISPLAY To turn the display on or off, press and hold the on / off"... -
Page 12: Speed Indication
12.5 BATTERY SOC INDICATOR The battery level is indicated by five segments based in the battery symbol in the upper left corner of the display. Each segment corresponds to 20% battery charge. 12.6 SPEED INDICATION The speed indicator shows the current speed while cycling. User can change the unit to MPH, then the display will show the speed in MPH. -
Page 13: Display Interface
Error code Description Current flow fault / Communication fault Throttle fault Motor fault Hall sensor fult Brake levers fault Display conection fault 12.11 DISPLAY INTERFACE The display shows four cycling parameters (ODO; TRIP 1; TRIP 2 and TIME). To change displayed information, use the "SET"... -
Page 14: Warranty
Warranty Card, d) "Guarantor" - means Ecobike Spółka z ograniczoną odpowiedzialnością, address: ul. Osiniecka nr 108, 54-530 Wrocław, entered in the Register of Entrepreneurs of the National Court Register kept by the District Court for Wrocław Fabryczna in Wrocław, 6th Commercial Division of the National Court Register under... - Page 15 3. The basis for recognition of a claim during the warranty period is valid and completed with a Warranty Card along with proof of purchase. The Warranty Card, not filled in or filled out only in part, i.e. it does not include a bicycle model, battery number, date of sale, stamp or signature of the Seller, is invalid.
- Page 16 9. The necessity to make the Repair of the Equipment should be reported to the Service Point indicated by the Guarantor, who assesses the given damage. The assessment is carried out on the terms set by the manufacturer, which are the same for all users of the Equipment. The holder of the guarantee is obliged to deliver the equipment to the Service Point in person or by means of a Carrier, the cost and risk of the shipment being borne by the Eligible Person.
- Page 17 loss of transactions, loss of revenue or anticipated savings, increased costs or expenses and for any indirect, consequential or specific loss or damage. 16. For all claims arising from the granted Guarantee, only Polish law is in force. 17. To settle any disputes between the parties that may be related to relationships based on sales agreements concluded by the parties or other agreements to which these Guarantee Terms would apply, only the common court competent for the Guarantor's headquarters shall be competent.
-
Page 18: Guarantee Certificate
15. GUARANTEE CERTIFICATE MODEL: ............FRAME: ..........BATTERY: .......... MOTOR: .......... DATE OF PURCHASE: ..........SIGNATURE AND STAMP OF SELLER …………………………………………………….. SERVICE DATE DATE OF DOINGS STAMP SIGNATURE COMPLAIN SERVICE COMPULSORY "ZERO" REVIEW AFTER 70-120 KM (the review is subject to a fee) - Page 19 16. NOTES ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….. ………………………………………………………………………………………………………………….
