You are recommended to read carefully this manual before installing the product.
1 - DESCRIPTION
1A - Introduction
The receiver type MINI 2 OUT is , designed for the control of automatic closing systems and anti-burglar
systems thanks to its very high security coding system (KeeLoq ® Hopping code).
(The operating frequency is among the European harmonized frequencies; the product fully complies
with the EMC European Regulations (CE).) The code sent by the transmitter changes at every activation,
avoiding any scanning and copying risk. A special algorithm allows to keep the transmitter and receiver.
The receiver has 2 output relays ( with NO and NO/NC contacts, and can be connected to many types
of mechanics ( gate, garage door, rolling shutters, awnings, anti-burglar appliances, lighting, etc.).
The programming can be done in self-learning mode by means of the learn button.
The housing protection of IP65 allows external installations.
The appliance full complies with the European Regulations
89/336/EEC, 73/23/EEC ,EN 60336-1 and FCC Part 15.
2 RELAY
EXTERNAL MINI RECEIVER
Thank you for choosing this product.
MI NI 2 OU T
Par t N o. RE C TS M INI 2OUT
v.11.22.16
Advertisement
Related Manuals for Transmitter Solutions RECTSMINI2OUT
Summary of Contents for Transmitter Solutions RECTSMINI2OUT
- Page 1 2 RELAY EXTERNAL MINI RECEIVER MI NI 2 OU T Par t N o. RE C TS M INI 2OUT Thank you for choosing this product. You are recommended to read carefully this manual before installing the product. 1 - DESCRIPTION 1A - Introduction The receiver type MINI 2 OUT is , designed for the control of automatic closing systems and anti-burglar systems thanks to its very high security coding system (KeeLoq ®...
- Page 2 Screws 2 - TECHNICAL SPECIFICATIONS Carrier frequency 433,92 MHz Cover Local oscillator frequency 6.6128 MHz i t a Local Oscillator VCO / PLL > Intermediate frequency 10.7 MHz v i t y t i Local oscillator spurious emissions < -57 dBm : y l Vac/dc Consumption:...
- Page 3 5 - LAYOUT CONNECTIONS 4.3 - Installing Antenna 14 15 14 15 6 7 8 9 10 11 12 13 0 12 24 ch3 ch4 ac / dc Fig. 4 5.1 - Contacts terminal 6 = Contact NO Relay3 terminal 7 = Contact C Relay3 terminal 8 = Contact NO Relay4...
- Page 4 During this period, if the product doesn’t operate correctly, due to a defective component, the product will be repaired or replaced at the sole discretion of Transmitter Solutions.The warranty does not extend to the receiver case which can be damaged by conditions outside the control of Transmitter Solutions.
