- Page 1 MTP 8010 3 PHASE TESTER & MOTOR ROTATION TESTER INSTRUCTION MANUAL...
-
Page 2: Table Of Contents
INDEX Page 1. INTRODUCTION ......1 2. SAFETY NOTES ......2 3. FEATURES ........3 4. MEASURING METHODS ....4--5 5. SPECIFICATIONS ......6 6. MAINTENANCE ....... 7... - Page 3 Parts and Functions Black White 600 V 3 PHASE TESTER (1) PHASE ROTATION INPUT TERMINAL (2) OPEN PHASE INDICATOR (3) PHASE ROTATION INDICATOR (4) MOTOR TESTER POWER SWITCH (5) MOTOR TESTER POWER INDICATOR (6) MOTOR ROTATION INDICATOR (7) MOTOR ROTATION INPUT TERMINAL...
-
Page 5: Introduction
1. INTRODUCTION NOTE This meter has been designed and tested according to IEC Publication 348, Safety Requirements for Electronic Measuring Apparatus, IEC/EN 61010-1 and other safety standards. Follow all warnings to ensure safe operation. WARNING READ "SAFETY NOTES" (NEXT PAGE) BEFORE USING THE METER. -
Page 6: Safety Notes
2.SAFETY NOTES Read the following safety information carefully before attempting to operate or service the meter. Use the meter only as specified in this manual： otherwise the protection provided by the meter may be impaired. Rated environmental conditions： (1) Indoor use. (2) Installation Category lll. -
Page 8: Features
3.FEATURES Three functions in one unit, including open phase, phase sequence and motor rotation indication. This model is ideal for installing conveyor lines, pump systems and interconnected drivers. Identifies 3-phase sequence and open phase check. Battery operated. Comply with three large alligator clips. Meets UL requirement. -
Page 9: Measuring Methods
4.MEASURING METHODS Operation of 3 Phase Rotation Tester： (1) Connect the test lead to 3-phase input terminals by A-B-C. (2) Connect color alligator clips to the terminals of a 3-phase power source. Connecting order may be optional. (3) Make sure that all of the three lamps for open phase Check are on. - Page 10 Operation of Motor Rotation Tester： (1) Make sure there is no voltage present. (2) Connect the test lead to motor input terminal by L1-L2-L3, and press the power button (Fig1). The power indicator green lamp is lit. (If red lamp of clockwise or counter- clockwise is lit before rotating the motor shaft, it means there is voltage present.
-
Page 11: Specifications
5.PECIFICATIONS Input Voltage： 100Vac up to 600Vac. Frequency： 45 to 70 Hz. Circuit Structure： All electronic (not mechanical). Power Requirement： DC9V battery. Power Consumption： Consumption current approx. 14mA of motor rotation field of tester. AC power consumption approx. 7mA per phase rotation field of indicator. Installation Category：... -
Page 13: Maintenance
6.MAINTENANCE Battery Replacement： (1) It is necessary to replace battery, when green lamp is dull lit. (2) Use a screwdriver to unscrew the screws on the back then open the case (Fig.2), take out the battery and replace with new battery type (DC 9V). - Page 14 specifications without notice. Les Instruments Instruments 4409, Rue Charleroi Montreal-Nord, Quebec H1H 1T6 Telephone : (514) 326-7167 Fax : (514) 326-7835 Hot Line : 1-888-326-7167 Web Site : www.mtpinc.com Email : info@mtpinc.com...
