Summary of Contents for Whites Vision Spectra
- Page 1 Vision ™ Field Guide all you need to know...
- Page 2 Navigation UP/DOWN moves the Cusor vertical to select from a list. SIDE/SIDE moves the highlighted selection horizontally. MENU/TAB brings up menu or moves the Cursor to the next item or selection on the screen. Selection is highighted. MENU/TAB x2 brings up information screen. Includes backlight and advanced menu (see page 11).
- Page 3 ACTIVE PINPOINT SCREEN TRIGGER SQUEEZED TO Pinpoint - SQUEEZE AND HOLD TRIGGER ACTIVE ANALYZE SCREEN TRIGGER FORWARD TO Analyze - TRIGGER FORWARD...
- Page 4 Programs Coin - Aggressively rejects pull-tabs and trash. Responds to most coins and some rings. - Less trash reject - accepts aluminum, responds to most jewelry coins Coin & Jewelry and rings. - Salt subtraction method. Rejects iron and some trash. Accepts aluminum, Salt Beach responds to most jewelry coins and rings.
- Page 5 Sensitivity (Pre-Amp) Adjusts receive signal amplification. Affects sensitivity, depth, Rx Gain – and external noise. Boosts transmit signal for use in low mineral ground. Tx Boost – CAUTION - prolonged use will increase battery drain. Adjust post amp signal strength after discrimination filter process. Discrimination –...
- Page 6 Audio Target Volume – Adjust how loud a metal target “beeps”. Adjust volume level of Threshold (slight background hum). Audio Threshold – Tone – Target Tone or Pitch. (the “beep” a metal target produces). Tone or pitch of the Threshold. Threshold Tone or Pitch - When activated produces a progressively higher pitch keyed to VDI Tone ID –...
- Page 7 Discrimination Custom setting accept or reject for VDI range. Discrimination Accept / Reject – “X” Box = Accept (detected) - Empty Box = Reject. Adjust level of Bottle cap signal response. Bottle Cap Reject – Hot Rock – Adjust rejection level of negative pebbles and rocks that are not silenced by the ground balance system and would sound like targets.
- Page 8 Frequency Three Frequencies – Best choice for general use. Transmits and receives 2.5 KHz-7.5 KHz and 22.5 KHz at the same time. Salt Compensate – Receives and displays all frequencies. Uses subtraction method for saltwater balance. 2.5 KHz – Single frequency. More sensitive to high conductive metals, Silver/Copper.
-
Page 9: Ground Balance/Tracking
Ground Balance/ Tracking For best results, instrument start up should be followed by a manual ground balance. Pull and hold trigger, then press and hold enter while pumping loop up and down over the ground until threshold is smooth. Release enter then release trigger. Also helpful as an option to check tracking from any search mode. - Page 10 Information/Confi gure To access Information/Configure press MENU twice in succession. To Exit squeeze and release trigger on hand grip twice. Backlight - Backlight level - 0 = OFF, 20 = BRIGHT. CAUTION - Backlight use will cause a slight increase in battery drain.
- Page 11 Expert Menu - A much more extensive and advanced Menu. The Expert Menu contains - • Building your own custom program. • Wireless sharing programs - transfer custom programs between Vision instruments • Multiple headphone transmit and receive. • Changes color scheme and sound effects. •...
-
Page 12: First Aid
First Aid • Help Balloons - From menu screens and Zoom menus, trigger forward - brings up a “Help Balloon” that offers more information about the menu item. Help Balloon Trigger Forward • COMPLETE OWNER’S GUIDE - All of Vision’s systems and controls are explained in complete detail.
