Summary of Contents for ICARO SQUARE Light 90
-
Page 2: Table Of Contents
WHAT TO DO WHEN IT HAPPENS? ........4 PACKING INSTRUCTIONS ..........5 CARE, MAINTENANCE, AND REPAIR ....... 9 TERMS OF THE GUARANTEE ......... 10 ANNEX ................11 ICARO paragliders Hochriesstraße 1, D-83126 Flintsbach Telephon : +49 (0)8034 909700 Telefax: +49 (0)8034 909701 Email: office@icaro-paragliders.com... - Page 3 SQUARE light. All technical data and instructions in this manual were drawn up with great care. ICARO Paragliders cannot be made responsible for any possible errors in this manual. Should you decide to sell this rescue system later, please pass on this manual to the new owner.
- Page 4 Our products are manufactured with the greatest care using state-of-the-art technology. Before delivery to our dealers and flight schools, each individual rescue device is individually tested by ICARO paragliders. Important information in this manual is written in fat cursive writing.
-
Page 5: To Get To Know Your Square Light
NOT STEERABLE. Rescue systems from ICARO are characterized by a high level of reliability and maximum material strength. Fastest inflation while maintaining moderate sink rates are features of these systems. -
Page 6: Packing Instructions
The following manual is aimed at pilots who are competent in folding modern square reserve parachutes. The manual itself cannot serve as a substitute of proper training in folding a parachute. ICARO Paragliders can ensure the safety and reliability of the system only in cases where it was packed by a trained professional who followed a proper packing process. - Page 7 Page 6 4. The SQUARE light is a square rescue parachute with four corner points, so lay out the canopy with one corner at the bottom, one on the left, one on the right and one on top. Start with the first corner at the bottom and smooth the material by running your hand along it on the table 5.
- Page 8 The inner container of ICARO rescue systems has two loops, in which the handle of the harness can be attached (center, side). Note the instructions for the rescue unit in the operating instructions of your harness.
- Page 9 Page 8 It is essential to ensure that the shackles or carabiners are firmly closed after connecting the rescue to the paraglider harness. Another fixing method is to put the belt of the rescue system through the connection belt of the harness and than the rescue system through the harness belt.
-
Page 10: Care, Maintenance, And Repair
Page 9 Care, maintenance, and repair Care Instructions • Please do not store your rescue system in the vicinity of acids, grease, oils or paint. To ensure safe operation, the system needs proper maintenance and care. • Do not store your rescue system in extreme temperatures or humidity (more than 30 C 0r 55-65% humidity). -
Page 11: Terms Of The Guarantee
ICARO paragliders guarantees the proper processing, an operation within the allowable limits of proper operation and the fulfillment of the eligibility criteria of rescue equipment for 24 months at the time of first delivery by ICARO paragliders. Guarantee is only valid for ICARO products with LTF/ EN certification. - Page 12 Page 11 • A fully and correctly completed guarantee card must be sent at least 6 weeks after buying the glider to ICARO paragliders commercial. Alternatively, can this be sent via the appropriate online form on www.icaro-paragliders.com. What is excluded from guarantee? •...
- Page 13 Page 12 If the rescue equipment has been independently verified, then from this point on the warranty and sample inspection are excluded. The same applies when selling the devices. The inspection must be noted on the device next to the type plate with the corresponding verification stamp.
-
Page 14: Annex
Page 13 ANNEX Checksheet for rescue systems Client (Name, Address): Type / size / year of construction: Serial number: Certification number: Date of last inspection: Memos Was an emergency tripping necessary? Where did you land after this emergency tripping? Necessary repairs? Was there a splashdown? Visible damages? Any dirt on the canopy?
