SRP4x4
STANDARD RELEASE PANEL
OPERATING & MAINTENANCE MANUAL
An ISO 9001:2008 Registered Company
APPROVED

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRP4x4 and is the answer not in the manual?

Questions and answers

Related Manuals for Protectowire SRP4x4

Summary of Contents for Protectowire SRP4x4

  • Page 1 SRP4x4 STANDARD RELEASE PANEL OPERATING & MAINTENANCE MANUAL An ISO 9001:2008 Registered Company APPROVED...
  • Page 2 Model Number, Drawing Number and Serial Number. This product information is recorded on the Panel Identification Label located inside the control panel. Please have this information available before call- ing your Authorized Protectowire Distributor or the Factory.

  • Page 3: Table Of Contents

    Table of Contents General Information & Panel Specification Company Information / Publishing Date .................... 2 Notice & Warnings..........................3 System Description & Features......................4 Systems Specifications........................5 - 6 Enclosure Information Enclosure Dimensions........................7 - 9 Panel Mounting........................... 10 Battery Cabinet Mounting........................11 Wiring Wire Routing Detail (Power Limited vs Non-Power Limited)............

  • Page 4: Company Information / Publishing Date

    The Protectowire Co., Inc. 60 Washington Street, Pembroke, MA U.S.A. 02359-1833 Telephone: 1-781-826-3878 Fax: 1-781-826-2045 WWW.PROTECTOWIRE.COM Model SRP-4x4 Standard Release Panel Operating & Maintenance Manual Man-2002 Rev. C Publish Date 08-04-2016...

  • Page 5: Notice & Warnings

    ALL POWER PRIOR TO SERVICING SYSTEM. CAUTION The Protectowire Co., Inc. designs and manufactures fire protection systems to meet both UL and FM Global criteria for electrical transients introduced on both the power supply side of the system and into the panel from field wiring for initiating device circuits, notification appliance circuits, and other external field routed wiring.

  • Page 6: System Description & Features

    Standard Initiating Device Circuits Compatible with the following: a. Up to 10,000 Feet (3,048m) of Protectowire type PHSC linear heat detector. b. Up to 5 (0.045mA) Hochiki smoke detectors. c. Any combination of Normally Open contact initiating devices.

  • Page 7: Systems Specifications

    SPECIFICATIONS Housing Type: 16 gauge steel. Door: Piano Hinged, lockable. Dimensions: 20 1/2” x 14 1/4” x 4 3/4” Finish: Red enamel with red, black and white logo/label. Knockouts: Minimum of one 1/2” and two 3/4” knockouts on each side, top and bottom. Visual Indicators (Visible LED’s with door closed) AC-ON: (1) Green...
  • Page 8 SPECIFICATIONS (continued) Output Circuit (4 TOTAL) (ALARM INDICATING, RELEASING, SUPERVISORY AND TROUBLE BELL) 4 Supervised Notification Appliance Circuits (NAC) Class B, reverses polarity on alarm (Optional Class A Module: AM-91-2). Maximum line loss not to exceed 1.0 Volts or 1 Ohm fully loaded. Power-limited, each circuit has self-resetting type fuse (PTC).
  • Page 9 1.06 14.12...

  • Page 10: Enclosure Dimensions

    ENCLOSURE DIMENSIONS IMPORTANT: The stated dimensions are for the enclosure back box only and do not account for the overall dimen- sions of the enclosure with the door installed. To account for the enclosure door and hinges add an additional 0.4” to the back box width &...
  • Page 11 ENCLOSURE DIMENSIONS 0.64 14.40 20.40 DOOR FRONT/SIDE VIEW...

  • Page 12: Panel Mounting

    PANEL MOUNTING - Panel shall be located in a clean, dry, vibration free environment. Panel shall not be OUT. DISC. TROUBLE ALARM ALARM TROUBLE SUPVISRY GENERAL ZONE subjected to extreme temperatures or humidity. OUTPUT ZONE FIRE CONTROL OUTPUT ZONE PANEL BATT TRO OUTPUT ZONE...

  • Page 13: Battery Cabinet Mounting

    BATTERY CABINET MOUNTING SRP-4X4 FIRE CONTROL PANEL SRP-4X4 FIRE CONTROL PANEL - The Battery Cabinet should be mounted directly below the SRP-4x4 Panel. The Battery wiring is classified as Non- Power-Limited. Therefore the wiring must be segregated from Power-Limited wiring with a minimum of two cable TRANSFORMER AC INPUT PUSH TO READ ALARM POINT...

  • Page 14: Wire Routing Detail (Power Limited Vs Non-Power Limited)

    SRP-4x4 Fire Alarm Control Panel Typical Panel Wire Routing Detail When bringing field wires to and from the control panel you must maintain segregation between Power Limited and Non-Power Limited wiring. Use the illustration below as a guideline for routing wire within the system enclo- sure.

  • Page 15: Wire Size Estimator

    ALARM NOTIFICATION APPLIANCE CIRCUIT WIRE SIZE ESTIMATOR To insure that all notification appliance circuits will be supplied with adequate power to operate, it is necessary to use the correct size cable for the distance and current requirements of each circuit. Follow the steps below to calculate the correct wire size for your application.

  • Page 16: Field Wiring (Initiating Device Circuits)

    CLASS A (NFPA STYLE D) / CLASS B (NFPA STYLE B) Use the following compatible devices approved by The Protectowire Co., Inc. - UP TO 10,000 FEET OF PROTECTOWIRE (May be placed after last detector) - UP TO (5) 0.045mA TWO-WIRE HOCHIKI SMOKE DETECTORS NOTES: Maximum feed cable resistance = 100 OHMS to last smoke detector.

  • Page 17: Field Wiring (Nac & Solenoid Release Circuits)

    FIELD WIRING SUPERVISED ALARM NOTIFICATION, SOLENOID RELEASE CIRCUITS & NON-SUPERVISED AUXILIARY 24V USAGE NOTE: OUTPUT CIRCUIT #1 USED FOR NOTIFICATION PURPOSES ONLY WHILE OUTPUT CIRCUITS #2 thru #4 MAY BE USED FOR EITHER NOTIFICATION AND/OR RELEASING NOTES: Output circuits OP1 thru OP4 are all power-limited circuits and must be segregated from non-power-limited circuits with a minimum spacing of two cable entry openings and 1/4”...

  • Page 18: Alarm Point Location Meter (Pdm-1000-4)

    When an alarm signal is received at the main control panel, depress the meter switch (see illustration below) of the zone in alarm. The meter will then display the distance to the actuated portion of the PROTECTOWIRE line heat detector circuit.

  • Page 19: Auxiliary Relay Module (Rb-4)

    RB-4 AUXILIARY RELAY MODULE Description - Auxiliary signaling relays are often needed to provide an interface to other systems for annunciation and/or electrical shutdown. The RB-4 Relay Module provides 4 individually zone activated sets of Form “C” contacts in one module. Operation - The RB-4 relays are normally de-energized.

  • Page 20: Class A Alarm Notification Module (Am-91-2)

    CLASS “A” ALARM NOTIFICATION APPLIANCE CIRCUIT ADAPTER Description: The AM-91-2 Alarm Notification Appliance Circuit Adapter Module converts the two Class B system Alarm Notification Appliance Circuits from the Main Board to Class A type circuits. This provides four wire alarm notification appliance circuits in lieu of the standard 2 wire circuits.

  • Page 21: Installation Test & Maintenance

    SRP 4x4 STANDARD RELEASE PANEL INSTALLATION, TESTING & MAINTENANCE Installation & System Power Up. 1. Carefully unpack system and inspect for any visual damage from shipping. Bench testing of panel for proper operation prior to installation is recommended. 2. Mount the system in a clean, easily accessible, stable area with four (4 ) 1/4” screws. The system enclosure should be mounted to allow clear visibility of the systems control indicators and easy access to the systems control switches.
  • Page 22 SRP 4x4 STANDARD RELEASE PANEL INSTALLATION, TESTING & MAINTENANCE Testing and Maintenance Quarterly testing is advised to help insure system controls are functioning properly. Testing should be per- formed by competent personnel having jurisdiction over the protective signaling system. The following instruc- tions should be observed in conjunction with the System Operational Outline contained in this manual when testing this equipment.
  • Page 23 SRP 4x4 STANDARD RELEASE PANEL INSTALLATION, TESTING & MAINTENANCE Operational Outline: 1. Normal Standby Condition a) “AC ON” Indicator (Green) illuminated. 2. Power Supervision AC power source failure: a) “AC ON” Indicator (Green) OFF. b) System trouble buzzer ON - Press “SYSTEM SILENCE” button to silence. c) “SYSTEM TROUBLE”...
  • Page 24 SRP 4x4 STANDARD RELEASE PANEL INSTALLATION, TESTING & MAINTENANCE Operational Outline Continued: 5. Switch Supervisory Zone Continued Open in Switch Supervisory Circuit - Supervisory Trouble/System Trouble: a) “SYSTEM TROUBLE” Indicator (Yellow) ON. b) “SUPERVISORY TROUBLE” Indicator (Yellow) ON. c) System trouble buzzer ON - Press “SYSTEM SILENCE” button to silence. d) Repair Open to return to standby condition.

  • Page 25: Troubleshooting

    SRP 4x4 STANDARD RELEASE PANEL TROUBLESHOOTING BASIC TROUBLESHOOTING GUIDE FOR THE SRP 4x4 STANDARD RELEASE PANEL INDICATOR STATUS FAULT CONDITION COURSE OF ACTION ALTERNATE ACTION “AC ON” Indicator OUT AC Power source failure Check AC power source Check secondary voltage “SYS.
  • Page 26 SRP 4x4 STANDARD RELEASE PANEL TROUBLESHOOTING CONTINUED BASIC TROUBLESHOOTING GUIDE FOR THE SRP 4x4 STANDARD RELEASE PANEL INDICATOR STATUS FAULT CONDITION COURSE OF ACTION ALTERNATE ACTION “AC ON” Indicator ON Short in zone circuit field Class B - Remove the If the circuit does not clear “SYS.

  • Page 27: Wire Diagram Program Chart

    SINGLE RELEASE, THREE ALARM ZONES WITH ONE WATERFLOW ZONE AND SUPERVISORY ZONE WITH SYSTEM TROUBLE/ SUPERVISORY BELL CIRCUIT & WATER VALVE FLOW TAMPER 8.2K 8.2K MANUAL STATION PROTECTOWIRE 8.2K 8.2K 8.2K LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY ON LOOP RETURN EARTH GROUND - GREEN WIRING OBSERVE POLARITY...
  • Page 28 WITH SYSTEM TROUBLE/SUPERVISORY OUTPUT BELL CIRCUIT ZONES 1 & 2 CROSS-ZONED & WATER VALVE FLOW TAMPER MANUAL 8.2K 8.2K STATION PROTECTOWIRE 8.2K 8.2K 8.2K LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY ON LOOP RETURN EARTH GROUND - GREEN WIRING OBSERVE POLARITY...
  • Page 29 ONE WATERFLOW ZONE, AND ONE SUPERVISORY ZONE WITH SYSTEM TROUBLE/SUPERVISORY OUTPUT BELL CIRCUIT & WATER VALVE FLOW TAMPER MANUAL 8.2K 8.2K STATION PROTECTOWIRE 8.2K 8.2K 8.2K LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY ON LOOP RETURN EARTH GROUND - GREEN WIRING...
  • Page 30 ONE WATERFLOW ZONE, AND TWO SUPERVISORY ZONES WITH SYSTEM TROUBLE/SUPERVISORY OUTPUT BELL CIRCUIT SUPV. & VALVE WATER TAMPER SUPV. FLOW 8.2K 8.2K PROTECTOWIRE 8.2K 8.2K 8.2K LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY MANUAL STATION ON LOOP RETURN EARTH GROUND - GREEN...
  • Page 31 SINGLE RELEASE WITH TROUBLE BELL - TWO ALARM ZONES,1 MANUAL PULL STATION ZONE, ONE WATERFLOW ZONE, AND ONE SUPERVISORY ZONE & WATER VALVE FLOW TAMPER 8.2K 8.2K MANUAL STATION PROTECTOWIRE 8.2K 8.2K 8.2K LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY ON LOOP RETURN EARTH GROUND - GREEN WIRING...
  • Page 32 ONE WATERFLOW ZONE AND TWO SUPERVISORY ZONES WITH SYSTEM TROUBLE/SUPERVISORY OUTPUT BELL CIRCUIT SUPV. SUPV. VALVE WATER TAMPER FLOW 8.2K 8.2K PROTECTOWIRE 8.2K 8.2K 8.2K LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY MANUAL STATION ON LOOP RETURN EARTH GROUND - GREEN...
  • Page 33 WITH OUTPUT CKT AND TWO SUPERVISORY ZONES WITH SYSTEM SUPERVISORY/TROUBLE BELL CIRCUIT ZONES 1 & 2 CROSS-ZONED VALVE WATER TAMPER FLOW 8.2K 8.2K PROTECTOWIRE 8.2K 8.2K 8.2K LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY ON LOOP RETURN EARTH GROUND - GREEN...
  • Page 34 ONE MANUAL STA. ZONE, ONE WATERFLOW ZONE, AND ONE SUPERVISORY ZONE WITH SUPERVISORY/TROUBLE BELL OUTPUT ZONES 1 & 2 CROSS-ZONED WATER VALVE FLOW TAMPER MANUAL 8.2K STATION PROTECTOWIRE 8.2K 8.2K 8.2K 8.2K LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY ON LOOP RETURN EARTH GROUND - GREEN...
  • Page 35 TRIPLE, SPLIT RELEASE, THREE ALARM (IDC) ZONES, ONE WATERFLOW ZONE AND ONE SUPERVISORY ZONE SUPV. & VALVE WATER TAMPER FLOW 8.2K 8.2K 8.2K PROTECTOWIRE 8.2K 8.2K LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY MANUAL STATION ON LOOP RETURN EARTH GROUND - GREEN WIRING...
  • Page 36 ZONES 1 & 2 ZONES 3 & 4 CROSS-ZONED CROSS-ZONED & VALVE TAMPER 8.2K 8.2K 8.2K 8.2K PROTECTOWIRE 8.2K LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY ON LOOP RETURN EARTH GROUND - GREEN WIRING OBSERVE POLARITY NEUTRAL - WHITE WHEN CONNECTING SMOKE DETECTORS YEL.
  • Page 37 WITH SYSTEM TROUBLE/SUPERVISORY BELL OUTPUT CIRCUIT ZONES 1 & 2 CROSS-ZONED VALVE WATER TAMPER MANUAL FLOW 8.2K STATION 8.2K 8.2K PROTECTOWIRE 8.2K 8.2K LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY ON LOOP RETURN EARTH GROUND - GREEN WIRING OBSERVE POLARITY NEUTRAL - WHITE...
  • Page 38 WIRING DIAGRAM PROGRAM #13 DUAL COMBINED RELEASE, TWO ALARM (IDC) ZONES, EACH CROSS-ZONED WITH A LOW AIR ZONE, AND ONE SUPERVISORY ZONE WITH SYSTEM TROUBLE/SUPERVISORY BELL OUTPUT CIRCUIT VALVE TAMPER 8.2K 8.2K PROTECTOWIRE 8.2K 8.2K 8.2K LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY...
  • Page 39 WIRING DIAGRAM PROGRAM #14 DUAL SPLIT RELEASE, TWO ALARM (IDC) ZONES, EACH CROSS-ZONED WITH A LOW AIR ZONE, ONE SUPERVISORY ZONE AND SYSTEM TROUBLE/SUPERVISORY BELL OUTPUT CIRCUIT VALVE TAMPER 8.2K 8.2K PROTECTOWIRE 8.2K 8.2K 8.2K LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY...
  • Page 40 WIRING DIAGRAM PROGRAM #15 FOUR ALARM (IDC) ZONES WITH INDIVIDUAL ZONE ALARM OUTPUT (NAC)S & VALVE TAMPER 8.2K 8.2K 8.2K 8.2K PROTECTOWIRE 8.2K LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY ON LOOP RETURN EARTH GROUND - GREEN WIRING OBSERVE POLARITY NEUTRAL - WHITE...
  • Page 41 WIRING DIAGRAM PROGRAM #16 FOUR ALARM (IDC) ZONES WITH FOUR (NAC) GENERAL ALARM OUTPUTS & VALVE 8.2K 8.2K 8.2K 8.2K TAMPER 8.2K PROTECTOWIRE LINEAR HEAT DETECTOR TRANSFORMER OBSERVE POLARITY ON LOOP RETURN EARTH GROUND - GREEN WIRING OBSERVE POLARITY NEUTRAL - WHITE...

  • Page 42: Battery Calculations

    2.2K resistor. If voltage across resistor is 27 Volts then the batteries need to be replaced. If voltage across resistor is less than 26 volts contact Protectowire. If the batteries show any visual defects of swelling, cracking or severe corrosion then they should be replaced immediately. Life expectancy is typically 3-5 years, to...

  • Page 43: Panel Instructions (Tearout)

    OINT OCATION ETER Press and hold to read distance (ft/m) to alarm actuation point of Protectowire zone in Alarm. Switches METER READ read from left to right with Zone 1 (first pushbutton), Zone 2 (second pushbutton), Zone 3 (third push-...
  • Page 45 APPENDIX A The following Smoke Detectors/ Solenoids / Notification Appliance Circuits (NAC’s) are all approved by UL for use in the SRP-4x4 Unless otherwise noted. UL Compatibility Identifier for smoke detectors are listed under SRP. Per UL 864 9th edition stipulation has been added that two wire smoke detectors of different models are not to be mixed or matched on a system.
  • Page 46 APPENDIX A (continued) Per listing Agencies (UL / FM) only approved and tested 24 Volt Notification Appliance Circuits (NAC) can be installed on the SRP-4x4 Fire Control Panel. The following NAC devices are listed for use on the SRP-4x4 Panel. Per UL listing, Output Circuit 1 has a maximum output rating of 1 Amp FWR.
  • Page 47 APPENDIX A (continued) Important: consult manufacture cut-sheet for actual current draw - Indicates Field Selectable Device NAC Type Model / Series Average Current *RSD24-75110 .250 Amps *RSD24-153075 Strobe Light Retrofit .114 Amps AMESCO *RSB24-153075 RSD24-110 .200 Amps TMP1-3A Temporal Module .025 Amps SMS1-3A Synchronization Module...
  • Page 48 The Protectowire Company, Inc. 60 Washington Street, Pembroke, MA 02359 U.S.A. p:781-826-3878 f:781-826-2045 web: www.protectowire.com email: pwire@protectowire.com MAN2002C-1116 (1C) SPECIAL HAZARD FIRE DETECTION SYSTEMS...
