Summary of Contents for Hussmann Chino TY3
- Page 1 T Y 3 , T Y 4 ( E N T Y C E ) ISLAND CASE SELF-CONTAINED I N S T A L L A T I O N & O P E R A T I O N G U I D E...
-
Page 2: Table Of Contents
Table of Contents General Information Cut and Plan Views Spec Sheet Installation Close‐off Removal Lifting Instructions Electrical Electrical Wiring Diagram Index Wiring Daigrams Program Parameters Danfoss Controller Manual Dixell Controller Manual... - Page 3 1. Do Not Push, Pull, Adjust, or Manipulate the Entyce case by any glass compone.nt • Doing so will result in severe damage to such components • Glass or Acrylic Breakage may result in serious injury • See lifting and transport instructions for proper moving technique ref.
-
Page 5: General Information
Shortages: Check your shipment for any possible shortages of material. If a shortage should exist and is found to be the responsibility of Hussmann Chino, notify Hussmann Chino. If such a shortage involves the carrier, notify the carrier immediately, and request an inspection. Hussmann Chino will acknowledge shortages within ... -
Page 6: Cut And Plan Views
Cut and Plan Views TY3-4 TY-4 4' wide Merchandiser 4' wide Island Merchandiser base panels base rails (572) Optional Drain black “B” (203) angled (54) “A” (314) shelf (619) Elec Inserts (254) (1257) (594) 1/8 (54) Refrig “A” (314) “B”... - Page 7 TY3-3 3' wide Merchandiser “A” (25) 1/2 (826) (968) Angled Shelf Insert “B” -optional (254) (1464) (918) (254) (616) open to oor (724) (483) Shelves - optional (298) base close-o (740) (695) (152) (514) 4.5' 5.5' “A” 1/2 (1384) 1/2 (1689) 1/2 (724) “B”...
-
Page 8: Spec Sheet
SELF-SERVICE DELI REVISION DATE 07/09/20 HUSSMANN - TY3-3 E-END SELF-CONTAINED (CHINO) REFRIGERATION DATA: CONVENTIONAL AVERAGE DISCHARGE VELOCITY CAPACITY *** AIR** (°F) (SEE CASE LENGTHS CASE USAGE (FT/MIN) (BTU/HR/FT) SETPOINTS BELOW) 4.5E, 5.5E DELI 1750 28~32 125~175 **FRONT DISCHARGE AIR MEASURED INSIDE AIR CURTAIN HONEYCOMB... - Page 9 SELF-SERVICE DELI REVISION DATE 07/09/20 HUSSMANN - TY3-4 I-ISLAND, E-END SELF-CONTAINED (CHINO) REFRIGERATION DATA: AVERAGE CONVENTIONAL DISCHARGE AIR* VELOCITY (°F) CAPACITY ** CASE LENGTHS CASE USAGE (FT/MIN) (SEE SETPOINTS (BTU/HR/FT) BELOW) 6I, 8I, 10I, SS DELI 1500 32~36 125~175 4E, 6E, 8E...
- Page 10 SELF-SERVICE DELI CHEESE REVISION DATE 09/30/19 HUSSMANN - TY3-5-SC (CHINO) REFRIGERATION DATA: EST. AVERAGE REFG. DISCHARGE AIR* CASE CONVENTIONAL VELOCITY CHRG. LENGTHS (°F) CAPACITY ** CASE LENGTHS CASE USAGE (FT/MIN) (LBS) (SEE SETPOINTS (BTU/HR) BELOW) SS DELI 12,385 29~33 125~175...
- Page 11 SELF-SERVICE DELI / PRODUCE REVISION DATE 10/09/19 HUSSMANN - TY3-6 I-SC (CHINO) REFRIGERATION DATA: CONVENTIONAL AVG DISCHARGE DEFROST VELOCITY CAPACITY AIR* (°F) WATER CASE LENGTHS CASE USAGE (FT/MIN) (BTU/HR/FT) (LBS/DAY/FT) (SEE SETPOINTS) SS DELI 1840 28~32 100~150 *FRONT DISCHARGE AIR MEASURED INSIDE AIR CURTAIN HONEYCOMB...
- Page 12 SELF- S E R V I C E DELI T Y P E I R E V I S I O N DATE 10/09/19 HUSSMANN - TY4-4 I-ISLAND, E-END SELF-CONTAINED (CHINO) R E F R I G E R AT I O N DATA: AV E R AG E CONVENT ION AL D I S C H AR G E AIR*...
- Page 13 SELF-SERVICE DELI TYPE II REVISION DATE 10/09/19 HUSSMANN - TY4-4 I-ISLAND, E-END SELF-CONTAINED (CHINO) REFRIGERATION DATA: CONVENTIONAL DISCHARGE AIR * VELOCITY CASE LENGTHS CAPACITY ** (°F) (SEE CASE USAGE (FT/MIN) (BTU/HR/FT) SETPOINTS BELOW) 6I,8I,10I DELI 2300 28~32 100~150 4E,6E,8E DELI 1950 28~32 100~150...
-
Page 14: Installation
Installation Store Conditions Do Not Install the Vented Panels of the self-contained model against a wall or • Case is designed to operate at temperatures at either 75°F at at 55% relative humidity or 80°F at 55% rela- other storage fixture. tive humidity. - Page 15 Figure1 Figure2 Clearances Minimum Clearances for Self-Contained cases are to be followed as instructed for proper placement inside store locations. - Intake and exhaust clearances are to be a minimum of 8’ when placed next to a solid wall. - Height clearance measured from floor follows as a minimum of 10’ vertically. - Minimum of 36”...
-
Page 16: Close-Off Removal
Close‐off Removal Step 1 Slide bottom of close-off in upward motion to remove from tabs. Step 2 Pull Close-off in outward then downward motion to completely remove side panel close-off Step 3 Once side panel close-off has been removed from case four screws will be visible which fasten the round close-off to the case. -
Page 17: Lifting Instructions
Lifting Instructions Entyce Lifting and Transport Instructions Lift Zone Jack Points J-Bar Zone 34.42 Dollies under each Base Leg 72.68 1. The Entyce can be lifted by a forklift only at the specified location in the diagram WARNING Improper placement of forks may damage drainage piping. - Page 18 8. If using J-Bars, use the specified jacking points to raise the case • Raise one side of the case first. • Use as many J-Bars as possible to lift from the base channels • A minimum of 2 J-Bars is required •...
- Page 19 Do not Jack or lift at any point J-Bar lift points 8. If using J-Bars, use the specified jacking points to raise the case • Raise one side of the case first. • Use as many J-Bars as possible to lift from the base channels •...
-
Page 20: Electrical
Electrical Field Wiring and Serial Plate Amperage Standard Case Wire Color Code Field Wiring must be sized for component amperes printed on the serial plate. Actual ampere draw may be less Color Decsription Color than specified. Field wiring from the refrigeration control Ground Green panel to the merchandisers is required for refrigeration... -
Page 21: Electrical Wiring Diagram Index
Electrical Wiring Diagram Index TY3-SELF CONTAINED TY3-3X4.5E-S 4.5' 3043372 DAN FOSS TY3EC-3X4.5E-S 4.5' 3047158 TY3EC-3X5.5E-S 5.5' 3058910 TY3-3X4.5E-S 4.5' 3062195 TY3-4X4E-S HARRIS TEETER ONLY 3043374 TY3-4X4E-S W/PARKING LOT 3070437 TY3-4X6E-S 3043375 TY3-4X6I-S 3043378 TY3-ECSQ-4X6I-S 3040191 TY3-4X8I-S 3043379 TY3-4 X 8E-S 3102623 TY3-4X10I-S 3043380... -
Page 22: Wiring Daigrams
Electrical Wiring Diagram Index (Cont’d) DIXELL CTRL TY3-3X4.5-S W/XR75 CTLR 4.5' 3157238 TY3EC-3X4.5E-S W/XR75 CTLR 4.5' 3168381 TY3-3X5.5-S W/XR75 CTLR 5.5' 3157241 TY3ECRC-4X6E-S W/XR75 CTLR 3157152 TY3ECSQ-4X6I-S W/XR75 CTLR 3156421 TY3-4X4E-S W/XR75 CTLR 3160998 TY3-4X6I-S W/XR75 CTLR 3158087 TY3-4X8I-S W/XR75 CTLR... -
Page 69: Program Parameters
Parameter Programmed Report PGM0010A01 PGM0010A02 TANDARD CASE REV B 9/6/1 Sheetz REV B 9/21/17 Parameter Code Default Actual (°C) Actual (°F) Actual (°C) Actual (°F) Temperature (set point) Deli (Type I) -50.0°C 50.0°C 2.0°C -3.3 -5.0 Deli (Deli Type II) -50.0°C 50.0°C 2.0°C... - Page 70 Parameter Programmed Report Real time clock Six start times for defrost. t01-t06 0 hours 23 hours 0 hours 0 hours 0 hours Setting of hours. 0=OFF t11-t16 0 min 59 min 0 min 0 min 0 min Six start times for defrost. Setting of minutes.
- Page 71 August 31, 2018 This warning does not mean that Hussmann products will cause cancer or reproductive harm, or is in violation of any product-safety standards or requirements. As clarified by the California State government, Proposition 65 can be considered more of a ‘right to know’...
-
Page 72: Danfoss Controller Manual
Danfoss Controller User Guide Controller for temperature control AK-CC 210 ADAP-KOOL® Refrigeration control systems Open Camera IPhone User Hold the camera up to the QR code Android User Open QR Code Reader app if necessary. Hold the camera up to the QR code Tap the notification to be taken to the destination of the QR code... -
Page 73: Dixell Controller Manual
Dixell Controller 026-1210 Rev 3 03-FEB-2015 XR75CX Digital Controller for Medium‐Low Temperature Refrigeration Applications Installation and Operation Manual Open Camera IPhone User Hold the camera up to the QR code Android User Open QR Code Reader app if necessary. Hold the camera up to the QR code Tap the notification to be taken to the destination of the QR code... - Page 74 Maintenance Case Cleaning • DO NOT USE A CLEANING OR SANITIZING SOLU- TION THAT HAS AN OIL BASE (these will dissolve the To insure long life, proper sanitation and minimum butyl sealants) or an AMMONIA BASE (this will corrode maintenance costs, the refrigerator should be thoroughly the copper components of the case) cleaned frequently.
- Page 75 Service Tips WARNING ALWAYS DISCONNECT THE ELECTRICAL POWER AT THE MAIN DISCONNECT WHEN SERVICING OR REPLACING ANY ELECTRICAL COMPONENT OF THIS REFRIGERATOR. THIS INCLUDES, BUT IS NOT LIMITED TO SUCH ITEMS AS FANS AND THERMOSTATS. Fan Blade Replacement 3) Install honeycomb by inserting the notched side up against the deflector and press upwards inserting the bottom The evaporator fan is located directly under the deck pan.
- Page 76 User Information Stocking Case Cleaning Improper temperature and lighting will cause serious Long life and satisfactory performance of any equipment are product loss. Discoloration, dehydration and spoilage can be dependent upon the care given to it. To insure long life, proper controlled with proper use of the equipment and handling of sanitation and minimum maintenance costs, the refrigerator product.
- Page 77 Service Record Last service date: /Chino The MODEL NAME and SERIAL NUMBER is required in order to provide you with the correct parts and information for your particular unit. Additional copies of this publication may be obtained by contacting: They can be found on a small metal plate on the unit. Hussmann®...
