Venta LW15 User Manual
  1. Manuals
  2. Brands
  3. Venta Manuals
  4. Humidifier
  5. LW15
  6. User manual

Venta LW15 User Manual

Hide thumbs Also See for LW15:
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
RE AD AND SAVE THESE
IMPORTANT INSTRUCTIONS
QUESTIONS?
SUPPORT HOTLINE
888-333-8218
V E N T A
O R I G I N A L
H U M I D I F I E R
L W 1 5 / L W 2 5 / L W 4 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LW15 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Venta LW15

Summary of Contents for Venta LW15

  • Page 1 USER MANUAL RE AD AND SAVE THESE IMPORTANT INSTRUCTIONS QUESTIONS? SUPPORT HOTLINE 888-333-8218 V E N T A O R I G I N A L H U M I D I F I E R L W 1 5 / L W 2 5 / L W 4 5...

  • Page 2: Table Of Contents

    VENTA HUMIDIFIER USER MANUAL ORIGINAL HUMIDIFIER MODELS LW15, LW25, LW45 CONTENTS Important safeguards ----------------------------------------------------------------------------------3 Easy Setup Guide ----------------------------------------------------------------------------------------4 Parts List ------------------------------------------------------------------------------------------------9 Maintenance and Cleaning ------------------------------------------------------------------------10 Additional Products -----------------------------------------------------------------------------------11 Additional Information -------------------------------------------------------------------------------13 Troubleshooting ----------------------------------------------------------------------------------------14 ----------------------------------------------------------------------------------------------------------15 Servicing Your Humidifier --------------------------------------------------------------------------- 17 Warranty --------------------------------------------------------------------------------------------------------20...

  • Page 3: Important Safeguards

    Aromatherapy, or before moving/handling the unit. • Plug into 110-120 V AC outlet only. Do not use your humidifier if the power supply or plug is damaged. Do not replace a damaged power supply or plug. Only Venta may replace the power supply or plug.

  • Page 4: Easy Setup Guide

    1. UNPACKING First things first, remove bottle(s) of Water Treatment Additive from the corner of your packaging (one sample bottle for LW15/ LW25 models, two sample bottles for LW45 models). Keep these handy as you’ll need them in a bit. Unpack your humidifier setting the Styrofoam aside.
  • Page 5 Lift the motor out of the housing, remove the power cable, and set it aside for a mo- ment. Inside of one of the panels is a sticker with the serial number on it. Write this number down as you’ll need it later! 3.
  • Page 6 Undo the tie holding the power cord and place the upper hous- ing on the lower housing, guiding the power cord out through the slot provided. Please contact Venta Air Technologies Inc. at 888-333-8218 or info-us@venta-air.com if there is any damage to your unit. 5. SET IT UP Now it’s time to set up the humidifier.
  • Page 7 Remove the upper housing from the lower housing and set it aside for a moment. Take the lower housing over to your sink/bathtub/water source and fill it with regular tap water up to the water line. Remember the bottle(s) of Water Treatment Additive? Go grab those and pour them into the water in the lower housing.
  • Page 8 • Cleaning of disc stack(s): If a dishwasher isn’t an option, cleaning the disc stack(s) can be done by soaking disc stack(s) in hot water with Venta Cleaner or white vinegar for approx. 30 minutes. This will help loosen any buildup of calcium or lime that may have accrued.

  • Page 9: Parts List

    MAIN COMPONENTS Disc Stack Handle Lower Housing Upper Housing Disc Stack Water Level Sensor Strip Gear Teeth Gear Support Gear Gear Support Rubber Coupling Mounting Ring Fan Blade Power Button Power Level Power Adjustment Button Continuous Lighting: On No lighting: Off Flashing: Fault Low Water (See Eliminating Faults)

  • Page 10: Maintenance And Cleaning

    EVERY 10-14 DAYS Rinse the lower housing and disc stack(s) with warm water. Wipe lower housing and fan blade with a soft cloth. Recharge with the recommended dose of Venta Water Treatment Additive and fresh tap water. TWICE A YEAR Use the Venta Cleaner periodically to thoroughly clean the Venta Humidifier.

  • Page 11: Additional Products

    This will deactivate the additive. In cases when all water has evaporated, Venta WTA remains in the lower housing – it does not evaporate (like salt in sea wa- ter). Simply add more tap water and the WTA will activate. Venta Air Technologies Inc.
  • Page 12 Venta Cleaner is recommended for use with the Venta Humidifier and Venta Airwashers only. Shelf life when stored in a cool location away from sunlight: 30 months. After opening, use within 12 months. Venta Cleaner is not suitable for ultrasonic, heat vaporizing, or atomizing-type vaporizer humidifiers.Venta Cleaner is not intended to be used with detergents, cleaning agents, or other chemicals.

  • Page 13: Additional Information

    ADDITIONAL INFORMATION Technical data LW15 LW25 LW45 Colors black, white For rooms up to 300 sq.ft. 430 sq.ft. 600 sq.ft. Water hygiene Water Treatment Additive Power levels Noise level (level 1-3) 22/32 dBA 24 / 34 / 44 dBA 24 / 35 / 45 dBA Power consumption (level 1-3) 3 / 4 Watt...

  • Page 14: Troubleshooting

    TROUBLESHOOTING Problem Possible causes What to do Appliance does not 1. Power supply not 1. Connect switching power function connected. supply to main socket, 2. Cable connector not switch on appliance. plugged in and latched 2. Plug main cable connec- into drive unit.

  • Page 15: Faq

    WHERE IS THE BEST PLACE FOR THE VENTA HUMIDIFIER? If possible, the Venta Humidifier should be placed in the center of the room, or along a wall away from windows and a heat source. When using your Venta Humidifier for multiple rooms (larger model Venta Humidifiers) it should be placed centrally between rooms.
  • Page 16 In addition, the WTA helps improve the efficiency of the Venta Humidifier by allowing the water to sheet on the disc stack(s) instead of “beading” up, allowing maximum use of every square inch of the disc stack(s).

  • Page 17: Servicing Your Humidifier

    SERVICING YOUR HUMIDIFIER CLEANING THE GEAR DO NOT submerge the gear in water. To clean any buildup of calcium or lime from the gear “teeth,” brush with a soft-bristled brush. The gear teeth should be pointed toward the floor while brushing, otherwise deposits will fall into the gear and cause it to malfunction.
  • Page 18 Fig 7. Remove the locking ring ... prying it up using a small screwdriver ... REPL ACING THE GE AR AND COUPLING A. Place the rubber coupling into the locking ring so the rubber feet from the coupling hang below the ring. When placing the coupling and ring on the center shaft of the fan, the rubber feet should line up with the notch marks on the fan.
  • Page 19 ADDITIONAL SERVICE OPTIONS If you prefer Venta to handle your concern, warranty repair, or if you wish to utilize the Ultrasonic Cleaning service for your Venta Humidifier for an additional fee, please call our customer support department toll-free at 888-333-8218 to obtain a Return Merchandise Authorization (RMA) number and to make payment.

  • Page 20: Warranty

    For product registration please submit online at https://www.venta-air.com/en_us/service/product-registration/. Venta warrants that for a 2 years from the date of purchase, this product will be free from defects in material and workmanship. Venta, at its option, will repair or replace this product or any mechanical parts of the product to be defective during the warranty period.
  • Page 21 Customer Support: Venta Air Technologies Inc., US Headquarters 1111 North Plaza Drive Suite 715 Toll Free: 1-888-333-8218 www.venta-air.com/en_us e-mail: info-us@venta-air.com...
