Summary of Contents for TNICER T5
- Page 1 HELMET BLUETOOTH HEADSET ＴＮＩＣＥＲ－ Ｔ５ Bluetooth...
-
Page 2: Product Introduction
FM radio and receiving GPS navigation voice prompts.Pro- vide you with a clear, safe and comfortable experience during the ride. TNICER T5 has the latest version 5.2 Bluetooth, stable system operation, dual intelligent noise cancellation, low power consumption, with 40MM high quality speakers and intelli- gent pickup microphone, support two devices connected to achieve two people intercom. -
Page 3: Function Description
Function Description •Qualcomm version 5.2 Bluetooth chip •Intelligent DSP audio processing, the 12th generation of CVC noise reduction processing, 16K voice bandwidth transmission rate •500m 2-way intercom Bluetooth headset •High pairing speed •Fast charging •3 EQ sound effects •Music sharing •Voice assistant •Automatic answer, support last dialed number redial •Intelligent microphone... - Page 4 Button Functions and Operations Power on/off Power on: Press and hold the [multi-function button + intercom button] for 3 seconds, the power-on prompt will sound, and the blue light will be on. Power off: Press and hold the [multi-function button + intercom button] for 3 seconds,the power off prompt sounds, and the red light is on.
-
Page 5: Music Control
Music Control ① Play/Pause: Intercom Bluetooth connection state, short press [multi-function button] to play music,short press [multi-function button] again to pause the music. ② Next song: Long press the [volume up button] for 2 seconds to select the next song. ③... -
Page 6: Pairing Operation
1.If you have connected to other phones, the blue light will flash slowly, please reset and turn on the device again. 2. Search for cell phone Bluetooth, select "Tnicer-T5" connection pairing, click to connect.When the pairing is successful, it will be accompanied by the voice prompt "device is connected", and the Bluetooth connection is successful. - Page 7 Pairing and intercom between headsets 1. Pairing and intercom between two Bluetooth intercoms (A,B) Active/passive pairing operation: 1) Turn on the two Bluetooth intercoms (A,B), press and hold the B intercom [multi-function button] for 3 seconds.At this time, red and blue lights alternately flashing, passive pairing mode on.
- Page 8 Voice assistant In standby state, short press [intercom button+ volume down button] to enter the voice assistant function.At this time, the blue light flashes slowly. Last number redial In standby mode, short press [Multi-function button] twice to redial the last number.
-
Page 9: Installation
Installation Method 1: Use double-sided adhesive pad Ｐｕｔ ｔｈｅ ｄｏｕｂｌｅ－ ｓｉｄｅｄ ａｄｈｅｓｉｖｅ ｐａｄ ｏｎ ｔｈｅ Ｈｅｌｍｅｔ ｍｏｕｎｔｉｎｇ ｂｒａｃｋｅｔ Ｄｏｕｂｌｅ ｓｉｄｅｄ ａｄｈｅｓｉｖｅ ｐａｄ Ｍｏｕｎｔｉｎｇ ｂｒａｃｋｅｔ Ｉｎｔｅｒｃｏｍ Ｐｕｔ ｔｈｅ ｍｏｕｎｔｉｎｇ ｂｒａｃｋｅｔ ｗ ｉｔｈ ｄｏｕｂｌｅ－ ｓｉｄｅｄ Ｓ ｎａｐ ｔｈｅ ｈｅａｄｓｅｔ ｉｎｔｏ ｔｈｅ ｍｏｕｎｔｉｎｇ ｂｒａｃｋｅｔ， ｔａｐｅ ｏｎ ｔｈｅ ｈｅｌｍｅｔ ｔｈｅ ｉｎｓｔａｌｌａｔｉｏｎ ｉｓ ｃｏｍｐｌｅｔｅ Attention: The microphone logo on the microphone plug needs to be inserted upwards,as shown in the picture:... - Page 10 Installation Method 2: Use metal clip Ａ ｄｈｅｒｅ ｔｈｅ ｓｉｎｇｌｅ－ ｓｉｄｅｄ ａｄｈｅｓｉｖｅ ｔｏ ｔｈｅ Ｈｅｌｍｅｔ ｍｏｕｎｔｉｎｇ ｂｒａｃｋｅｔ， ａｎｄ ｔｈｅｎ ｓｎａｐ ｔｈｅ ｍｅｔａｌ ｃｌｉｐ ｉｎｔｏ ｔｈｅ ｍｏｕｎｔｉｎｇ ｂｒａｃｋｅｔ． Ｓ ｉｎｇ ｌｅ Ｓ ｉｄｅｄ Ｍｅｔａｌ ｃｌｉｐ ａｄｈｅｓｉｖｅ ｐａｄ Ｍｏｕｎｔｉｎｇ ｂｒａｃｋｅｔ Ｉｎｔｅｒｃｏｍ Ｓ ｎａｐ ｔｈｅ ｈｅａｄｓｅｔ ｉｎｔｏ ｔｈｅ ｂａｓｅ， ｔｈｅ Ｐｕｔ ｔｈｅ ｍｅｔａｌ ｃｌｉｐ ｉｎｔｏ ｔｈｅ ｈｅｌｍｅｔ ｉｎｓｔａｌｌａｔｉｏｎ ｉｓ ｃｏｍｐｌｅｔｅ Quickly remove the Bluetooth headset from the helmet Unplug the headset cable first, and then press the middle of the metal clip fixing snap with one finger (push to the helmet side), make the metal clip and the device disconnect, while pushing up the device, let itslide out the metal clip smoothly...
- Page 11 T5 Package List Single-sided adhesive pad Mounting bracket Speaker & microphone Double-sided adhesive pad Speaker velcro Square velcro Charging cable Metal clip Manual Sponge Sticker 1.Bluetooth headset 7. Speaker velcro 2. Speaker & microphone 8. Sponge Sticker 3. Mounting bracket 9.
-
Page 12: Product Parameters
Product Parameters Working distance: 500m Bluetooth intercom for two riders Working frequency: 2.4GHz Bluetooth version: Bluetooth 5.2 Support Bluetooth protocol: HSP/HFP/A2DP/AVRCP Battery type: 600mAh rechargeable lithium polymer Standby time: 50 hours Talking time: 25 hours of cell phone talk/intercom Charging time: about 2 hours Power adapter: DC 5V 1A (optional) Charging interface: TYPE-C interface Operating temperature: 0℃-50℃... - Page 13 More installation and operation videos are available on our official Youtube channel. YouTube channel: TNICER After-sales service email: tnicerservice@tognicer.com If you have any questions, please feel free to contact us through the after-sales mailbox.
