IRIS/SIMPO Repeater
Addressable Fire Alarm Repeater Panel
Model: TFT
User Operation &
Maintenance Programming
Manual
Attention:
This manual contains information on limitations regarding product use and
function and information on the limitations as to liability of the manufacturer.
The entire manual should be carefully read.
The information in this manual is a subject to change without notice!
ver. 1.0.8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TFT and is the answer not in the manual?

Questions and answers

Related Manuals for Teletek electronics TFT

Summary of Contents for Teletek electronics TFT

  • Page 1 IRIS/SIMPO Repeater Addressable Fire Alarm Repeater Panel Model: TFT User Operation & Maintenance Programming Manual Attention: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read.

  • Page 2: Table Of Contents

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual Table of Contents 1. INTRODUCTION ................................ 4 1.1. General Description ........................... 4 1.2. Basic Operation Features .......................... 4 1.3. Model with TFT Screen ..........................4 1.4. Control Access Levels..........................4 2.
  • Page 3 The manufacturer shall not accept any product, of which no prior notice has been received via the RAN form at: http://teletek-electronics.com/en/ran- form The setup and programming included in the technical documentation shall not be regarded as defects. Teletek Electronics bears no responsibility for the loss of programming information in the device being serviced. CONDITIONS FOR WAIVING THE GUARANTEE This guarantee shall apply to defects in products resulting only from improper materials or workmanship, related to its normal use.

  • Page 4: Introduction

    Attention: The enclosure box is not waterproofed! Clean the plastic surface with a wet cloth only, and the TFT screen with cleaning sprays or foams containing no solvents (alcohol, acetone, ammonia, etc.).

  • Page 5: Panel Interface

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual 2. PANEL INTERFACE Attention: The factory default language is set into English. You can change the language only from the installer’s programming menus at access level 3! Ask you installer or support engineer for details.

  • Page 6: Events Reviewing

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual Type Icon Mode Description Standby Not activated Sounder outputs. Fault Not activated Sounder outputs; fault detected. Sounders Fire alarm Activated Sounder outputs. (loop devices, panel outputs*) Fire alarm Activated Sounder outputs in fault.
  • Page 7 IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual Only three fields for reviewing events can be displayed at the same time on the screen. If there are more type of events to review, then the User can use the buttons with arrows to scroll up and down the active fields. See the following examples: No events in the network.
  • Page 8 IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual In the messages list, can be reviewed up to three messages for events at the same time. If more events are active, the screen shows the newest (1), second and the oldest one. With the arrow buttons, the User can review the rest of the events scrolling up and down, as the numbers are displayed in the middle, between the newest and the oldest event.

  • Page 9: Main Functional Buttons

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual 2.4. Main Functional Buttons The action of the functional buttons is common at all Access Levels and programming menus. Button Color State Description blue Active Button for changing the User Access Level.

  • Page 10: Silencing Buzzer

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual The Main Screen at Access Level 1 and no active messages for events: At Access Level 1 and active messages for Faults and/or Disablement events, the Repeater will always automatically switch on from Main Screen to events list after 20 seconds.

  • Page 11: Starting Evacuation For Fire Alarm

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual 3.1.2 Starting Evacuation for Fire Alarm At Access Level 1 is possible to start immediate Evacuation in the site(s), only when the fire alarm signal is received from a fire detector in a zone.

  • Page 12: Silencing Buzzer

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual 3.2.1 Silencing Buzzer The process for silencing of the internal buzzer at Access Level 2/3 is the same as described at item 3.1.1. 3.2.2 Silencing Alarm In case of receiving of fire alarm event from other panels in the network, the Repeater will turn on automatically to the alarm events list, showing information for the fire alarm.

  • Page 13: Starting Evacuation For Fire Alarm

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual 3.2.4 Starting Evacuation for Fire Alarm At Access Level 2/3, the user can start immediate evacuation at the protected site(s) at any time, regardless if there are received fire alarm events from other panels or not.

  • Page 14: Logging Out

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual The entered code is visualized with asterisks. Confirm the code with OK button. Use the backspace button to delete entered digits and edit the code. In case the entered code is invalid, the panel will return to Main Screen without changing the Access Level.

  • Page 15: Maintenance Programming Menus

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual 4. MAINTENANCE PROGRAMMING MENUS At Access Level 2 are available for programming some menus for daily maintenance of the Repeater. To enter the Programming menus, press SYSTEM button from Main Screen: Press SYSTEM ( ) button.

  • Page 16: Setting Date

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual 4.2. Setting Date Enter MAINTENANCE menu. Enter DATE submenu. Use the up and down arrow buttons to set the date. You can also directly enter the new settings using the keyboard after selecting the digit button for year/month/day.

  • Page 17: Clear The Log Memory For Events

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual To filter the events by Date of occurrence press DATE button and in the new screen enter year/month/day for search. Press GO TO button. The View Log screen will return showing the last registered event for this date.
  • Page 18 IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual Earth Fault Resistive connection between some signals and earth < 10k. Charger Fault The charging unit is failed. Sounder1 Short Short circuit detected at Sounder 1 output.
  • Page 19 IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – User & Maintenance Manual Both main and backup power supply are lost (the main power supply is lost and the Total loss of Power accumulator battery is fully discharged). Buzzer Disabled The internal buzzer is disabled.
  • Page 20 www.teletek-electronics.com Address: Bulgaria, 1407 Sofia, 14А Srebarna Str. Tel.: +359 2 9694 800, Fax: +359 2 962 52 13 e-mail: info@teletek-electronics.bg English, RevA, 10/ 2021...
