Addressable fire alarm repeater panel
Hide thumbs Also See for TFT:
Table of Contents

Advertisement

Quick Links

Download this manual
IRIS/SIMPO
Repeater
Addressable Fire Alarm Repeater Panel
Model: TFT
Installation &
Programming Manual
Attention:
This manual contains information on limitations regarding product use and
function and information on the limitations as to liability of the manufacturer.
The entire manual should be carefully read.
The information in this manual is a subject to change without notice!
ver. 1.0.8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TFT and is the answer not in the manual?

Questions and answers

Related Manuals for Teletek electronics TFT

Summary of Contents for Teletek electronics TFT

  • Page 1 IRIS/SIMPO Repeater Addressable Fire Alarm Repeater Panel Model: TFT Installation & Programming Manual Attention: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read.

  • Page 2: Table Of Contents

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual Table of Contents 1. INTRODUCTION ................................ 4 1.1. General Description ........................... 4 1.2. General Specifications ..........................4 1.3. Technical Specifications ..........................4 1.4. Functional Features ........................... 4 2.
  • Page 3 The manufacturer shall not accept any product, of which no prior notice has been received via the RAN form at: http://teletek-electronics.com/en/ran- form The setup and programming included in the technical documentation shall not be regarded as defects. Teletek Electronics bears no responsibility for the loss of programming information in the device being serviced. CONDITIONS FOR WAIVING THE GUARANTEE This guarantee shall apply to defects in products resulting only from improper materials or workmanship, related to its normal use.

  • Page 4: Introduction

    1. INTRODUCTION 1.1. General Description IRIS/SIMPO Repeater TFT is a control panel for remote indication of fire alarm, fault, trouble, warning and other type of events, reported from iRIS8, SIMPO and other Repeater panels connected into one common network. The IRIS/SIMPO Repeater can operate only as a part of a network.

  • Page 5: Installation

    -5ºС and +50ºC. The recommended mounting height is 1500 – 1600 mm up from the floor surface. The TFT screen must be well visible from the users and situated approximately at eye level. Leave enough space from all wall corners, at least 300 mm. The right side of the Repeater must be free for access because of the micro USB for software and firmware updates.
  • Page 6 IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual • The left and right side covers, are specific and cannot be exchanged with one another. The covers have marks at the back side, showing the position (left or right) for mounting.

  • Page 7: Initial Power-Up

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual 2.2. Initial Power-up When turned on, the Repeater panel always conducts a procedure of loading the parameters, which usually takes about 30 sec. A long sound signal is heard. There is no access to the menus of the Repeater panel during that procedure.

  • Page 8: Main Power Supply

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual 3.2. Main Power Supply Connect the external power supply unit 24V DC as observe the polarity of the connection. It is recommended to use power supply unit with backup batteries to guarantee the operation of the Repeater in case of mains power supply failure.

  • Page 9: Lan Network

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual The maximum cable length between two network modules and/ or repeater panel is 1000m. iRIS8 Fire panel SIMPO Fire panel Repeater TFT Redundant network Redundant network...

  • Page 10: Installer Programming Menus

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual 4. INSTALLER PROGRAMMING MENUS 4.1. Common Information At Access Level 3 the Installer has full rights for entire programming of the Repeater. To enter the Installer Programming menus, press ACCESS button from the Main Screen and introduce the code for Access Level 3 –...

  • Page 11: General Information For Digits Introducing

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual The following screens present the different type letters/symbols accessible in Repeater panel. Cyrillic Letters screen keyboard. Special Letters screen keyboard. Symbols screen keyboard. Digits screen keyboard.

  • Page 12: Programming Menus

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual 4.2. Programming Menus To enter the Programming menus, press SYSTEM ( ) button from Main Screen: Press PROGRAMMING menu button. The following menus are available for settings.
  • Page 13 IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual Enter SYSTEM - PROGRAMMING – PANEL – ACCESS CODES menu. Fields description: • Access Code Number – Use the left/right buttons to change the code number. Up to 4 code numbers are available for operation.

  • Page 14: Setting Of Network Parameters

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual 4.2.1.2. Setting of Network Parameters Enter SYSTEM - PROGRAMMING – PANEL – NETWORK menu. Quick summery for the submenus: • Network Settings – Menu for setting the parameters for connection between the Repeater and other panels in the network.

  • Page 15: Panels

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual 4.2.1.2.2. Panels After Enabling the Network, every panel starts looking for other panels in the network. If a new panel is found in the system it is added to the panels list with the number set into its Network Settings. The panels are displayed also with unique name (is set), IP address and current status in the network.
  • Page 16 IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual Examples for settings in PANELS submenu. The receiving of messages for events is Enabled. The The receiving of messages for events is Disabled. The options for repeating the outputs status are available for options for repeating the outputs status are unavailable further settings.

  • Page 17: Disable The Internal Buzzer

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual 4.2.1.3. Disable the Internal Buzzer This a submenu to enabling/disabling the internal buzzer of the Repeater. Enter SYSTEM - PROGRAMMING – PANEL - DISABLE menu. By default, the internal buzzer is Enabled.

  • Page 18: Restore Defaults

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual 4.2.2. Restore Defaults In the RESTORE DEFAULTS menu, the Installer can reset the Repeater panel to the factory settings of all the menus. The language of menus will restore in English. It is necessary to program also the Network and Panel settings to restore the operation of the Repeater in the network.

  • Page 19: Setting Time

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual 4.3.1. Setting Time Enter SYSTEM – MAINTENANCE - TIME menu. Use the up and down arrow buttons to set the time. Confirm the new set time with APPLY button.

  • Page 20: Coordinates Calibration

    4.3.3.1. Coordinates Calibration It is possible that after a certain period of use, the parameters of the TFT screen display to change, causing difficulties in pressing buttons, lower sensitivity, etc. This requires the display to be calibrated periodically. It is recommended to use touch pen for precise calibration and to avoid damage and contamination of the sensitive TFT screen.

  • Page 21: Colors Review

    ATTENTION: “Power Safe Backlight” must be disabled for conformity with EN54-2 standard! This is an option for switching off the backlight of the screen after 60 sec in case the TFT display is not used. By default, the Power Safe Backlight option is Enabled.

  • Page 22: Review The Log Memory For Events

    It is recommended first to save the system configuration with ProsTE software as TDF (Teletek Data File) file to your local computer. (Open ProsTE, select SYSTEM, right button of the mouse to add TFT REPEATER PANEL, perform READ operation, save the loaded configuration.)

  • Page 23: Clear The Log Memory For Events

    IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual To filter the events by Number, press NUMBER button and use the digit keyboard. Press OK. The View Log screen will show the contents of the searched number.
  • Page 24 IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual Sounder2 Open Circuit broken at Sounder 2 output. Fire Output Short Short circuit detected at Fire output. Fire Output Fault Circuit broken at Fire output. EXT Output Short Short circuit detected at Extinguishing output.
  • Page 25 IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual User log on Entry in access level 2 (Maintenance). Installer log on Entry in access level 3 (Installer). High Resistance Disabled The indication for high battery resistance is disabled.
  • Page 26 IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual APPENDIX B General structure of the menus.
  • Page 27 IRIS/SIMPO Repeater TFT - Addressable Fire Alarm Repeater Panel – Installation & Programming Manual Notes:...
  • Page 28 www.teletek-electronics.com Address: Bulgaria, 1407 Sofia, 14А Srebarna Str. Tel.: +359 2 9694 800, Fax: +359 2 962 52 13 e-mail: info@teletek-electronics.bg English, RevA, 10/ 2021...
