Dot Origin VTAP100 Installation Manual

Hide thumbs Also See for VTAP100:
Table of Contents

Advertisement

Quick Links

Download this manual
Installation Guide -
VTAP100 Embedded
Reader Board
VTAP100 OEM module
Revised January 2023 v2.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VTAP100 and is the answer not in the manual?

Questions and answers

Related Manuals for Dot Origin VTAP100

Summary of Contents for Dot Origin VTAP100

  • Page 1 Installation Guide - VTAP100 Embedded Reader Board VTAP100 OEM module Revised January 2023 v2.1...
  • Page 2 If you need help to set up or use your VTAP100, beyond what is contained in this Installation Guide, then please contact our support team. Email: vtap-support@dotorigin.com Download the latest documentation and firmware from https://vtapnfc.com Telephone UK and Europe: +44 (0) 1428 685861...

  • Page 3: Table Of Contents

    VTAP MOBILE WALLET READERS Contents 1  Using this guide 2  How the VTAP100 works 2.1 Default operation on factory settings 3  Mechanical installation 3.1 Power 3.2 Environment 3.3 Mounting points 3.4 Optional RS232 connection 3.5 Optional case 4  Module integration instructions 4.1 Applicable FCC rules...
  • Page 4 The VTAP100 equipment is intended for use by suitably qualified integrators, who will integrate the VTAP100 OEM module (PCB) into their own hardware, without any changes or modifications to the VTAP100 OEM module device. (An optional enclosure can be supplied.) Components mounted on the VTAP100 PCB are not user-serviceable.
  • Page 5 Consult the dealer or an experienced radio/TV technician for help. Integrators are responsible for evaluating their own end product (including the VTAP100 OEM module PCB) and obtaining separate approvals for the markets in which it will be sold or used.

  • Page 6: Using This Guide

    It contains the information you need about your VTAP100 OEM module hardware. Consult the VTAP Configuration Guide for more about configuration and maintenance features for any VTAP100, including how to update the firmware on your VTAP100 OEM module, when a new release is available.

  • Page 7: How The Vtap100 Works

    When the VTAP100 OEM module is connected to a computer it appears as a generic mass storage device (like a memory stick). To configure your VTAP, you simply edit or create text files.

  • Page 8: Default Operation On Factory Settings

    These steps demonstrate that the hardware can detect and interact with an OriginPass mobile NFC pass, which is ready to work with the default configuration of your VTAP100. 1. Obtain an OriginPass from Dot Origin by visiting https://originpass.com/VTAP/ and add it to Google or Apple Wallet.

  • Page 9: Mechanical Installation

    Figure 3-1 VTAP100 components - v4a Hardware WARNING: Observe all Safety instructions when installing the VTAP100 PCB. There is more detailed information in section 3.5 about how to fit the VTAP100 unit inside the Optional case case, if used. 3.1 Power Connect the PCB to a PC using only a MicroUSB to USB cable.

  • Page 10: Mounting Points

    CAUTION: Mounting a VTAP board on metal can reduce performance of the VTAP100, because metal can distort the NFC field. Never allow a metal surface between the VTAP100 and the user's phone or card. If you have to mount the VTAP100 on metal, you should ensure the separation is:...

  • Page 11: Optional Rs232 Connection

    The standard connector fitted to the PCB is a Hirose DF11-8DP-2DSA male header plug with shroud. The matching crimp housing is the Hirose DF11-8DS-2C. Figure 3-3 VTAP100 captive power cable or RS232 connection - v4a Hardware The connector J1 includes both USB and RS232 signals, as follows:...
  • Page 12 RXD pins are swapped between the DCE and DTE devices, so that the transmit pin on one connects to the receive pin on the other. The VTAP100 requires a 5V power supply, but not all RS232 devices have 5V on pin 9. Your options are:...

  • Page 13: Optional Case

    VTAP MOBILE WALLET READERS 3.5 Optional case The optional compact case for a VTAP100 is 97mm x 49mm and 40mm deep. Figure 3-5 VTAP100 -CC compact case You can design and affix your own branded label to the unit. If you need help branding units do contact vtap-support@dotorigin.com.

  • Page 14: Module Integration Instructions

    VTAP MOBILE WALLET READERS 4   Module integration instructions The VTAP100 OEM module has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.

  • Page 15: Antennas

    VTAP MOBILE WALLET READERS 4.4 Antennas The VTAP100 OEM module has been tested with its integrated loop antenna, printed on the PCB. There are no alternative antennas approved for use. If an external antenna is attached, the new arrangement would require a new FCC approval.

  • Page 16: Hardware Lock To Disable Usb Mass Storage Device

    A software lock prevents changes but leaves some files visible. A hardware lock means that the VTAP100 will no longer be detected as a USB mass storage device. (It will still behave as an HID keyboard device and, if enabled, the virtual COM port will behave as a composite USB device consisting of HID keyboard and USB virtual COM port.)

  • Page 17: Disposal

    6   Disposal For safety and sustainability, it is the responsibility of the integrator to ensure that when equipment containing a VTAP100 reaches the end of its life, it is recycled in accordance with WEEE Regulations within the EU. VTAP100 (PCB and cables) should not be disposed of in general waste. If you wish to discard electrical and electronic equipment (EEE), please contact your supplier for further information.
