- Page 1 Integration Guide - VTAP50 Reader Module VTAP50-MOD Revised April 2025 v1.03...
- Page 2 No part of this Integration Guide may be published or reproduced without the written permission of Dot Origin Ltd except for personal use. This Integration Guide relates to correct use of the VTAP50 module only. No liability can be accepted under any circumstances relating to the operation of the user’s own PC, network or infrastructure.
-
Page 3: Table Of Contents
6.6 Information on test modes 6.7 Additional testing requirements 6.8 Maintaining Apple ECP2/Access compliance 7 Hardware lock to disable USB mass storage device 8 Find your hardware version 9 Disposal A Tested external antennas VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE I... -
Page 4: Safety Instructions
The VTAP50 module is intended for use by suitably qualified integrators, who will integrate the VTAP50-MOD (PCB) into their own hardware, without any changes or modifications to the VTAP50-MOD device. Components mounted on the VTAP50 module PCB are not user- serviceable. - Page 5 The host integrator installing this module into their product must ensure that the final composite product complies with the requirements by a technical assessment or evaluation to the rules, including the transmitter operation and should refer to guidance in KDB 996369. VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE III...
- Page 6 Si le numéro d'identification n'est pas visible lorsque le module est installé à l'intérieur d'un autre appareil, alors l'extérieur de l'appareil dans lequel le module est installé doit également afficher une étiquette faisant référence au module fourni, Contient IC : 30458-VTAP50. VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE IV...
-
Page 7: Using This Guide
VTAP MOBILE WALLET READERS 1 Using this guide This guide is for first-time users of the VTAP50-MOD reader module. Figure 1-1 VTAP50-MOD reader module It contains the information you need about your VTAP50 hardware. Consult the VTAP Configuration Guide for more about configuration and maintenance features, including how to update the firmware on your VTAP50 unit, when a new release is available. -
Page 8: Attach An Antenna To The Module
VTAP MOBILE WALLET READERS 2 Attach an antenna to the module The VTAP50-MOD reader module has no on-board antenna. Before you can use any VTAP functionality, it requires connection of an external antenna, with a suitable matching circuit, to the VTAP50-MOD reader module. -
Page 9: Use Vtap Development Platform (Vtap-Mod-Dev)
2.3 Procure or design matching circuit and antenna If you have not yet chosen or designed an antenna and matching circuit, Dot Origin can provide support for integrating off-the-shelf or custom NFC antennas with VTAP50-MOD readers. Important considerations and examples of tuning circuits suited to specific off-the-shelf antennas are provided in the VTAP Application Notes about external... -
Page 10: Mechanical Installation
VTAP reader and cause injury if handled. 3.2 Environment The VTAP50 reader must be stored and operated under the following conditions: Ambient temperature -25 to +70°C (-13 to 158°F) Humidity 0 to 95% RH non-condensing Pressure 86-106kPa VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 4... -
Page 11: Mounting Points
at least 25mm separation between the VTAP antenna and any metal. Testing should be performed in the proposed mounting location, as other devices and structures in close proximity could affect pass reading performance. VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 5... -
Page 12: Optional Captive Cable Connection - Rs-232 And Usb
VTAP50 v1 Rev 2 or v2 Hardware onwards The connector J1 includes both USB and RS-232 signals, as follows: Function USB D+ +5V supply USB D- RS232 RXD (input) Reserved (sense input) RS232 TXD (output) Reserved (sense GND) VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 6... - Page 13 Or retain a USB connection in addition to the serial connection, if power is not available from your RS-232 device. Some serial cables have a separate DC 5.5/2.1mm barrel connector to supply power. In these cables, typically, the centre pin is +5V and the outer barrel is GND. VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 7...
-
Page 14: Optional Ffc Connector - Usb And 3.3V Serial
USB keyboard emulation output mode, which can be useful when testing. You can change the way the data is presented (eg with prefixes and postfixes) to suit your target receiving device/application. VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 8... -
Page 15: Optional 12-Pin Expansion Header - External Leds/Antenna
Rx (serial comms 3V3) Tx (serial comms 3V3) Read more in the following sections about attaching external LEDs or antennas on these pins. This connector can also be used to make a 3.3V serial connection. VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 9... - Page 16 Pin 3 or 4 - GND Pin 6 - GND Pin 11 - Rx (serial comms 3V3) Pin 8 – GPIO14 (UART_TXD0) Pin 12 -Tx (serial comms 3V3) Pin 10 – GPIO15 (UART_RXD0) VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 10...
-
Page 17: Optional External Leds
External LEDs should be decoupled, with 10μF bulk capacitance per LED along the LED path.) The VTAP50 reader can support both common cathode and common anode LEDs, by changing the LEDSelect setting in the config.txt file. VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 11... -
Page 18: Permanently Disable On-Board Leds
Turning to the top of the VTAP50 module board, you can identify the associated pads: Using a sharp knife, cut the track between the pads, following the red line in the picture below: VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 12... -
Page 19: How The Vtap50 Module Works
VTAP50-MOD to a PC, and simply tap your smartphone in the field of the antenna. Your mobile NFC pass will be read and payload data sent onwards as defined in the VTAP configuration. -
Page 20: Default Operation
NFC pass, which is ready to work with the default configuration of your VTAP50 module. 1. Obtain an OriginPass from Dot Origin by visiting https://originpass.com/VTAP/ and add it to Google or Apple Wallet. (You will require a username and password - contact vtap-support@dotorigin.com to get these.) - Page 21 .pem format, where # is replaced with a number from 1 to 6, matching the key slot you will save it in. (The demo passes are accessed using the key in KeySlot 6, so don't overwrite this one unless you are finished with Dot Origin demo passes.) Note: A VTAP reader cannot use more than 6 private key files.
- Page 22 3. Save the amended config.txt file and these changes will take effect immediately. (A small number of changes to the config.txt file require a reboot to take effect, for instance to the status of the virtual COM port, but these are highlighted in later sections). VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 16...
- Page 23 In this case, Google Smart Tap data will be received and sent on by the VTAP50 module, only if the pass does not require authentication by the terminal. VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 17...
-
Page 24: Check Status In Boot.txt
'AppKeys used:' Indicates the application keys (if any) uploaded to the VTAP reader for any other applications, such as keys loaded to use with DESFire applications. 'VCP enabled', if included - indicates that the virtual COM port has been enabled. VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 18... - Page 25 'Boot time' - The time at boot, which defaults to 1970/00/00 00:00:00 if power is removed to reboot. If the configuration has been locked the BOOT.TXT file will end with the words LOCKED S/W or LOCKED H/W. VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 19...
-
Page 26: Module Integration Instructions - Fcc/Ised
VTAP50-OEM reader board, when it is integrated into a host system. CAUTION: Changes or modifications made to the VTAP50-OEM reader board, that have not been expressly approved by Dot Origin Ltd could void the user's authority to operate the equipment. -
Page 27: Antennas
PCB. The VTAP50-OEM reader board is designed so that you can carefully break the integrated antenna from the board, at which point it becomes a VTAP50-MOD reader module, and you can connect an external antenna. A list of tested external antennas is provided in Annex . -
Page 28: Maintaining Apple Ecp2/Access Compliance
VTAP reader board or module is tested. This must ensure that the new equipment will read mobile wallet NFC passes when a smartphone is held at least 4cm from the surface of the equipment (both with and without Express mode enabled on the Access pass in the wallet). VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 22... -
Page 29: Hardware Lock To Disable Usb Mass Storage Device
PC will not detect a USB mass storage device, only a keyboard (or keyboard and virtual COM port). When you remove the jumper across LOCK and restart the VTAP50 module, it will be detected as a USB mass storage device and you can make firmware or configuration changes again. VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 23... -
Page 30: Find Your Hardware Version
BOOT.TXT information. If you cannot power the VTAP50 module You will find the version number is printed on the PCB, such as "VTAP50-V2 Rev4 DOT ORIGIN ©2022" in the photo below, which is VTAP50 v2 hardware. VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 24... -
Page 31: Disposal
WEEE Regulations within the EU. VTAP50 module (PCB and cables) should not be disposed of in general waste. If you wish to discard electrical and electronic equipment (EEE), please contact your supplier for further information. VTAP50-MOD INTEGRATION GUIDE © DOT ORIGIN PAGE 25... -
Page 32: A Tested External Antennas
VTAP MOBILE WALLET READERS A Tested external antennas The antenna types listed below have all been tested by Dot Origin, in place of the VTAP50-OEM integrated loop antenna, and found to be compatible. Table A-1 Tested external off-the-shelf antennas Antenna...
