Dot Origin VTAP100 Installation Manual

Reader board
Hide thumbs Also See for VTAP100:

Advertisement

Quick Links

Installation Guide -
VTAP100 Reader Board
VTAP100-OEM
Revised December 2024 v3.42

Advertisement

loading
Need help?

Need help?

Do you have a question about the VTAP100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dot Origin VTAP100

  • Page 1 Installation Guide - VTAP100 Reader Board VTAP100-OEM Revised December 2024 v3.42...
  • Page 2 If you need help to set up or use your VTAP100, beyond what is contained in this Installation Guide, then please contact our support team. Email: vtap-support@dotorigin.com Download the latest documentation and firmware from https://vtapnfc.com Telephone UK and Europe: +44 (0) 1428 685861 Telephone North America and Latin America: +1 (562) 262-9642  ...
  • Page 3 VTAP MOBILE WALLET READERS Contents 1  Using this guide 2  How the VTAP100 works 2.1 Default operation 2.2 Start reading your own passes 2.3 Check status in BOOT.TXT 3  Mechanical installation 3.1 Power 3.2 Environment 3.3 Mounting points 3.4 Optional RS-232 connection 3.5 Optional case...
  • Page 4 Safety instructions WARNING: INTENDED USE The VTAP100 equipment is intended for use by suitably qualified integrators, who will integrate the VTAP100-OEM (PCB) into their own hardware, without any changes or modifications to the VTAP100-OEM device. (An optional enclosure can be supplied.) Components mounted on the VTAP100 PCB are not user-serviceable.
  • Page 5 Contains FCC ID: 2A282-VTAP100G2 or Contains FCC ID: 2A282-VTAP100, in accordance with enclosed module ID. Co-location of this module with other transmitters that operate simultaneously are required to be evaluated using the multi-transmitter procedures.
  • Page 6 Si le numéro d'identification n'est pas visible lorsque le module est installé à l'intérieur d'un autre appareil, alors l'extérieur de l'appareil dans lequel le module est installé doit également afficher une étiquette faisant référence au module fourni, Contient IC : 30458-VTAP100G2. VTAP100 OEM INSTALLATION GUIDE © DOT ORIGIN PAGE IV...
  • Page 7 It contains the information you need about your VTAP100-OEM hardware. Consult the VTAP Configuration Guide for more about configuration and maintenance features for any VTAP100, including how to update the firmware on your VTAP100-OEM, when a new release is available.
  • Page 8 When the VTAP100-OEM is connected to a computer via USB cable, it appears as a generic mass storage device (like a memory stick). To configure your VTAP, you simply edit or create text files.
  • Page 9 NFC pass, which is ready to work with the default configuration of your VTAP100.  1. Obtain an OriginPass from Dot Origin by visiting https://originpass.com/VTAP/ and add it to Google or Apple Wallet. (You will require a username and password - contact vtap-support@dotorigin.com to get these.)
  • Page 10 VTAP MOBILE WALLET READERS This first time, you will need to connect the VTAP100 to your PC, using a USB cable. (If needed, you can make changes remotely in future over a virtual COM port or serial port, see VTAP Serial Integration Guide.) Step 1: Upload private key file(s) to your VTAP100  1.
  • Page 11 Put each parameter on a new line. Order of parameters does not matter to the VTAP100, but could help other people who need to edit the file. Start any comment lines in the config.txt file, that the VTAP100 should ignore, with a semicolon. Each parameter should only appear once - if it accidentally appears more than once then only the last instance will take effect.
  • Page 12 Note: If a VAS#KeySlot parameter is omitted, or set to 0, then all available keys will be automatically tried to choose the right key. If the data received by the VTAP100 cannot be decrypted, the Apple iphone will register a pass read, but the data will not be output.
  • Page 13 VTAP MOBILE WALLET READERS 2.3 Check status in BOOT.TXT If you navigate to the VTAP100 in the computer's file system. It will appear as an attached mass storage device and list the files contained, including the BOOT.TXT file. Inspecting BOOT.TXT will give you essential information about your VTAP100 set up, at time of last reboot, which might be helpful when troubleshooting.
  • Page 14 'Boot time' - The time at boot, which defaults to 1970/00/00 00:00:00 if power is removed to reboot. If the configuration has been locked the BOOT.TXT file will end with the words LOCKED S/W or LOCKED H/W. VTAP100 OEM INSTALLATION GUIDE © DOT ORIGIN PAGE 8...
  • Page 15 The VTAP100 unit for OEM integration comprises a PCB with an integral antenna. Figure 3-1 VTAP100 components - v4a or v5 Hardware Note: If you have a VTAP100 PCB version 3a or earlier the connections will be different, please contact us for manuals specific to your hardware. (If you are not sure which version PCB you have, just Check status in BOOT.TXT follow the instructions in Find your...
  • Page 16 PCB cutter. Use 2-4 small nuts and bolts to mount the board securely. Figure 3-2 VTAP100 PCB mounting holes - v4a or v5 Hardware The VTAP antenna should not be mounted more than 10mm deep within your enclosure (measuring from the antenna surface to the enclosure surface), so that a user’s...
  • Page 17 CAUTION: Mounting a VTAP board near metal can reduce performance of the VTAP100, because metal can distort the NFC field. Never allow a metal surface between the VTAP100 and the user's phone or card. If you have to mount the VTAP100 near metal, you should ensure the separation is:  ...
  • Page 18 The standard connector fitted to the PCB is a Hirose DF11-8DP-2DSA male header plug with shroud. The matching crimp housing is the Hirose DF11-8DS-2C. Figure 3-3 VTAP100 captive power cable or RS-232 connection - v4a or v5 Hardware The connector J1 includes both USB and RS-232 signals, as follows:...
  • Page 19 RXD pins are swapped between the DCE and DTE devices, so that the transmit pin on one connects to the receive pin on the other. The VTAP100 requires a 5V power supply, but not all RS-232 devices have 5V on pin 9. Your options are:  ...
  • Page 20 VTAP MOBILE WALLET READERS 3.5 Optional case The optional compact case for a VTAP100 is 97mm x 49mm and 40mm deep. Figure 3-5 VTAP100-CC compact case We can design and affix your own branded label to the unit. If you would like to brand your VTAP readers do contact vtap-support@dotorigin.com.
  • Page 21 VTAP MOBILE WALLET READERS 4   Module integration instructions - FCC/ISED The VTAP100 OEM module has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
  • Page 22 VTAP MOBILE WALLET READERS 4.4 Antennas The VTAP100 OEM module has been tested with its integrated loop antenna, printed on the PCB. There are no alternative antennas approved for use. If an external antenna is attached, the new arrangement would require a new FCC/ISED approval.
  • Page 23 USB mass storage device, only a keyboard (or keyboard and virtual COM port). When you remove the jumper across LOCK and restart the VTAP100, it will be detected as a USB mass storage device and you can make firmware or configuration changes again.
  • Page 24 VTAP MOBILE WALLET READERS 6   Find your hardware version If you need to report a problem with your VTAP100 or find the right reference diagram you will need to know your hardware version. If you can connect your VTAP100 to a PC, you can easily check the BOOT.TXT file.
  • Page 25 7   Disposal For safety and sustainability, it is the responsibility of the integrator to ensure that when equipment containing a VTAP100 reaches the end of its life, it is recycled in accordance with WEEE Regulations within the EU. VTAP100 (PCB and cables) should not be disposed of in general waste. If you wish to discard electrical and electronic equipment (EEE), please contact your supplier for further information.
