Basalte Eve Plus Instruction Manual

Eve Plus
Installation manual
1
Identification of the parts
Eve Plus
A Eve Plus sleeve
Eve Plus Mini - 0124-xx
Eve Plus Air - 0123-xx
Eve Plus - 0125-xx
B iPad (not included)
C Cover
D
Softy grip
E Plus connector
F Screws
G USB-C connector
2
Mounting the iPad
1. Unmount the screws on the back of the sleeve and slide
off the cover.
2. Place the Eve Plus sleeve on a flat surface with the soft
grip facing downwards.
Gently slide in the iPad. Never apply too much force and
keep the iPad aligned with the sleeve.
Make sure the iPad stays flush with the frame.
3. Gently slide de USB-C connector in de iPad.
4. Gently reattach the cover by sliding it into position
5. Lock using the screws.
Make sure to follow the steps above in the right order as a
wrong installation can damage the frame.
Made in Belgium
Basalte is a registered trademark of Basalte bv.
EVE Plus is a registered trademark of Basalte bv.
EVE Plus is a registered design of Basalte bv.
iPad is a registered trademark of Apple Inc.
basalte bv
fraterstraat 37b I 9820 merelbeke I belgium
tel +32 9 385 78 38 I info@basalte.be I www.basalte.be
3
Removing the iPad
1. Remove the screws holding the cover and slide off the
cover from the frame.
2. Place the Eve Plus sleeve on a flat surface, with the soft
grips facing downwards.
3. Gently slide out the iPad keeping it aligned with the
sleeve. Never apply too much force or pull the iPad up
or down while sliding. Make sure the iPad stays flush with
the sleeve until removed.
Eve Plus does not support always-on display
configuration.
Docking the Eve Plus
Eve Plus lets you dock your iPad on a wall or table, while
keeping it charged. Thanks to the Plus connector the iPad
can be docked horizontally (landscape) and vertically
(portrait).
Eve Plus is compatible with the Eve Plus wall base (0130-xx)
and table base (0150-xx).
Important remark
Eve Plus sleeves with USB-C connectors are not compatible
with Eve Plus wall base USB (0130-02) and Gigabit POE
adapter (0610-20).
Dimensions
Eve Plus Mini (0124-xx): 213,80 mm/8,79" x 138,80 mm/5,47"
Eve Plus Mini is compatible with:
iPad Mini (6th generation)
Eve Plus Air (0123-xx): 266 mm/10,47" x 182.5 mm/7,19"
Eve Plus Air 11" is compatible with:
iPad Pro 11" (1st, 2nd, 3rd generation)
iPad Air 10.9" (4th, 5th generation)
Eve Plus (0125-xx): 267 mm/10.51" x 183,5 mm/7.27"
Eve Plus is compatible with: iPad 10.9" (10th generation)
