Congratulations on the purchase of your new Bushnell binocular! Your binocular is a precision
instrument designed to provide many years of pleasurable viewing. This manual will help you
achieve optimum performance by explaining how you can adjust the binocular to your eyes,
and how to care for this instrument. Read the instructions carefully before using your binocular.
Fig. 1
Interpupillary Distance
Fig. 3

Zoom Feature

EYE ADJUSTMENTS (Figure 1)
How to Adjust for Distance Between Your Eyes
The distance between the eyes, called "interpupillary distance," varies from person to person. To achieve perfect
alignment of lens to eyes, follow these simple steps.
1.
Hold your binocular in the normal viewing position.
2.
Grasp each barrel firmly. Move the barrels closer together or further apart until you see a single
circular field. Always re-set your binocular to this position before using it.
How to Adjust for Individual Eye Strength
As individual eyesight varies from one person to another, most Bushnell binoculars have a diopter setting
feature which allows you to fine-tune the binocular to your vision. Follow the focusing instructions below for
your type of binocular.

FOCUSING

Bushnell binoculars have one of two focusing systems: Center or "Insta-Focus ® ".
® " rapid focusing system has a focusing lever between the barrels.
BINOCULAR
INSTRUCTION MANUAL
Fig. 2
Diopter Setting
Fig. 4
Roll-Down Eyecups
Lit. #: 91-0203/0719

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H2O 138005 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bushnell H2O 138005

  • Page 1 How to Adjust for Individual Eye Strength As individual eyesight varies from one person to another, most Bushnell binoculars have a diopter setting feature which allows you to fine-tune the binocular to your vision. Follow the focusing instructions below for your type of binocular.
  • Page 2 This will bring your eyes closer to the binocular lens thus providing improved field of view. INSTRUCTIONS FOR CARE Your Bushnell binocular will provide years of trouble-free service if it receives the normal care you would give any fine optical instrument. Non-waterproof models should not be exposed to excessive moisture.
