Bang&Oiufsen
SPECIFICATION GUIDELINES FOR SERVICE USE
Beolink Converter
Beolink Video
Concept
Main or link room product
BeoLink Converter
BeoLink Video
Operation
Remote operation
(Through connected products)
Compatability
Beolink Converter
Beolink Video
Cabinet
Placement
System data
Frequency response
Signal-to-noise ratio
Connections
Mains
�
Phase
Earth
�
19- 1
SPECIFICATION GUIDELINES
Type 1611 (EU), 1612 (US)
Type 1615 MKII
MUAAL converter with internal power supply and stand-by
switching.
For connection between ML and AAL audio and video
products.
Link room product
MUAAL converter with internal power supply and stand-by
switching.
For connection of a ex tra TV to a ML-based audio or video
system.
Beo4
Beolink 1000
All AN masters with Master Link distribution
All video masters with Master Link distribution
Black aluminium/plastic
Fastened to the wall
20 - 20.000 Hz +0/-1 dB
> 82 dB
Cable included, 3 m
230 - 240V AC, 50Hz (Type 1611, 1615)
120 V (Type 1612)
19- 1
SPECIFICATION
GUIDELINES.
Master Link
1
os
C6
07
os
010
11
012
G13
014
1
5
16
Power Link
(Not mounted i type 1615)
fl
4
:
3
0
1
7
6
Audio Aux Link
Dimensions
Total dimensionsW x H x D (on wall)
Power consumption, operation
Power consumption, stand-by
Weight
Optional acessories
Beolink 1000
Beo4
Cable cover
Master Link cable
Master Link junction box
Subject to change without notice
19- 1
Data - - 0.25V
2 Data+ + 0.25V
3 ML sense
4 - 10
N.C.
11 Supply voltage -7V -> -15V, stand-by -3V -> -15V
12 Supply voltage 7V -> 15V, stand-by 3V -> 15V
13 Audio L -
1V bal., Rin 2.2M ohm, Rout 75 ohm
14 Audio L +
1V bal., Rin 2.2M ohm, Rout 75 ohm
15 Audio R -
1 V bal., Rin 2.2M ohm, Rout 75 ohm
16 Audio R +
1 V bal., Rin 2.2M ohm, Rout 75 ohm
N.C.
2 Ground
3 N.C.
4 PL speaker on > 2.5V, off< O.SV
5 N.C.
6 N.C.
7 N.C.
8 N.C.
Video sound
Audio sound
Audio L in
Audio L out
2
Ground
Ground
3
Audio L out
Audio L in
4
Audio R in
Audio R out
5
Audio R out
Audio R in
6
Data: H > 3.5V, L < 0.8V
7
N.C.
20 x 10.5 x4 cm /7.8" x4.1" x 1.6"
2.1 watts (230V AC)
< 1.5 watts (230V AC)
0.6 kg
Type 1501, 1502 (Italy)
Type 1624, 1625 (Italy)
2560276 (1 0 pieces x 2.5 m)
Available from de a I er
3132170 black, 3132197 grey
�
