Installation Instructions
Warning
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, OR INJURY
TO PERSONS IMPORTANT
SAFETY INSTRUCTIONS
Lighted fixture is HOT!
WARNING - To reduce the risk of
FIRE OR INJURY TO PERSONS:
Turn off/unplug and allow to cool before replacing LED.
Fixture gets HOT quickly! Contact only switch/plug when
turning on. Do not touch hot lens, guard, or enclosure.
Keep fixture away from materials that may burn.
Do not operate the luminaire fitting with a missing or
damaged shield. Do not touch the source at any time.
Use a soft cloth or gloves. Oil from skin may cause
damage.
SAVE THESE INSTRUCTIONS
This set of instructions works for:
ST-DE-TR-A - Integral Denali Series Twin Sign Star Style "A
ST-DE-TR-B - Integral Denali Series Twin Sign Star Style "B"
ST-DE-TR-C - Integral Denali Series Twin Sign Star Style "C"
ST-DE-TR-F - Integral Denali Series Twin Sign Star Style "F"
ST-DE-TR-G - Integral Denali Series Twin Sign Star Style "G"
ST-DE-TR-C
ST-DE-TR-B
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION
B-K LIGHTING
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF B-K LIGHTING, INC. AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR
SELL ANYTHING IT MAY DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF B-K LIGHTING, INC. IS STRICTLY FORBIDDEN.
INTEGRAL DRIVER - TWIN SIGN STAR
Low Voltage
Hot Surface
Flammable
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL
• Product must be installed by a qualified person in a manner
consistent with its intended use and in compliance with the
National Electrical Code, Canadian Electrical Code, and all Local
and Provincial Codes.
• Follow product label information and instructions.
• Qualified Personnel with appropriate personal protective
equipment must perform all servicing of this product.
• Before wiring to power supply and during servicing, turn off and
lock out power at fuse or circuit breaker before service.
• The use of accessory equipment not recommended by the
manufacturer or installed contrary to instructions may cause an
unsafe condition. The use of damaged components may cause
an unsafe condition and void product warranty.
IMPORTANT LISTINGS AND CERTIFICATIONS
· Suitable for wet locations
ST-DE-TR-A
ST-DE-TR-G
ST-DE-TR-F
INSTRUCTIONS
40429 Brickyard Drive • Madera, CA 93636 • USA
www.bklighting.com • info@bklighting.com
TOOLS
NEEDED:
By Others
SAFETY AND INSTALLATION INSTRUCTIONS
360HD
Mounting
System
Denali Series
Fixture
559.438.5800 • FAX 559.438.5900
DENALI SERIES
1/8", 5/16" & 9/64" Allen Wrench
Waterproof Wire Connectors
Crimping Tool
Safety Cable
Mounting Hardware
Mounting Hardware for Substrate
• Do not block light emanating from product in whole or part,
as this may cause an unsafe condition.
• Never operate the fixture with missing or damaged lens.
Lens must be cleaned on regular basis.
• Entire fixture may become extremely hot. Do not touch hot
lens or fixture body.
• Replace LED assembly only with correct wattage and type
of power supply appropriate for LED assembly.
• All gaskets, o-rings and sealing surfaces must be kept clean
during installation and service; failure to do this may cause
an unsafe condition and void product warranty.
Safety Cable
Notch
Canopy
Safety Cable
and Support
Canopy
RELEASE DATE
REFERENCE NUMBER
01/27/2021
INS-2832-00
Heavy Duty
Mounting Plate
