Harken Industrial IN647 Product Manual

P R O D U C T M A N U A L
MEDIUM ROUND ANCHORAGE POINT
HARKEN INC, N15W24983 Bluemound Rd., Pewaukee, WI 53072, USA, Tel: 262-691-3320
HARKEN UK Ltd, Bearing House, Ampress Lane, Lymington, SO41 8LW, UK, Tel: +44 (0)1590 689122
Web: www.harkenindustrial.com • Email: info@harkenindustrial.com
EN795:2012 Class A
Protection against falls from a height
Anchor devices – requirements and
testing Class A – structural anchors
O R I E N T A T I O N
WARNING!
THIS PRODUCT IS PART OF A PERSONAL
FALL ARREST / HUMAN SUSPENSION ANCHOR
It is the installer's responsibility to ensure the suitability
of base materials into which the structural anchor device
is fixed.
Alterations or misuse of this equipment, or failure to follow
these instructions, may result in a fall or failure to arrest a
fall leading to serious injury or death.
Part Numbers: IN647, IN648
Rated Load: 17.5 kN
Rated for 2 users,
Max 150 kg per person
S P E C I F I C A T I O N S
Weight
Material
MRL Goods & Eqt.
(Breaking Load/4)
Breaking load
Recommended
Fasteners
Certifi ed to EN 795:2012
E F
G
D
C
A
WARNING!
Activities involving the use of this
equipment are inherently dangerous.
You are responsible for your own
actions and decisions.
Before using this equipment, you must:
• Read and understand all instructions for use
• Get specific training in its proper use
• Become acquainted with its capabilities and limitations
• Understand and accept the risks involved
FAILURE TO HEED ANY OF THESE WARNINGS MAY
RESULT IN SEVERE INJURY OR DEATH
EU Representative
Harken UK Ltd, Bearing House, Ampress Lane,
Lymington, UK, SO41 8LW
T: +44 (0)1590 689122
E: info@harkenindustrial.co.uk
W: www.harkenindustrial.com
312 grams
17-4 PH stainless
17.5 kN (EN 795)
70 kN
4 x M10
(recommend A2 70 SS)
Two person fall arrest
and human suspension
Dims (mm) (inches)
A 76 3
C 33 1.3
D 40 1.6
E 50 1.9
F 29 1.1
G 37 1.4
5174/4-18
