- Page 1 DLx PULLING WINCHES Model #DLx1900FC U.S. Patents 10640343, D867713 and D867714 DLx1500FC DLx1900FC DLx2600FC Dwg. No. 206870 1/23...
-
Page 2: Important Safety Information
WARNING READ INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO INSTALL, OPERATE OR SERVICE THIS WINCH. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN SERIOUS OR FATAL INJURY. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. IMPORTANT SAFETY INFORMATION • This winch is built for multi-purpose hauling and pulling operations. It is not recommended for lifting applications. For lifting, use a self-locking winch. - Page 3 FRANÇAIS - Pour obtenir une copie de la in English, send a self-addressed envelope garantie en français, envoyer une enveloppe to: Dutton-Lainson Company; P.O. Box 729; à votre nom et adresse à : Dutton-Lainson Hastings NE 68902-0729; U.S.A. Company; P.O. Box 729; Hastings NE 68902- 0729; U.S.A.
- Page 4 OPERATING INSTRUCTIONS DLx1500FC & DLx1900FC HANDLE AND NUT MUST BE TIGHTENED AGAINST DRIVE SHAFT BEFORE OPERATING WINCH. Wind line on winch reel by turning winch handle in clockwise direction with ratchet lever in up position. The ratchet should produce a loud, sharp clicking noise.
- Page 5 MAXIMUM STRAP ANGLE DLx1500FC - 20 Ft. (6.1m) - 25° DLx1900FC - 20 Ft. (6.1m) - 26° MAX ANGLE DLx2600FC - 25 Ft. (7.6m) - 26° CAUTION: Exceeding the maximum strap angle could result in damage to winch cover. WINCH COVER REMOVAL AND ASSEMBLY The cover comes off the winch in three pieces.
- Page 6 DLx1500FC To order replacement parts: Dutton-Lainson Company www.dlco.com Tel: 800-569-6577 Fax: 402-460-4612 email: DLsales@dutton-lainson.com Ref. Description Part. No. Ref. Description Part. No. Base - DLx1500 406195 Ratchet Kit 5704556 Bushing 204006 Reel - DLx1500 306278 Retaining Ring 205012 Strap, 20 ft.
- Page 7 DLx1900FC To order replacement parts: Dutton-Lainson Company www.dlco.com Tel: 800-569-6577 Fax: 402-460-4612 email: DLsales@dutton-lainson.com Ref. Description Part. No. Ref. Description Part. No. Base 406191 Reel 304779-PL Bushing 204009 Large Hub Reel 306124 Retaining Ring 205116 Strap, 20 Ft. 5242409 Drive Shaft...
- Page 8 DLx1500FC DLx1900FC DLx2600FC...
- Page 9 DLx2600FC To order replacement parts: Dutton-Lainson Company www.dlco.com Tel: 800-569-6577 Fax: 402-460-4612 email: DLsales@dutton-lainson.com Ref. Description Part. No. Ref. Description Part. No. Base 406220 Reel Spacer 204808 Bushing 204009 Reel 304782-PL Retaining Ring 205116 Rope Clamp Kit 5243506 Primary Shaft...
