  • Page 1 INSTRUCTION MANUAL...

  • Page 3: Table Of Contents

    Manual A . Features B . Mode and Function 1.Time and date setting 2.Pedometer Mode 3. Review records 4. Alarm mode 5. Chronograph mode 6.Countdown timer mode 7.Metronome mode 8.The second time setting 9.Altitude measurement mode 10.Atmospheric pressure measurement mode 11．...

  • Page 4: Features

    LIGHT/SELECT （button E） UP/BARO （button A） （button D）COMP MODE/SET （button C） DOWN/ALTI （button B） A . Features 12 / 24 Hourly format Pedometer EL backlight Compass The second time Pacer Display low battery Alarms(2 alarms and hourly chime). Time:hour, minute, second, week, month, day. Year from 2000 to 2099 fully automatic calendar.

  • Page 5: Mode And Function

    B . Mode and Function Pedometer mode Record mode Alarm mode Chronograph mode Timekeeping mode The second time mode Metronome mode Countdown timer mode Atmospheric pressure Altitude Compass measurement measurement Press button A in any mode, EL illuminates for 3 seconds. Press button B to choose modes.

  • Page 6: Time And Date Setting

    1.Time and date setting In timekeeping mode, keep pressing button B for 2s,the Second flashes, entering setting mode. Press button B to set the flashing items. Timekeeping Set Second Set Minute Set Hour Set Year “HOLD” Flash mode BEEP on/off Set LCD resolution Set 12/24H Set M/D format...
  • Page 7 press E to shift among these items:step→mileage→calories→exercise time→step Step Mileage Calories Exercise timer Set the pedometer In pedometer mode, keep pressing button B for 2s,the unit flashes, entering setting mode Press button B to set the flashing items: unit→step distance→weight Pedometer mode Set unit Step distance...

  • Page 8: Review Records

    3. Review records In the record mode, press C to review the latest 7 days record 12.17 12.18 12.23 History record review mode In the day record, you can shift the data for the following items by pressing E Pedometer Mileage Calories Exercise timer...

  • Page 9: Chronograph Mode

    Alarm mode Set Minute Set Hour Press E to increase the value, press and hold E to advance quickly. Press C to decrease the value, press and hold C to decrease quickly Keep pressing B for 2s to exit. It will exit setting mode when no any key pressing for 1 minute. When the alarm is on, it will sound BB—BB for 20s once it's the alarm time, the sign will will be flashing.

  • Page 10: Countdown Timer Mode

    Chronograph mode Review LAP 10S later Running Display Running Pause Press B for 2S ALP 1 ALP 31 LAP Total time 6、Countdown timer mode The maximum countdown range is: 99 hours, 59 minutes and 59.99 seconds. In the countdown timer mode, press button E to run/stop, press button C to return your setting value when it stop.

  • Page 11: Metronome Mode

    Press button B to select the following items for setting sequentially: B for2S 2Slater Countdown timer mode "HOLD" Flashes Set Hour Set Minute Set Second Press E to increase the value, press and hold E to advance quickly. Press C to decrease the value, press and hold C to decrease quickly Keep pressing B for 2s to exit.

  • Page 12: The Second Time Setting

    8、The second time setting In the second time setting mode, keep pressing B for 2s,the Minute flashes, entering setting mode Press button B to select the following items for setting sequentially: B for2S The 2nd time mode "HOLD" flashes Set Minute Set Hour Press E to increase the value, press and hold E to advance quickly.
  • Page 13 Altitude setting Press button B for 2s to enter altitude setting mode,press B to move and set the following items Display temp. adjust pressure Adjust humidity Adjusting humidity Reset Relative altitude setting （ ZERO） Press E/C to shift“YES”/“NO”,when it is YES, that means the relative altitude is 0, when NO, that means use the default value(work out according to default sea level atmosphere1013.25mb).

  • Page 14: Atmospheric Pressure Measurement Mode

    10、 Atmospheric pressure measurement mode Timekeeping mode Display temperature Display SEAP Display trend In timekeeping mode, press button E to enter atmospheric pressure measurement mode, Press E to shift the display: temperature→sea level atmospheric pressure→trend When it displays the trend by pressing C, you can review the former hourly curve Keep pressing E for 2s to shift the unit of temperature and altitude ℃/hpa/mb→℃/Inhg→℉/Inhg→℉/hpa/mb It will return to timekeeping mode after 24h without any pressing,...

  • Page 15: 11． Compass Mode

    Press C to decrease the value, press and hold C to decrease quickly Press button B for 2s to confirm, return to atmospheric pressure measurement mode Input your current temperature(TEMP) Press E to increase the value, press and hold E to advance quickly. Press C to decrease the value, press and hold C to decrease quickly Press button B for 2s to confirm, return to atmospheric pressure measurement mode Factory default atmospheric pressure value（FDEF）...
  • Page 16 The follow table indicated the meaning of each acronym for each direction. Direction Meaning Direction Meaning Direction Meaning Direction Meaning North North-north-east North-east East-north-east East East-south-east South-east South-south-east South South-south-west South-west West-south-west West West-north-west North-west North-north-west Note: if your compass never used before, please adjust as following method Compass adjust mode Bfor2S Adjust compass...
  • Page 17 In compass mode, keep pressing B for 2s to enter CAL, press B again to enter DEC (press E to increase 1,C decease 1) The maximum correction angle range is ±90° （ “W” “E” ±90°） Press B for 2s to confirm the corrected value, and return to normal measurement mode.

  • Page 18: Specification

    Sunshine： 0.8~2.5(mbar/h) Cloudy： 0.5~0.8(mbar/h) No change： - 0.5~0.5(mbar/h) Overcast sky： - 1.0~ - 0.5(mbar/h) Rainy： - 2.5~ - 1.0(mbar/h) Notes: temperature measurement by personal temperature (when you wear a watch), the effect of direct sunlight and humidity. In order to make the measurement of temperature more accurate, please take the watch from the wrist and place it in a place not directly exposed to the sun and good ventilation and dry the case.
  • Page 19 Static average moment current ≤130uA Static average drive current ≤6.62uA （max：597uA） Alarm average current ≤2.2mA （max：4.5mA） Average current using pedometer ≤0.028mA （max：0.056mA） EL backlight average current ≤9.22mA （max：12mA） Digital compass average current ≤0.208mA （max：0.439mA） weather forecast average current ≤0.12uA （max：900uA） pressure sensor average current ≤0.0276mA （max：0.259mA）...
