Table 1. Screw list (continued)
Component
Fan
Heat sink
Touchpad (for computer
shipped with downfiring
speakers)
Touchpad (for computer
shipped with upfiring speakers)
Display hinges
I/O daughter-board
Power button with optional
fingerprint reader
USB Type-C port bracket
System board
Major components of Inspiron 14 5430
The following image shows the major components of Inspiron 14 5430.
Screw type
M2x3
Captive screws
NOTE:
Screws are
part of the heat sink.
M2x2
M1.6x2.5
M2x2
M1.6x2.5
M2.5x3.5
M2x3
M2x3
M2x4
M2x1.8
Quantity
2
Integrated: 4
Discrete: 7
2
4
4
5
4
1
1
Downfiring speakers: 3
Upfiring speakers: 2
2
Removing and installing components
Screw image
11
