Viking M Technical Data

March 11, 1999
1. PRO DUCT NAME
Vi king Model M Quick Re sponse
Ex tended Cov er age Ad just able
Re cessed Dry Side wall Sprin kler
Base Part Num ber 10542
•
Avail able since 1998
•
2. MAN U FAC TURER
The Vi king Cor po ra tion
210 N. In dus trial Park Road
Hastings, Mich i gan 49058 USA
Tele phone: (616) 945-9501
(877) 384-5464
Fax: (616) 945-9599
e-mail: techsvcs@vikingcorp.com
3. PRO DUCT DE SCRIP TION
The Vi king Model M Quick Re sponse
Ex tended Cov er age (QREC) Dry Side -
wall Sprin kler is a thermosensitive
glass-bulb spray sprin kler, suit able for
use in ar eas sub ject to freez ing. It is de -
signed for dry sys tems and preaction
sys tems where nec es sary to pre vent
wa ter or con den sa tion from en ter ing the
sup ply nip ple prior to sprin kler ac tu a -
tion. This sprin kler may also be in stalled
in spaces sub ject to freez ing and sup -
plied from a wet sys tem in an ad ja cent
heated area.
The as sem bly fea tures a sealed brass
in let and a du ra ble threaded steel bar rel
with an Elec tro de pos it ed Ep oxy Base
coat ing. This sprin kler is of the Model M
de sign with a rug ged 3 mm glass bulb
and hor i zon tal style side wall de flec tor.
The QREC Dry Hor i zon tal Side wall
Sprin kler is avail able in sev eral fin ishes
and tem per a ture rat ings to meet de sign
re quire ments (see Ta ble 1).
The seal at the threaded end of the as -
sem bly is held in place by force trans mit -
ted from the com pres sion screw through
the glass bulb and in ter nal parts, onto a
spe cial seal ing spring. Dur ing fire con di -
tions, the heat-sensitive liq uid in the
glass bulb ex pands, caus ing the glass to
shat ter, re leas ing the in ter nal parts to
open the wa ter way. Wa ter flow ing
through the sprin kler or i fice strikes the
sprin kler de flec tor, form ing a uni form
spray pat tern to ex tin guish or con trol the
fire.
The Model M Quick Re sponse Ex -
tended Cov er age Dry Hor i zon tal Side -
wall Sprin kler is in stalled with the re -
cessed style es cutch eon with up to 5/8"
(15,9 mm) ad just ment (see Fig ure A) to
pro vide a re cessed ap pear ance. The
es cutch eon slips over the sprin kler de -
Note: Units of mea sure in pa ren the ses may be ap prox i ma tions.
Form No. F_051598
TECH NI CAL DATA
Model M 1/2" (15 mm) Or i fice Quick Re sponse
Ex tended Cov er age Dry Side wall Sprin kler
For Light-Hazard Oc cu pancies Only
flec tor, al low ing in stal la tion of the es -
cutch eon af ter the wall fin ish is ap plied.
Model M Quick Re sponse Ex tended
Cov er age Dry Side wall Sprin klers may
be or dered in lengths from 3-1/4" to 48"
(82,5 mm to 1 219 mm)*, and they are
avail able in 1/4" (6,35 mm) in cre ments.
* Lengths over 48" (1 219 mm) are avail able, with no
ap prov als, on a "made-to-order" ba sis. Con tact
the man u fac turer.
4. TECH NI CAL DATA
LIST INGS AND AP PROVALS
Re fer to Ta ble 1 on page 109 d.
Listed to max i mum length of 48" (1 219
mm)*.
Glass-bulb fluid tem per a ture rated to
-65 °F (-55 °C).
Rated to 175 psi (1 207 kPa) wa ter work -
ing pres sure.
Thread Size: 1" NPT or 25 mm BSPT
Or i fice Size: Nom i nal 1/2" (15 mm)
K-Factor: 5.5 U.S. (7,9 met ric**) all
listed and all ap proved lengths
** Met ric K-factor shown is for use when pres sure is
mea sured in kPa. When pres sure is mea sured in
BAR, mul ti ply the met ric K-factor shown by 10.0
Minimum op er at ing pres sure: 7 psi
(48,3 kPa).
Fac tory tested pneu mat i cally at 95 psi
(655 kPa).
Spring: U.S.A. Pat ent No. 4,167,974
Bulb: U.S.A. Pat ent No. 4,796,710
SPRIN KLER MA TE RIALS
Frame: Brass Cast ings UNS-C84400
De flec tor: Brass UNS-C26000
Bulb: Glass, nom i nal 3 mm di am e ter
®
Seal: Tef lon Tape
Spring: Nickel Al loy
Screw: Brass UNS-C36000
Pip Cap: Brass UNS-C31600
Seat: Cop per UNS-C21000
Or i fice: Cop per UNS-C21000
Washer: Stain less Steel UNS-S30400
Spring Base: Brass UNS-C31400 or
UNS-C31600
Gas ket: Buna N
Pin: Stain less Steel UNS-S42000
Tube: JIC Hy drau lic Steel Tube
MODEL M
QUICK RE SPONSE
EX TENDED COV ER AGE
DRY SIDE WALL SPRIN KLER
In let: Brass UNS-C36000
Sup port (In ter nal): Steel UNS-G10080
Elec tro de pos it ed Ep oxy Base fin ish
Bar rel: Steel Pipe UNS-G10200 Elec -
tro de pos it ed Ep oxy Base fin ish
AC CES SORIES
Dry Sprin kler Wrench†:
Re cessed: Part No. 07565W/B
†Re quires a sep a rate 1/2" square drive ratchet and
ex ten sion (not avail able from Vi king).
Sprin kler Guard: Chrome, with no list -
ings or ap prov als, for in stal la tion on
Model M Dry Side wall Sprin klers
man u fac tured af ter May 1994 only,
Part No. 08954
AVAIL ABLE FIN ISHES
Re cessed: Chrome-Enloy
Poly es ter
OR DERING IN FOR MA TION
For proper ship ment, spec ify: model, or -
i fice size, fin ish, tem per a ture rat ing, es -
cutch eon, and length ("A" di men sion).
The dry hor i zon tal side wall sprin klers
are or dered in spe cific lengths noted as
the "A" di men sion (see Fig ure A). The
"A" di men sion is the dis tance from the
face of the fit ting (tee) to the fin ished sur -
face of the wall in which it is to be in -
stalled. The dry hor i zon tal side wall
sprin kler must be or dered and man u fac -
tured spe cif i cally for the con di tions of
the in di vid ual in stal la tion. For lim its of
ad just ment for the re cessed es cutch -
eon, see Fig ure A.
5. AVAIL ABIL ITY AND SER VICE
Vi king sprin klers are avail able through a
net work of do mes tic, Ca na dian, and in -
ter na tional dis trib u tors. See the Yel low
Pages of the tele phone di rec tory for a lo -
cal dis trib u tor (listed un der "Sprin klers-
Au to matic-Fire") or con tact Vi king.
Re places page 109 a-c, dated June 22, 1998
(up dated sprin kler photo).
