Read Assembly Instructions carefully
IMPORTANT :
and retain for future reference.
DESCRIPTION
ITEM NAME: 2 DRAWER BEDSIDE
PRODUCT CODE : KL-BKL-002
KL-BKL-006
30 mins
Floor Area
Ceiling Height
250 cm x
200 cm
200 cm
APPROXIMATE ASSEMBLY TIME
2 PERSONS ASSEMBLY
REQUIRED ASSEMBLY SPACE
PHILLIPS SCREWDRIVER
REQUIRED ASSEMBLY TOOLS:
ASSEMBLED DIMENSIONS (cm)
