Summary of Contents for UBC CENTAUR 2.1

  • Page 2: Table Of Contents

    CENTAUR FROM THE CITY general information..................................3 Limitation of liability ..................................3 Explanation of symbols ................................... 4 1. STANDARDS AND DIRECTIVES ............................5 2. TECHNICAL DATA .................................. 5 3. CONSTRUCTION OF THE SHOWCASE ..........................7 4. SAFETY A ....................................8 5.
  • Page 3: General Information

    CENTAUR GENERAL INFORMATION This manual is intended for studying the rules of installation, operation, maintenance and safe operation of the refrigerated display case, hereinafter referred to as the display case. The manual is an integral part of the display case and must be kept and available for use throughout the display window's service life.
  • Page 4: Explanation Of Symbols

    CENTAUR Failure to comply with the above points will also void the warranty. The manufacturer reserves the right to make technical changes to optimize and improve the efficiency of the equipment. EXPLANATION OF SYMBOLS Before studying the instructions, familiarize yourself with the information marks: General warning sign Warning about non- hazardous substances Electrical voltage warning...
  • Page 5: Standards And Directives

    Standards used in the design and manufacture of products: EN ISO 23953-2:2015 2. TECHNICAL DATA Table 1 shows the technical data of the " CENTAUR " showcase. Table 1 - Technical parameters Technical characteristics CENTAUR 2.1 CENTAUR 2.5 Dimensions (length/width/height), mm 2100/816/2292 2500/816/2292 Dimensions including packaging, (length/width/height),...
  • Page 6 CENTAUR Figure 1 – Dimensional drawing When working with the equipment, it is necessary to observe the information on the sign . This is a sticker on the inner (right side) panel of the equipment that contains important technical data. –...
  • Page 7: Construction Of The Showcase

    CENTAUR 3. CONSTRUCTION OF THE SHOWCASE Figure 3 – Location of main nodes and components. 1. Compressor; 2. Capacitor; 3. Condenser fan; 4. LED lamp power supply unit; 5. Terminal box; 6. Solenoid valve; 7. Herkon ; 8. Thermostat; 9. Doors; 10.
  • Page 8: Safety A

    CENTAUR 4. SAFETY A 4.1. ELECTRIC VOLTAGE Work on the electrical part should be performed only by specialists. In the event of a malfunction or damage, contact the service department. Touching live parts can result in electric shock Risk of fire due to sparks or overloading •...
  • Page 9: Placement Requirements

    CENTAUR 4.3 . MECHANICAL HAZARDS • Risk of injury due to the falling of display shelves loaded with product. The shelves must be completely fixed in the holes intended for this purpose • It is possible to clamp the hands from the side loops handles.
  • Page 10: Installation And Connection

    CENTAUR IT IS PROHIBITED place in the unit compartment any foreign objects that interfere with the normal operation of the showcase. When placing the display case on objects with fuel and lubricant materials, the display case must be installed and operated in accordance with the national rules for the operation of electrical equipment and the rules for operation on objects with fuel and lubricant materials.
  • Page 11 CENTAUR 3. Dismantle the end grills (Fig. 6.1.2.) Fig. 6.1.2. End fittings 4. Dismantle the bars that fasten the showcase to the pallet (Fig. 6.1.3, a) 5. Remove the showcase from the pallet (Fig. 6.1.3, b) Fig. 6.1.3. a) location of fastening elements; b) pallet. 6.2.
  • Page 12 CENTAUR 2. Unscrew the M12 bolts that fix the stand in the lower position. Before twisting , support the showcase from below (Fig. 6.1.4, b). 3. Raise the stand to the upper position, fix with screws and bolts (Fig. 6.1.5.). Fig.
  • Page 13 CENTAUR The scheme of placement of the overbonnet showcase together with the bonnet 6.3. CONNECTION IT IS FORBIDDEN ! E exploitation showcases without availability in the network ground contact sockets . Not allowed connection several showcase into one power outlet through an " extension cord " with branching outlets .
  • Page 14: Start-Up

    CENTAUR 7. START-UP The showcase must be installed in such a way as to ensure free access to it. Guided by the recommendations from Appendix B, prepare the product for work. It is recommended to connect the showcase for the first time no earlier than 4 hours after its installation.
  • Page 15 CENTAUR Monitoring of compliance with the temperature regime is carried out using the Danfoss electronic con- troller ERC 112 C . Fig. 10.1. Control elements of the Danfoss controller ERC 112 C Control elements are buttons programmed as follows: K button Function _ Short-term pressing : Increasing the set temperature (settings)
  • Page 16: Defrost Mode

    CENTAUR Fig. 10.2. Display indication Display indication According to the display indication Temperature in volume. Operating mode code The cooling function is active Defrosting is active The evaporator fan is active Emergency signal 11. DEFROST MODE The showcase has an automatic defrost function. The frequency, duration and interval of the defrost start are set by the manufacturer at the factory.
  • Page 17: Product Loading

    CENTAUR WARNING! Leakage of melt water. • Do not allow the formation of puddles in front of and under the unit; • Remove the melted water that has leaked out immediately; • Contact the service department. 12. PRODUCT LOADING To ensure the normal and uninterrupted operation of the display case, as well as uniform and high-quality cooling of products, a number of recommendations should be followed: - it is forbidden to cover the cold air circulation holes inside the showcase with products - loading of products should be carried out without exceeding the loading norms and without going beyond...
  • Page 18 CENTAUR Technical maintenance of the showcase (except for the works specified in tab. 3) and troubleshooting is performed by specialists of the service center or the manufacturer's company according to the application for maintenance or repair. WARNING! A false call * of a specialist is paid by the owner. *A false call is considered a call if, at the time of the specialist's arrival, the showcase is functional and meets the technical characteristics specified in the operating instructions.
  • Page 19: Possible Faults And Their Remedies

    CENTAUR FORBIDDEN to clean the assembly part with a jet of water. 14. POSSIBLE FAULTS AND THEIR REMEDIES lists the possible malfunctions of the showcase and how to eliminate them. Table 4. List of possible display window malfunctions and ways to eliminate them Description of the malfunction Probable cause Method of elimination...
  • Page 20: Maintenance And Service

    CENTAUR The door does not close The door closing mechanism Contact the service department is damaged Door sagging 15. MAINTENANCE AND SERVICE For trouble-free operation of the showcase, preventive maintenance must be carried out once every three months (if necessary, more often), namely: - external inspection of the showcase;...
  • Page 21: Warranty From The Manufacturer

    CENTAUR 18. WARRANTY FROM THE MANUFACTURER The manufacturer guarantees the correct operation of the refrigerated display case in compliance with the requirements and rules of operation described in this manual, and undertakes warranty obligations for 1 year from the moment of sale, or the period specified in the contract. The display case model, number and date of sale are indicated in the passport by the manufacturer, or the relevant data is indicated by the company selling the display case.
  • Page 22 CENTAUR Authorized service Poland : UBC Logistyka Sp . z o. o Bosnia : NICROM COOLING DOO BYKOW, UL. GAJOWA 5 Milan Vrhovca 79, 79101 55-095 MIRKOW Prijedor , Republic of Srpska , BiH Wojtek Rytkowski Dragan Tankosic tel.:+48717400076 / tel . com.: +48603227267 tel .

This manual is also suitable for:

Centaur 2.5
