Random Vacuum Cleaner Instructions Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BR151 and is the answer not in the manual?

Questions and answers

Lauren m Gosnell
February 16, 2025

It just keeps spinning in circles and then blinks a red light. I have tried cleaning all sensors etc. It has never worked and still isn’t working.

3 comments:
Mr. Anderson
February 16, 2025

A red blinking light on the Onson BR151 indicates an abnormal warning, low battery, or that the device is not calibrated. If the robot is spinning in circles, it may be due to a calibration issue. To fix this, try recalibrating the device. If the issue persists, check for obstructions in the wheels or sensors and ensure the battery is sufficiently charged.

This answer is automatically generated

Chasity Moore
May 1, 2025

@Lauren m Gosnell

Chasity Moore
May 1, 2025

I just dealt with this problem. The frame wasn't aligned properly.

Darletta
February 17, 2025

Has stopped mopping. Tank is full of water

2 comments:
Mr. Anderson
February 17, 2025

The Onson BR151 may have stopped mopping even though the tank is full of water due to improper maintenance. A user mentioned that their original water tank filled with moss because they forgot to empty it after use. If the tank is not cleaned regularly, clogs or buildup could prevent water from flowing properly. Additionally, if cleaning solutions were used instead of just water, it might have caused blockages. Checking and cleaning the tank, ensuring proper installation, and avoiding cleaning solutions may help resolve the issue.

This answer is automatically generated

Amy
February 17, 2025

@Darletta

Hobbitlovr
May 29, 2025

How does the mop function work?

1 comments:
Mr. Anderson
May 29, 2025

The Onson BR151 mop function works by attaching a mopping cloth to a mopping holder, which is then installed on the robot. Water is added to a small water tank by opening the silica gel plug. The tank is installed into the robot, and the mop uses the water to clean the floor. It is effective only on dust-free floors and not suitable for carpets. After use, the tank and mop cloth should be cleaned and removed promptly.

This answer is automatically generated

Kathleen
May 17, 2025

While charging my vacuum, it's making a continual 'double' chirping sound. I've charged it before, and only the light flashed. Can you please tell me why it's chirping? Thank you!

1 comments:
Mr. Anderson
May 23, 2025

The continual 'double' chirping sound while charging may indicate an issue with charging or a low battery condition. According to the light indication system, during charging, the power light is steady green and the recharge light slowly blinks green. If there's a problem, such as battery over-discharge or the product not being used for a long time, it may not charge properly and could produce warning sounds. Ensure the charging electrodes are clean and the vacuum is properly seated on the charger. If the problem continues, the battery may be over-discharged and require service.

This answer is automatically generated

Elaine Ray
May 5, 2025

My vac indicates it is fully charged. Leaves the port, gets about a foot away does a circle and shuts down. One of my electrodes on the port seems to be discolored. Am I am to replace that part?

1 comments:
Mr. Anderson
May 18, 2025

Yes, a discolored electrode on the Onson BR151 vacuum could indicate dirt or damage, which may interfere with charging. If the vacuum is not fully charged due to poor contact, it could shut down after a short distance. Cleaning the charging electrode with a dry cloth is recommended.

This answer is automatically generated

ken
February 12, 2025

how do i clean hair from the wheels, brushes so forth?

1 comments:
Shanth
May 20, 2025

how do i clean hair from the wheels, brushes so forth?

Lolita Ignacio
January 30, 2025

How to switch from dry mopping to wet mopping

1 comments:
Mr. Anderson
February 10, 2025

To switch from dry mopping to wet mopping with the Onson BR151 robot vacuum, follow these steps:

1. Attach the Water Tank – Ensure the water tank is properly installed on the robot.
2. Install the Mop Pad – Attach the mop pad to the designated area on the robot.
3. Turn on the Robot – Press the power button to start the cleaning process.
4. Avoid Carpets – Lift carpets or ensure the robot does not go over them while wet mopping.

This setup enables the robot to perform wet mopping instead of just dry cleaning.

This answer is automatically generated

Michael Stevens
August 6, 2025

I lost the remote control

Emlyn
July 3, 2025

How to start mopping function from the remote

Earl M Hill
July 3, 2025

set clock on remote

Summary of Contents for Onson BR151

  • Page 1 Random Vacuum Cleaner Instructions Manual...
  • Page 2 Safety Regulations Before using this product,please read the following safety instructions and follow all routine safety precautions. Please read the instructions carefully , please keep the instructions. Any operation inconsistent with this instruction manual may cause damage to this product. Note:...
  • Page 3: Table Of Contents

    Table of Contents Product Composition / Package Contents......................3 Product Composition/Parts............................. 4 Preparations................................6 Using the Product - Charging the robot vacuum cleaner...................7 Product Usage - Start Cleaning..........................8 Product Usage- Pause, Wake-up and Shutdown....................9 Cleaning Mode............................... 10 Product Usage/Wi-Fi connection......................... 11 Product Usage/Install the mopping holder......................
  • Page 4: Product Composition / Package Contents

    Product Composition / Package Contents 1x Robot Vacuum 1x Charging Dock 2x Battery 1x Remote Control 1x Adapter 1x mopping holder assembly 1x watertank 1x dustbin 1x Cleaning Brush 1x Instruction Manual 2x Side Brush 4xFilter Cotton...
  • Page 5: Product Composition/Parts

    Product Composition/Parts Front of the main unit Rear of the main unit Lower visual sensor Recharge Power button Side brush button Surface cover Water tank button Driving wheel Omnidirectional lens Charging electrode Universal wheel Dust box Battery...
  • Page 6 Dust box Charging pile Dust box flip Signal indicator Dust box conductive spring DC plug HEPA filter Charging electrode Remote control Edge cleaning Power On/Off Recharge Automatic cleaning Spot cleaning Pause/Start Direction control Water flow adjustment Zig-zag cleaning Suction adjustment...
  • Page 7: Preparations

    Preparations Removing protective strips Before using the cleaner, remove protective strips from the cleaner. Removing protective strips Removing protective film...
  • Page 8: Using The Product - Charging The Robot Vacuum Cleaner

    Using the Product - Charging the robot vacuum cleaner 1. Place the charging stand on the flat ground against the wall. Do not place any articles 0.5 m on the left and right of the charging stand or 1.5 m in front of the charging stand. During cleaning, the main unit automatically checks its power level.
  • Page 9: Product Usage - Start Cleaning

    Product Usage - Start Cleaning Spot Cleaning For different cleaning requirements, this product provides multiple Applicable scenario: The cleaning mode is applicable to the cleaning modes for you to choose. You can use different cleaning ground environment where rubbish is concentrated. The main unit modes through the main unit or remote control.
  • Page 10: Product Usage- Pause, Wake-Up And Shutdown

    Product Usage- Pause, Wake-up and Shutdown Pause: When the main unit is working, press the power button on the main unit or press the pause key on the remote control to suspend the main unit. Wake-up: After the main unit is suspended for more than 10 minutes, the main unit activates the sleep mode (the indicator of the main unit is off).
  • Page 11: Cleaning Mode

    Cleaning Mode 1. Random Cleaning Robot random cleaning for 90 minutes, after the cleaning finished, it will auto back to recharging. 2. Edge Cleaning Robot proceed edge cleaning with a distance less than 2CM to the wall. 3. Spot Cleaning Robot firstly clockwise in outer spiral cleaning method by default,after reaching the maximum radius of 0.6 meters, the inner spiral cleaning is performed, and the cleaning ends after returning to the starting position.
  • Page 12: Product Usage/Wi-Fi Connection

    Product Usage/Wi-Fi connection 1. Download APP/Register Scan the QR code in below picture or search“Tuya Smart”from APP store and download it. Register it according to the APP operation instruction. 2. Wi-Fi Connection There are two Wi-Fi connection modes: EZ mode and AP mode.
  • Page 13 (1)EZ mode: 1. Power on the robot, press and hold recharge button for 3 seconds to enter EZ mode, you will hear a beep voice, power light turns yellow and blinks. 2. Log in your Tuya APP 3.Select “Small Home 4.Select 2.4 Ghz Wi-Fi 5.Select EZ mode, click and click”Add Device”...
  • Page 14 (2)AP mode: 1. Power on the robot, press and hold recharge button for 6 seconds to enter AP mode, you will hear beep voice twice, power light turns yellow and blinks. 2. Log in your TUYA APP 3.Select “Small Home 4.Select 2.4 Ghz Wi-Fi and click “Add Device”...
  • Page 15 5.Select AP mode, and 6.Go to connect with 7.After connected with click “confirm the the hot-spot WI-FI hot-spot Wi-Fi, return to indicator is blinking which start with” Tuya APP interface and slowly” and “Next”. SmartLife XXX” wait for robot connection result.
  • Page 16: Product Usage/Install The Mopping Holder

    Product Usage/Install the mopping holder A.Install the mopping cloth to the mopping holder; B.Install the mopping holder to the robot;...
  • Page 17: Product Usage/Watertank

    Product Usage/Watertank * Please do not use mopping function in the carpet. * After mopping finished, please clean the watertank and disassemble the mop cloth in time. A.Take out the watertank; C.Flatten the rubber plug B.Open the silica gel plug and add water; D.Install the watertank to robot...
  • Page 18: Parts Maintenance - Dust Box

    Parts Maintenance – Dust Box A. Press the button on the dust box to remove the dust box. C. Dump rubbish. B. Open the side cover of the dust box. D. Take out the HEPA filter.
  • Page 19 E. Tap the HEPA filter to remove dust. G. Clean the dust box with a cloth. F. Wash the HEPA filter.
  • Page 20 H. Dry the dust box and filter component to guarantee their service life. Note: It is recommended that you wash the HEPA filter every 15 to 30 days. The maximum service life of the HEPA filter is three months. I. Put the HEPA filter back into the dust box. Note: 1.
  • Page 21: Parts Maintenance/Filter Cotton

    Parts Maintenance/Filter Cotton A.Take out the outlet rubber plug ; C.change a new filter cotton; B.Take out the filter cotton from outlet rubber plug; D.Install the outlet rubber plug。...
  • Page 22: Parts Maintenance - Charging Electrode, Lower Visual Sensor, Driving Wheel And Universal Wheel

    Parts Maintenance – Charging Electrode, Lower Visual Sensor, Driving Wheel and Universal Wheel Note: The charging electrode, lower visual sensor and bumper contain sensitive electronic components. Use a dry cloth to clean the parts. Do not use a wet cloth in case water enters the parts and causes damage Cleaning the charging electrode Cleaning the driving wheel and universal wheel Cleaning the lower visual sensor...
  • Page 23: Light Indication

    Light indication Robot has two light indication, the upper is power and the under is recharging. Light has three color: red, green and yellow. Light status have lights off, lights steady on, quick blink and slow blink. Definition of light Item Contents Power...
  • Page 24: Product Specifications

    Product Specifications Item Specification Category Diameter 300 mm Height 74 mm Structure Net weight 2.5 kg Voltage 14.4 V Battery Battery 2500 mAh rechargeable lithium battery Dust box capacity 200 ml Charging type Auto charging and manual charging Cleaning parameters Cleaning mode Auto cleaning;...
  • Page 25: Security Information

    Security Information Hazardous Substance Hexavalent Component Mercury (Hg) Cadmium (Cd) Polybrominated Lead (Pb) and chromium Polybrominateddiphenylether Type and its and its biphenyls its compounds (Cr(VI)) and its (PBDE) compounds compounds (PBB) compounds Plastic parts 〇 〇 〇 〇 〇 〇 Metal parts 〇...
  • Page 26 Warnings about battery You must not remove (or attempt to remove) the battery incorporated in this product on your own. To replace the battery, you must contact your service provider or an independent qualified professional. These instructions have been prepared for the exclusive use of your service provider or independent qualified professional.
